FCC ID SWX-AFP
Mesh Points
by Ubiquiti Inc.
Grantee Code: SWX Product Code: AFP
Latest application date: 2016-06-13
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-06-13 |
| 2402-2480 MHz | Original Equipment | 2016-06-13 |
| 5180-5240 MHz | Original Equipment | 2016-06-13 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-12-10 | PDF 5.7 MB |
| Internal Photos | Internal Photos | 2016-12-10 | PDF 2.4 MB |
| External Photos | External Photos | 2016-12-10 | PDF 760.8 KB |
| Label Info | ID Label/Location Info | 2016-06-13 | PDF 192.5 KB |
| Label Info AFi-P | ID Label/Location Info | 2016-06-13 | PDF 192.5 KB |
| Label Info AFi-P-LP | ID Label/Location Info | 2016-06-13 | PDF 200 KB |
| Test Setup Photos DSS | Test Setup Photos | 2016-12-10 | PDF 266.9 KB |
| Test Setup Photos DTS BT LE | Test Setup Photos | 2016-12-10 | PDF 270 KB |
| Test Setup Photos DTS WLAN | Test Setup Photos | 2016-12-10 | PDF 251.6 KB |
| Test Setup Photos NII B1-B3 | Test Setup Photos | 2016-12-10 | PDF 265.4 KB |
| Test Setup Photos NII B4 | Test Setup Photos | 2016-12-10 | PDF 260.2 KB |
| Test Report DSS | Test Report | 2016-06-13 | PDF 2.2 MB |
| Test Report DTS BT LE | Test Report | 2016-06-13 | PDF 1.7 MB |
| Test Report DTS WLAN | Test Report | 2016-06-13 | PDF 5.2 MB |
| Test Report NII B1 | Test Report | 2016-06-13 | PDF 2.4 MB |
| Test Report NII B4 | Test Report | 2016-06-13 | PDF 2.3 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-06-13 | PDF 77.2 KB |
| Declaration Letter | Cover Letter(s) | 2016-06-13 | PDF 116.5 KB |
| Declaration of Function disabled | Cover Letter(s) | 2016-06-13 | PDF 92.4 KB |
| POA | Cover Letter(s) | 2016-06-13 | PDF 73.3 KB |
| RF Exposure | RF Exposure Info | 2016-06-13 | PDF 350.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 31.6 KB | |
| Schematics Metadata only | Schematics | PDF 239.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 204.7 KB | |
| Operational Description Software Security Metadata only | SDR Software/Security Inf | PDF 52.6 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 166.4 KB | |
| Tune Up Procedure Metadata only | Parts List/Tune Up Info | PDF 94.1 KB |
Application Information
| Application ID | siPhCBPivpKJgIyPMRQciQ== |
|---|---|
| Final Action Date | 2016-06-13 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0012268215 |
| Model | AFP |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Mesh Points |
| Responsible Party | Mark Feil, Compliance Director, compliance@ui.com  , 385-293-3532 |
| Test Firm | Alex Chen, SPORTON International Inc., alex@sporton.com.tw  , 886-3-327-3456 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 12/10/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
