FCC ID SWPEVB019-BLE
Legacy View Valve
by CHANDLER SYSTEMS, INC.
Grantee Code: SWP Product Code: EVB019BLE
Latest application date: 2016-08-08
Device Images
FCC ID Device Details
| FCC ID | SWPEVB019-BLE |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | SWP |
| Product Code | EVB019BLE |
| Applicant Business | CHANDLER SYSTEMS, INC. 🇺🇸 |
| Related Domains |  chandlersystemsinc.com |
| Equipment Class | Legacy View Valve |
| Test Firm | Shenzhen STS Test Services Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-08-08 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-08-08 | PDF 1.5 MB |
| Internal Photo | Internal Photos | 2016-08-08 | PDF 672.9 KB |
| Exernal Photos | External Photos | 2016-08-08 | PDF 499.2 KB |
| label & Location | ID Label/Location Info | 2016-08-08 | PDF 118.3 KB |
| setup photo | Test Setup Photos | 2016-08-08 | PDF 275.1 KB |
| Test Report | Test Report | 2016-08-08 | PDF 1.8 MB |
| AuthorizationLetter | Cover Letter(s) | 2016-08-08 | PDF 9.8 KB |
| Long Term Confidentiality Request Letter | Cover Letter(s) | 2016-08-08 | PDF 14.8 KB |
| RF exposure letter | RF Exposure Info | 2016-08-08 | PDF 112.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 181.4 KB | |
| SCH Metadata only | Schematics | PDF 125.5 KB | |
| Operational description Metadata only | Operational Description | PDF 187.5 KB |
Application Information
| Application ID | AJ5ZwKsn97diSwgCzFjY/w== |
|---|---|
| Final Action Date | 2016-08-08 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0022628176 |
| Model | EVB019-BLE |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Legacy View Valve |
| Responsible Party | BILL KIRKWOOD, CONTROLLER, bkirkwood@chandlersystemsinc.com , 419-281-6829 |
| Technical Contact | Bovey Yang, Shenzhen STS Test Services Co., Ltd, bovey@stsapp.com  , 86-0755-36886288 |
| Test Firm | Bovey Yang, Shenzhen STS Test Services Co., Ltd., bovey@stsapp.com , (86)-0755-61996328 |
| TCB Email | tcbinfo@metlabs.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power is conducted. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| AJ5ZwKsn97diSwgCzFjY/w== | 2016-08-08 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0006000 | 15C |
Grants
TCB Grant - Application AJ5ZwKsn97diSwgCzFjY/w==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Electrical and Electronic Testing NA, Inc 914 W. Patapsco Avenue Baltimore, MD 21230-3432 |
Date of Grant: 08/08/2016 Application Dated: 08/08/2016 |
| CHANDLER SYSTEMS, INC. |
| 710 ORANGE STREET |
| ASHLAND, OH 44805 |
| Attention: BILL KIRKWOOD , CONTROLLER |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SWPEVB019-BLE |
| Name of Grantee: | CHANDLER SYSTEMS, INC. |
| Equipment Class: | Digital Transmission System |
| Notes: | Legacy View Valve |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0006 |
| Output power is conducted. |
| Output power is conducted. |
EAS Grant - Application AJ5ZwKsn97diSwgCzFjY/w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
CHANDLER SYSTEMS, INC. 710 ORANGE STREET ASHLAND, OH 44805 United States |
Date of Grant: 08/08/2016 Application Dated: 08/08/2016 |
| Attention: BILL KIRKWOOD , CONTROLLER |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SWPEVB019-BLE |
| Name of Grantee: | CHANDLER SYSTEMS, INC. |
| Equipment Class: | Digital Transmission System |
| Notes: | Legacy View Valve |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0006 |
| Output power is conducted. |
| Output power is conducted. |
