FCC ID SWX-M442G
WiFi 2.4G Module
by Ubiquiti Inc.
Grantee Code: SWX Product Code: M442G
Latest application date: 2016-10-04
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-10-04 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-10-04 | PDF 299.5 KB |
| Users Manual Statement Letter Metadata only | Cover Letter(s) | 2016-10-04 | PDF 44.6 KB |
| Internal Photo | Internal Photos | 2016-10-04 | PDF 644.4 KB |
| External Photos | External Photos | 2016-10-04 | PDF 234.5 KB |
| Label and Location | ID Label/Location Info | 2016-10-04 | PDF 77.7 KB |
| Test Photos | Test Setup Photos | 2016-10-04 | PDF 304.3 KB |
| MPE Test Report | RF Exposure Info | 2016-10-04 | PDF 351.7 KB |
| Test Report | Test Report | 2016-10-04 | PDF 5.3 MB |
| Confidentiality Letter | Cover Letter(s) | 2016-10-04 | PDF 44.4 KB |
| Modular Approval Letter | Cover Letter(s) | 2016-10-04 | PDF 17 KB |
| POA | Cover Letter(s) | 2016-10-04 | PDF 44.8 KB |
| um Statement letter | Cover Letter(s) | 2016-10-04 | PDF 44.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 10.6 KB | |
| Schematics Metadata only | Schematics | PDF 170.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 68.1 KB |
Application Information
| Application ID | oFYa34d/Vxij5Byb3E5hhg== |
|---|---|
| Final Action Date | 2016-10-04 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0012268215 |
| Model | M442G |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | WiFi 2.4G Module |
| Responsible Party | Mark Feil, Compliance Director, compliance@ui.com  , 385-293-3532 |
| Test Firm | Sharon Jiang, SPORTON International Inc., sharonjiang@sporton.com.tw  , 886-3-656-9065 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Power listed is maximum combined output power conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This module is restricted to installation in products for use only in mobile and fixed applications. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20 MHz and 40 MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| oFYa34d/Vxij5Byb3E5hhg== | 2016-10-04 | Original Equipment |
Grants
TCB Grant - Application oFYa34d/Vxij5Byb3E5hhg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 10/04/2016 Application Dated: 10/04/2016 |
| Ubiquiti Inc. |
| 685 Third Avenue |
| New York, NY 10017 |
| Attention: Mark Feil , Compliance Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SWX-M442G |
| Name of Grantee: | Ubiquiti Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | WiFi 2.4G Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.269 |
| Single Modular Approval. Power listed is maximum combined output power conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This module is restricted to installation in products for use only in mobile and fixed applications. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20 MHz and 40 MHz bandwidth modes. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application oFYa34d/Vxij5Byb3E5hhg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Ubiquiti Inc. 685 Third Avenue New York, NY 10017 United States |
Date of Grant: 10/04/2016 Application Dated: 10/04/2016 |
| Attention: Mark Feil , Compliance Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SWX-M442G |
| Name of Grantee: | Ubiquiti Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | WiFi 2.4G Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.269 |
| Single Modular Approval. Power listed is maximum combined output power conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This module is restricted to installation in products for use only in mobile and fixed applications. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. This device has 20 MHz and 40 MHz bandwidth modes. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
