FCC ID SWX-R5ACPTMP
Rocket 5AC PTMP
by Ubiquiti Inc.
Grantee Code: SWX Product Code: R5ACPTMP
Latest application date: 2016-03-25
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5735-5840 MHz | Class II permissive change or modification of presently authorized equipment | 2016-03-25 |
| 5480-5715 MHz | Class II permissive change or modification of presently authorized equipment | 2015-09-23 |
| 5735-5840 MHz | Original Equipment | 2015-05-01 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-03-25 | PDF 3.6 MB |
| Manual | Users Manual | 2015-09-23 | PDF 3.4 MB |
| Manual | Users Manual | 2015-06-22 | PDF 3.6 MB |
| Internal Photos1M | Internal Photos | 2015-06-22 | PDF 513 KB |
| Internal Photos Metadata only | Internal Photos | 2015-05-01 | PDF 513 KB |
| External Photos1 | External Photos | 2015-06-22 | PDF 492.4 KB |
| External Photos Metadata only | External Photos | 2015-05-01 | PDF 492.4 KB |
| Label and Location | ID Label/Location Info | 2015-05-01 | PDF 1.3 MB |
| Antenna 3 | Block Diagram | 2015-05-01 | PDF 4.8 MB |
| Test Setup Photos | Test Setup Photos | 2015-09-23 | PDF 392.9 KB |
| Annex A | Test Report | 2016-03-25 | PDF 49 KB |
| FCC Part 1.1310 test report | Test Report | 2016-03-25 | PDF 369.9 KB |
| FCC Part 15.407 test report | Test Report | 2016-03-25 | PDF 214.3 KB |
| Annex A | Test Report | 2015-09-23 | PDF 269.9 KB |
| Annex B | Test Report | 2015-09-23 | PDF 1.2 MB |
| Annex C | Test Report | 2015-09-23 | PDF 331.7 KB |
| Annex D | Test Report | 2015-09-23 | PDF 582.2 KB |
| Annex E | Test Report | 2015-09-23 | PDF 169 KB |
| Annex F | Test Report | 2015-09-23 | PDF 208.3 KB |
| DFS Annex A | Test Report | 2015-09-23 | PDF 149.6 KB |
| DFS Annex B | Test Report | 2015-09-23 | PDF 81.3 KB |
| DFS Annex C | Test Report | 2015-09-23 | PDF 77.3 KB |
| DFS Annex D | Test Report | 2015-09-23 | PDF 158.5 KB |
| Part 15.407 DFS | Test Report | 2015-09-23 | PDF 1 MB |
| Part 15.407 UNII-2 | Test Report | 2015-09-23 | PDF 504.8 KB |
| Annex A | Test Report | 2015-05-01 | PDF 221.3 KB |
| Annex B | Test Report | 2015-05-01 | PDF 1.5 MB |
| Annex C | Test Report | 2015-05-01 | PDF 335.3 KB |
| Annex D | Test Report | 2015-05-01 | PDF 588.7 KB |
| Annex E | Test Report | 2015-05-01 | PDF 171 KB |
| Annex F | Test Report | 2015-05-01 | PDF 207.5 KB |
| Test Report | Test Report | 2015-05-01 | PDF 510.9 KB |
| Attestation | Attestation Statements | 2015-09-23 | PDF 70.4 KB |
| Agent Authorization Letter | Cover Letter(s) | 2016-03-25 | PDF 33.3 KB |
| Permissive Change Letter | Cover Letter(s) | 2016-03-25 | PDF 22.8 KB |
| C2PC | Cover Letter(s) | 2015-09-23 | PDF 159.2 KB |
| Correspondence | Cover Letter(s) | 2015-09-23 | PDF 96.2 KB |
| Agent Auth | Cover Letter(s) | 2015-05-01 | PDF 33.3 KB |
| Antenna 1 | Cover Letter(s) | 2015-05-01 | PDF 3.9 MB |
| Antenna 10 | Cover Letter(s) | 2015-05-01 | PDF 3.5 MB |
| Antenna 11 | Cover Letter(s) | 2015-05-01 | PDF 1.2 MB |
| Antenna 12 | Cover Letter(s) | 2015-05-01 | PDF 4.7 MB |
| Antenna 13 | Cover Letter(s) | 2015-05-01 | PDF 1.2 MB |
| Antenna 2 | Cover Letter(s) | 2015-05-01 | PDF 3.9 MB |
| Antenna 4 | Cover Letter(s) | 2015-05-01 | PDF 4.8 MB |
| Antenna 5 | Cover Letter(s) | 2015-05-01 | PDF 4.8 MB |
| Antenna 6 | Cover Letter(s) | 2015-05-01 | PDF 4.8 MB |
| Antenna 7 | Cover Letter(s) | 2015-05-01 | PDF 3.5 MB |
| Antenna 8 | Cover Letter(s) | 2015-05-01 | PDF 4.6 MB |
| Antenna 9 | Cover Letter(s) | 2015-05-01 | PDF 4.6 MB |
| Correspondence | Cover Letter(s) | 2015-05-01 | PDF 96.4 KB |
| Long Term Confidentiality | Cover Letter(s) | 2015-05-01 | PDF 47.1 KB |
| Short Term Confidentiality | Cover Letter(s) | 2015-05-01 | PDF 48.4 KB |
| Part 1.1310 UNII-2 | RF Exposure Info | 2015-09-23 | PDF 265.7 KB |
| RF Exposure | RF Exposure Info | 2015-05-01 | PDF 262.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 25 KB | |
| Schematics Metadata only | Schematics | PDF 592.7 KB | |
| Theory of Op Metadata only | Operational Description | PDF 63.1 KB | |
| UNII Security 11AC Metadata only | SDR Software/Security Inf | PDF 209.7 KB | |
| UNII Security 11N Metadata only | SDR Software/Security Inf | PDF 214.1 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 84.8 KB |
Application Information
| Application ID | pK8radRjq9e+ckTdsJ37NQ== |
|---|---|
| Final Action Date | 2016-03-25 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0012268215 |
| Model | R5ACPTMP |
| Frequency Range | 5735-5840 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Rocket 5AC PTMP |
| Responsible Party | Mark Feil, Compliance Director, compliance@ui.com  , 385-293-3532 |
| Agent | Amanda Amanda Amanda, Compliance Testing, LLC, amandar@compliancetesting.com  , 480-926-3100 |
| Test Firm | Michael Schafer, Compliance Testing, LLC, michaels@compliancetesting.com , 480-926-3100 |
| TCB Email | amandar@compliancetesting.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Class II permissive change to update power tables. Power output listed is aggregate conducted. Device operates with specific antennas for both Point-to-Point and point-to-multipoint operations and in a 2 x 2 MIMO configuration as described in this filing. This device supports 10 MHZ, 20 MHz, 30 MHz and 40MHz BW modes. The antenna(s) used with this transmitter must be professionally installed and provide a minimum of 20cm separation from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| pK8radRjq9e+ckTdsJ37NQ== | 2016-03-25 | Class II permissive change or modification of presently authorized equipment |
| sYOxBarS7rb3k6EcDUvS9g== | 2015-09-23 | Class II permissive change or modification of presently authorized equipment |
| q7M1/T0a2R02qrbUR3AVJw== | 2015-05-01 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application sYOxBarS7rb3k6EcDUvS9g==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 |
Date of Grant: 09/23/2015 Application Dated: 07/01/2015 |
| Ubiquiti Inc. |
| 685 Third Avenue |
| New York, NY 10017 |
| Attention: Mark Feil , Compliance Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SWX-R5ACPTMP |
| Name of Grantee: | Ubiquiti Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 MO | 15E | 5480.0 - 5715.0 | 0.098 |
| Class II permissive change to add DFS bands. Power output listed is aggregate conducted. Device operates with specific antennas in a Point-to-Point, 2 x 2 MIMO configuration as described in this filing. This device supports 10 MHZ, 20 MHz, 30 MHz and 40 MHz BW modes. The antenna(s) used with this transmitter must be professionally installed and provide a minimum of 20cm separation from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application sYOxBarS7rb3k6EcDUvS9g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Ubiquiti Inc. 685 Third Avenue New York, NY 10017 United States |
Date of Grant: 09/23/2015 Application Dated: 07/01/2015 |
| Attention: Mark Feil , Compliance Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SWX-R5ACPTMP |
| Name of Grantee: | Ubiquiti Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 MO | 15E | 5480.0 - 5715.0 | 0.098 |
| Class II permissive change to add DFS bands. Power output listed is aggregate conducted. Device operates with specific antennas in a Point-to-Point, 2 x 2 MIMO configuration as described in this filing. This device supports 10 MHZ, 20 MHz, 30 MHz and 40 MHz BW modes. The antenna(s) used with this transmitter must be professionally installed and provide a minimum of 20cm separation from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 |
Date of Grant: 05/01/2015 Application Dated: 05/01/2015 |
| Ubiquiti Inc. |
| 685 Third Avenue |
| New York, NY 10017 |
| Attention: Mark Feil , Compliance Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SWX-R5ACPTMP |
| Name of Grantee: | Ubiquiti Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 | 15E | 5735.0 - 5840.0 | 0.131 |
| Power output listed is aggregate conducted. Device operates with specific antennas for both Point-to-Point and point-to-multipoint operations and in a 2 x 2 MIMO configuration as described in this filing. This device supports 10 MHZ, 20 MHz, 30 MHz and 40MHz BW modes. The antenna(s) used with this transmitter must be professionally installed and provide a minimum of 20cm separation from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. MO: This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
EAS Grant - Application q7M1/T0a2R02qrbUR3AVJw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Ubiquiti Inc. 685 Third Avenue New York, NY 10017 United States |
Date of Grant: 05/01/2015 Application Dated: 05/01/2015 |
| Attention: Mark Feil , Compliance Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SWX-R5ACPTMP |
| Name of Grantee: | Ubiquiti Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 | 15E | 5735.0 - 5840.0 | 0.131 |
| Power output listed is aggregate conducted. Device operates with specific antennas for both Point-to-Point and point-to-multipoint operations and in a 2 x 2 MIMO configuration as described in this filing. This device supports 10 MHZ, 20 MHz, 30 MHz and 40MHz BW modes. The antenna(s) used with this transmitter must be professionally installed and provide a minimum of 20cm separation from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. MO: This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 |
Date of Grant: 03/25/2016 Application Dated: 03/25/2016 |
| Ubiquiti Inc. |
| 685 Third Avenue |
| New York, NY 10017 |
| Attention: Mark Feil , Compliance Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SWX-R5ACPTMP |
| Name of Grantee: | Ubiquiti Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Rocket 5AC PTMP |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15E | 5735.0 - 5840.0 | 0.131 |
| Class II permissive change to update power tables. Power output listed is aggregate conducted. Device operates with specific antennas for both Point-to-Point and point-to-multipoint operations and in a 2 x 2 MIMO configuration as described in this filing. This device supports 10 MHZ, 20 MHz, 30 MHz and 40MHz BW modes. The antenna(s) used with this transmitter must be professionally installed and provide a minimum of 20cm separation from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application pK8radRjq9e+ckTdsJ37NQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Ubiquiti Inc. 685 Third Avenue New York, NY 10017 United States |
Date of Grant: 03/25/2016 Application Dated: 03/25/2016 |
| Attention: Mark Feil , Compliance Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SWX-R5ACPTMP |
| Name of Grantee: | Ubiquiti Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Rocket 5AC PTMP |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15E | 5735.0 - 5840.0 | 0.131 |
| Class II permissive change to update power tables. Power output listed is aggregate conducted. Device operates with specific antennas for both Point-to-Point and point-to-multipoint operations and in a 2 x 2 MIMO configuration as described in this filing. This device supports 10 MHZ, 20 MHz, 30 MHz and 40MHz BW modes. The antenna(s) used with this transmitter must be professionally installed and provide a minimum of 20cm separation from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
