DTZ2100 LCD Monitor Test Setup Photos - FCC ID SUZDTZ2100

FCC ID SUZDTZ2100

Test Setup Photos

LCD Monitor

by Coretronic Corp.

Document preview loads when visible.

Document Details

FCC IDSUZDTZ2100
Document ID509008
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitleRF931227H03_15.209_
ApplicantCoretronic Corp.
Equipment ClassLCD Monitor
Product CodeDTZ2100
Application IDBG59DgycPGaPmW9pNBlZag==
Application PurposeOriginal Equipment
Application Date2005-01-25
Frequency Range0.667 MHz
FRN0013602586
Test FirmBureau Veritas CPS (H.K.) Ltd. Taoyuan Branch
Certified ByEric Lin Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-01-25
Available2005-01-25
Created2005-01-17
Modified2005-01-17
Pages2
File TypeAdobe Acrobat PDF
File Size247029
File SHA-256c23a0b6db51b021f653ed2eddd91ee33ee19ba0bed9aa37b004358ab49dc227b
PDF Metadata Authormidoli2
PDF Metadata ProducerAcrobat Distiller 5.0 (Windows) midoli2
FCC.gov SourcesFCC.gov 509008
