FCC ID SVNDH-PFM88
5G Wireless Video Transmission Device CPE
by Zhejiang Dahua Vision Technology Co., Ltd
Grantee Code: SVN Product Code: DHPFM88
Latest application date: 2016-06-08
Device Images
FCC ID Device Details
| FCC ID | SVNDH-PFM88 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | SVN |
| Product Code | DHPFM88 |
| Applicant Business | Zhejiang Dahua Vision Technology Co., Ltd 🇨🇳 |
| Related Domains |  dahuatech.com |
| Equipment Class | 5G Wireless Video Transmission Device CPE |
| Test Firm | SGS-CSTC Standards Technical Services Co.,Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5745-5825 MHz | Original Equipment | 2016-06-08 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-06-08 | PDF 1.2 MB |
| Internal Photos | Internal Photos | 2016-06-08 | PDF 2.6 MB |
| External Photos | External Photos | 2016-06-08 | PDF 1.4 MB |
| Label Location | ID Label/Location Info | 2016-06-08 | PDF 162.9 KB |
| Test Setup Photos | Test Setup Photos | 2016-06-08 | PDF 482.8 KB |
| Test Report WiFi | Test Report | 2016-06-08 | PDF 2.1 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-06-08 | PDF 34.5 KB |
| Declaration Letter about Professional Installation | Cover Letter(s) | 2016-06-08 | PDF 13.7 KB |
| POA | Cover Letter(s) | 2016-06-08 | PDF 35.5 KB |
| MPE Report | RF Exposure Info | 2016-06-08 | PDF 145.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 33.1 KB | |
| Schematics Metadata only | Schematics | PDF 159.1 KB | |
| Operational Description Metadata only | Operational Description | PDF 19.5 KB | |
| Operational Description Software Secuirty Metadata only | SDR Software/Security Inf | PDF 21.2 KB |
Application Information
| Application ID | 5ZEKq+dxj3Wg6BSQAQ896w== |
|---|---|
| Final Action Date | 2016-06-08 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0028432326 |
| Model | DH-PFM88 |
| Frequency Range | 5745-5825 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | 5G Wireless Video Transmission Device CPE |
| Responsible Party | Yolanda chen, chen_yunhuan@dahuatech.com , 0571-28822025 |
| Test Firm | Zenger Zhang, SGS-CSTC Standards Technical Services Co.,Ltd., zenger.zhang@sgs.com  , 86(0)2161915654 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Installers and end-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance This device is can be used as used as WIFI AP, CPE, or outdoor PTP, PTMP. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 5ZEKq+dxj3Wg6BSQAQ896w== | 2016-06-08 | Original Equipment |
Grants
TCB Grant - Application 5ZEKq+dxj3Wg6BSQAQ896w==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 06/08/2016 Application Dated: 06/08/2016 |
| Zhejiang Dahua Vision Technology Co., Ltd |
| No.1199, Bin'an Road, Binjiang District, Hangzhou, |
| P.R. China |
| Hangzhou, 310053 China |
| Attention: Yolanda chen |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SVNDH-PFM88 |
| Name of Grantee: | Zhejiang Dahua Vision Technology Co., Ltd |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 5G Wireless Video Transmission Device CPE |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 | 15E | 5745.0 - 5825.0 | 0.019 |
| Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Installers and end-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance This device is can be used as used as WIFI AP, CPE, or outdoor PTP, PTMP. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
EAS Grant - Application 5ZEKq+dxj3Wg6BSQAQ896w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Zhejiang Dahua Vision Technology Co., Ltd No.1199, Bin'an Road, Binjiang District, Hangzhou, P.R. China Hangzhou, 310053 China |
Date of Grant: 06/08/2016 Application Dated: 06/08/2016 |
| Attention: Yolanda chen |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SVNDH-PFM88 |
| Name of Grantee: | Zhejiang Dahua Vision Technology Co., Ltd |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 5G Wireless Video Transmission Device CPE |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 | 15E | 5745.0 - 5825.0 | 0.019 |
| Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Installers and end-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance This device is can be used as used as WIFI AP, CPE, or outdoor PTP, PTMP. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| Mail To: |
