FCC ID SWX-R5ACPTP
Rocket 5AC PTP
by Ubiquiti Inc.
Grantee Code: SWX Product Code: R5ACPTP
Latest application date: 2016-03-25
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5735-5840 MHz | Class II permissive change or modification of presently authorized equipment | 2016-03-25 |
| 5480-5715 MHz | Class II permissive change or modification of presently authorized equipment | 2015-09-16 |
| 5735-5840 MHz | Original Equipment | 2015-04-28 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-03-25 | PDF 3.7 MB |
| Manual | Users Manual | 2015-09-16 | PDF 3.7 MB |
| Manual1 | Users Manual | 2015-06-22 | PDF 3.5 MB |
| Manual Metadata only | Users Manual | 2015-04-28 | PDF 3.5 MB |
| Internal Photos1 | Internal Photos | 2015-06-22 | PDF 633 KB |
| Internal Photos Metadata only | Internal Photos | 2015-04-28 | PDF 633 KB |
| External Photos1 | External Photos | 2015-06-22 | PDF 439.9 KB |
| External Photos Metadata only | External Photos | 2015-04-28 | PDF 439.9 KB |
| Label and Location | ID Label/Location Info | 2015-04-28 | PDF 1.5 MB |
| Test Setup Photos | Test Setup Photos | 2015-09-16 | PDF 336.6 KB |
| Test Setup Photos1 | Test Setup Photos | 2015-06-22 | PDF 336.6 KB |
| Annex A_Output Power | Test Report | 2016-03-25 | PDF 142.5 KB |
| FCC Part 1.1310 test report | Test Report | 2016-03-25 | PDF 364.3 KB |
| FCC Part 15.407 test report | Test Report | 2016-03-25 | PDF 221.9 KB |
| Annex A | Test Report | 2015-09-16 | PDF 381.8 KB |
| Annex A DFS | Test Report | 2015-09-16 | PDF 418.7 KB |
| Annex B | Test Report | 2015-09-16 | PDF 2 MB |
| Annex B DFS | Test Report | 2015-09-16 | PDF 110.7 KB |
| Annex C | Test Report | 2015-09-16 | PDF 751.2 KB |
| Annex C DFS | Test Report | 2015-09-16 | PDF 132.4 KB |
| Annex D | Test Report | 2015-09-16 | PDF 877.1 KB |
| Annex D DFS | Test Report | 2015-09-16 | PDF 254.6 KB |
| Annex E | Test Report | 2015-09-16 | PDF 91.8 KB |
| Annex F | Test Report | 2015-09-16 | PDF 202.7 KB |
| Part 15.407 | Test Report | 2015-09-16 | PDF 547.3 KB |
| Part 15.407 DFS Metadata only | Test Report | 2015-09-16 | PDF 1,019.5 KB |
| Part 15.407 DFS Rev1 | Test Report | 2015-09-16 | PDF 1,020.5 KB |
| Annex A Metadata only | Test Report | 2015-04-28 | PDF 142.3 KB |
| Annex A Rev3 | Test Report | 2015-04-28 | PDF 142.5 KB |
| Annex A_Rev1 Metadata only | Test Report | 2015-04-28 | PDF 374.8 KB |
| Annex B | Test Report | 2015-04-28 | PDF 2.6 MB |
| Annex C | Test Report | 2015-04-28 | PDF 436.2 KB |
| Annex D Metadata only | Test Report | 2015-04-28 | PDF 2.7 MB |
| Annex D_Rev1 | Test Report | 2015-04-28 | PDF 958.4 KB |
| Annex E | Test Report | 2015-04-28 | PDF 169.9 KB |
| Annex F | Test Report | 2015-04-28 | PDF 202.8 KB |
| Part 15.407 Metadata only | Test Report | 2015-04-28 | PDF 253.7 KB |
| Part 15.407_Rev1 | Test Report | 2015-04-28 | PDF 543.8 KB |
| Attestation | Attestation Statements | 2015-09-16 | PDF 90.9 KB |
| Agent Authorization Letter | Cover Letter(s) | 2016-03-25 | PDF 33.3 KB |
| Permissive Change Letter | Cover Letter(s) | 2016-03-25 | PDF 22.7 KB |
| C2PC Letter | Cover Letter(s) | 2015-09-16 | PDF 86.2 KB |
| Agent Auth | Cover Letter(s) | 2015-04-28 | PDF 33.3 KB |
| Antenna 1 | Cover Letter(s) | 2015-04-28 | PDF 841.8 KB |
| Antenna 10 | Cover Letter(s) | 2015-04-28 | PDF 1.2 MB |
| Antenna 11 | Cover Letter(s) | 2015-04-28 | PDF 4.7 MB |
| Antenna 12 | Cover Letter(s) | 2015-04-28 | PDF 1.2 MB |
| Antenna 2 | Cover Letter(s) | 2015-04-28 | PDF 3.9 MB |
| Antenna 3 | Cover Letter(s) | 2015-04-28 | PDF 3.9 MB |
| Antenna 4 | Cover Letter(s) | 2015-04-28 | PDF 4.8 MB |
| Antenna 5 | Cover Letter(s) | 2015-04-28 | PDF 4.8 MB |
| Antenna 6 | Cover Letter(s) | 2015-04-28 | PDF 4.8 MB |
| Antenna 7 | Cover Letter(s) | 2015-04-28 | PDF 4.8 MB |
| Antenna 8 | Cover Letter(s) | 2015-04-28 | PDF 3.5 MB |
| Antenna 9 | Cover Letter(s) | 2015-04-28 | PDF 3.5 MB |
| Correspondence | Cover Letter(s) | 2015-04-28 | PDF 100.7 KB |
| Long Term Confidentiality | Cover Letter(s) | 2015-04-28 | PDF 44.5 KB |
| Short Term Confidentiality | Cover Letter(s) | 2015-04-28 | PDF 47.4 KB |
| RF Exp. | RF Exposure Info | 2015-04-28 | PDF 264.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 25 KB | |
| Schematics Metadata only | Schematics | PDF 592.5 KB | |
| Theory of Op Metadata only | Operational Description | PDF 63.1 KB | |
| UNII Security 11AC Metadata only | SDR Software/Security Inf | PDF 209.7 KB | |
| UNII Security 11N Metadata only | SDR Software/Security Inf | PDF 214.1 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 82.3 KB |
Application Information
| Application ID | V3TInzBD+Nzmk4EDi9nMPA== |
|---|---|
| Final Action Date | 2016-03-25 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0012268215 |
| Model | R5ACPTP |
| Frequency Range | 5735-5840 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Rocket 5AC PTP |
| Responsible Party | Mark Feil, Compliance Director, compliance@ui.com  , 385-293-3532 |
| Agent | Amanda Amanda Amanda, Compliance Testing, LLC, 480-926-3100 |
| Test Firm | Michael Schafer, Compliance Testing, LLC, michaels@compliancetesting.com  , 480-926-3100 |
| TCB Email | amandar@compliancetesting.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Class II permissive change to update power tables. Power output listed is aggregate conducted. Device operates with specific antennas in a Point-to-Point, 2 x 2 MIMO configurations as described in this filing. This device supports 10 MHZ, 20 MHz, 30 MHz, 40 MHz, 50Hz, 60MHz and 80MHz BW modes. The antenna(s) used with this transmitter must be professionally installed and provide a minimum of 95cm separation from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| V3TInzBD+Nzmk4EDi9nMPA== | 2016-03-25 | Class II permissive change or modification of presently authorized equipment |
| SduX11Uuqq43Xqagme4NZw== | 2015-09-16 | Class II permissive change or modification of presently authorized equipment |
| j/vGm18wE2KGIxbO/JHpTQ== | 2015-04-28 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application V3TInzBD+Nzmk4EDi9nMPA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 |
Date of Grant: 03/25/2016 Application Dated: 03/25/2016 |
| Ubiquiti Inc. |
| 685 Third Avenue |
| New York, NY 10017 |
| Attention: Mark Feil , Compliance Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SWX-R5ACPTP |
| Name of Grantee: | Ubiquiti Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Rocket 5AC PTP |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15E | 5735.0 - 5840.0 | 0.398 |
| Class II permissive change to update power tables. Power output listed is aggregate conducted. Device operates with specific antennas in a Point-to-Point, 2 x 2 MIMO configurations as described in this filing. This device supports 10 MHZ, 20 MHz, 30 MHz, 40 MHz, 50Hz, 60MHz and 80MHz BW modes. The antenna(s) used with this transmitter must be professionally installed and provide a minimum of 95cm separation from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
