WIN81803 WIND-4 Test Setup Photos - FCC ID SS3-WIN81803

FCC ID SS3-WIN81803

Setup Photos

WIND-4

by SZ DJI TECHNOLOGY CO., LTD

Document preview loads when visible.

Document Details

FCC IDSS3-WIN81803
Document ID3826907
Document TypeTest Setup Photos
DescriptionSetup Photos
Document TitleTest Setup Photos_DTS
ApplicantSZ DJI TECHNOLOGY CO., LTD
Equipment ClassWIND-4
Product CodeWIN81803
Application IDmlKzz7ax+88krsvyradnHQ==
Application PurposeOriginal Equipment
Application Date2018-04-23
Frequency Range2406.5-2476.5 MHz
FRN0022596753
Test FirmBay Area Compliance Laboratories Corp.(Dongguan)
Certified ByXi Xiang
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date06/07/2018
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2018-04-23
Available2018-06-07
Created2018-04-12
Modified2018-04-12
Pages3
File TypeAdobe Acrobat PDF
File Size313123
File SHA-25652717d1c9062b59e63767b9fc7f6b0ca5b2be4c42e7febb77a506908988a8e71
PDF Metadata AuthorDG06198
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows) DG06198
FCC.gov SourcesFCC.gov 3826907
