MV190T LCD TV & MONITOR Block Diagram - FCC ID SWMMV190T

FCC ID SWMMV190T

BLOCK DIAGRAM

LCD TV & MONITOR

by SNC Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDSWMMV190T
Document ID615382
Document TypeBlock Diagram
DescriptionBLOCK DIAGRAM
Document Title<C0FCC3BC20C6E4C0CCC1F620C6D1BDBA20C0CEBCE2>
ApplicantSNC Co., Ltd.
Equipment ClassLCD TV & MONITOR
Product CodeMV190T
Application IDw5zYYlEPw6C523XT1BBF/w==
Application PurposeOriginal Equipment
Application Date2005-12-27
FRN0012547998
Test FirmKOSTEC Co., Ltd.
Certified ByHYEON-JONG SHIN MANAGER
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-12-27
Available2005-12-27
Created2005-12-21
Modified2005-12-21
Pages1
File TypeAdobe Acrobat PDF
File Size64690
File SHA-256f162fcdda4e28a76498d33eeda575f9cde06918e99252d68b86688f915d7f75b
PDF Metadata Author<B1E8C7CFC7FC>
PDF Metadata ProducerAcrobat Distiller 6.0 (Windows) <B1E8C7CFC7FC>
FCC.gov SourcesFCC.gov 615382
