FCC ID STZAIR600AC
VHF Fixed Station Remote Telemetry Transceiver
by Simoco Wireless Solutions Pty Ltd
Grantee Code: STZ Product Code: AIR600AC
Latest application date: 2017-02-28
Device Images
FCC ID Device Details
| FCC ID | STZAIR600AC |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | STZ |
| Product Code | AIR600AC |
| Applicant Business | Simoco Wireless Solutions Pty Ltd 🇦🇺 |
| Related Domains |  simocowirelesssolutions.com |
| Equipment Class | VHF Fixed Station Remote Telemetry Transceiver |
| Test Firm | EMC Technologies NZ Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 150-174 MHz | Original Equipment | 2017-02-28 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-02-28 | PDF 597.8 KB |
| Internal Photos | Internal Photos | 2017-02-28 | PDF 3.2 MB |
| External Photos | External Photos | 2017-02-28 | PDF 689.4 KB |
| Label Details | ID Label/Location Info | 2017-02-28 | PDF 312.9 KB |
| Radiated Emission Test Set Up Photos | Test Setup Photos | 2017-02-28 | PDF 1.1 MB |
| Radiated Hazard Assessment | Test Report | 2017-02-28 | PDF 131.5 KB |
| Test Report | Test Report | 2017-02-28 | PDF 594.9 KB |
| Frequency Programming Attestation | Attestation Statements | 2017-02-28 | PDF 117.4 KB |
| Part 15 Attestation | Attestation Statements | 2017-02-28 | PDF 24.3 KB |
| Power Amplifier Attestation | Attestation Statements | 2017-02-28 | PDF 116.4 KB |
| Spectrum Efficiency Attestation | Attestation Statements | 2017-02-28 | PDF 116.1 KB |
| Authorization to Act letter | Cover Letter(s) | 2017-02-28 | PDF 115 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2017-02-28 | PDF 116.3 KB |
| Extended Frequency Justification | Cover Letter(s) | 2017-02-28 | PDF 117.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 181.7 KB | |
| Schematics Metadata only | Schematics | PDF 3.5 MB | |
| Operational Description Metadata only | Operational Description | PDF 199.1 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 84.8 KB | |
| Tune-Up Procedure Metadata only | Parts List/Tune Up Info | PDF 671.5 KB |
Application Information
| Application ID | IYDsg6IaljpavmcT81ASNQ== |
|---|---|
| Final Action Date | 2017-02-28 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0010966224 |
| Model | AIR600AC |
| Frequency Range | 150-174 MHz |
| Equipment Class | TNB - Licensed Non-Broadcast Station Transmitter |
| Device Description | VHF Fixed Station Remote Telemetry Transceiver |
| Responsible Party | Barend Gildenhuys, Mr, barend.gildenhuys@simocowirelesssolutions.com , +44 (0) 1332 375 500 |
| Test Firm | Andrew Cutler, EMC Technologies NZ Ltd., auklab@ihug.co.nz  , 64-9-360-0862 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output Power listed is rated conducted; maximum conducted output power as allowed by 47 CFR 90.205(s) is 5 W. All qualified end-users of this device must have the knowledge to control their exposure conditions and/or duration, and the exposure conditions and/or duration of their passengers and bystanders, to comply with the General Population / Uncontrolled MPE limit and requirements. The antenna used for this transmitter must be installed to provide a minimum separation distances of 80-cm from all persons, as described in this filing, must not exceed 6 dBd gain, and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions, including antenna co-location requirements of § 1.1307(b)(3), for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| IYDsg6IaljpavmcT81ASNQ== | 2017-02-28 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application IYDsg6IaljpavmcT81ASNQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 02/28/2017 Application Dated: 02/28/2017 |
| Simoco Wireless Solutions Pty Ltd |
| 1270 Ferntree Gully Road |
| Scoresby |
| Melbourne, Victoria, 3179 Australia |
| Attention: Barend Gildenhuys , Mr |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | STZAIR600AC |
| Name of Grantee: | Simoco Wireless Solutions Pty Ltd |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | VHF Fixed Station Remote Telemetry Transceiver |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| BC EF ES | 90 | 150.0 - 174.0 | 5.0 | 5.0 PM | 7K60FXD |
| BC EF ES | 90 | 150.0 - 174.0 | 5.0 | 5.0 PM | 7K60FXE |
| Output Power listed is rated conducted; maximum conducted output power as allowed by 47 CFR 90.205(s) is 5 W. All qualified end-users of this device must have the knowledge to control their exposure conditions and/or duration, and the exposure conditions and/or duration of their passengers and bystanders, to comply with the General Population / Uncontrolled MPE limit and requirements. The antenna used for this transmitter must be installed to provide a minimum separation distances of 80-cm from all persons, as described in this filing, must not exceed 6 dBd gain, and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions, including antenna co-location requirements of § 1.1307(b)(3), for satisfying RF exposure compliance. |
| BC: | The output power is continuously variable from the value listed in this entry to 5%-10% of the value listed. |
| EF: | This device may contain functions that are not operational in U.S Territories except as noted in the filing. This grant has extended frequencies as noted in the filing and Section 2.927(b) applies to this authorization. |
| ES: | This equipment is capable of supporting a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth. |
EAS Grant - Application IYDsg6IaljpavmcT81ASNQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Simoco Wireless Solutions Pty Ltd 1270 Ferntree Gully Road Scoresby Melbourne, Victoria, 3179 Australia |
Date of Grant: 02/28/2017 Application Dated: 02/28/2017 |
| Attention: Barend Gildenhuys , Mr |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | STZAIR600AC |
| Name of Grantee: | Simoco Wireless Solutions Pty Ltd |
| Equipment Class: | Licensed Non-Broadcast Station Transmitter |
| Notes: | VHF Fixed Station Remote Telemetry Transceiver |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| BC EF ES | 90 | 150.0 - 174.0 | 5.0 | 5.0 PM | 7K60FXD |
| BC EF ES | 90 | 150.0 - 174.0 | 5.0 | 5.0 PM | 7K60FXE |
| Output Power listed is rated conducted; maximum conducted output power as allowed by 47 CFR 90.205(s) is 5 W. All qualified end-users of this device must have the knowledge to control their exposure conditions and/or duration, and the exposure conditions and/or duration of their passengers and bystanders, to comply with the General Population / Uncontrolled MPE limit and requirements. The antenna used for this transmitter must be installed to provide a minimum separation distances of 80-cm from all persons, as described in this filing, must not exceed 6 dBd gain, and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions, including antenna co-location requirements of § 1.1307(b)(3), for satisfying RF exposure compliance. |
| BC: | The output power is continuously variable from the value listed in this entry to 5%-10% of the value listed. |
| EF: | This device may contain functions that are not operational in U.S Territories except as noted in the filing. This grant has extended frequencies as noted in the filing and Section 2.927(b) applies to this authorization. |
| ES: | This equipment is capable of supporting a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth. |
