FCC ID SWX-RM5ACL
Access Point
by Ubiquiti Inc.
Grantee Code: SWX Product Code: RM5ACL
Latest application date: 2016-09-26
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5745-5825 MHz | Original Equipment | 2016-09-26 |
| 5745-5825 MHz | Original Equipment | 2014-04-15 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Quick Start Guide | Users Manual | 2016-09-26 | PDF 3 MB |
| User Manual | Users Manual | PDF 2.1 MB | |
| Internal Photos | Internal Photos | 2016-09-26 | PDF 898.3 KB |
| Internal Photos | Internal Photos | PDF 898.3 KB | |
| External Photos | External Photos | 2016-09-26 | PDF 800.6 KB |
| External Photos | External Photos | PDF 800.6 KB | |
| Label_Label Location | ID Label/Location Info | 2016-09-26 | PDF 129.4 KB |
| Label info | ID Label/Location Info | 2014-04-15 | PDF 496.3 KB |
| Test Setup Photos | Test Setup Photos | 2016-09-26 | PDF 1.2 MB |
| Test Photos | Test Setup Photos | PDF 1.2 MB | |
| Test Report | Test Report | 2016-09-26 | PDF 2.8 MB |
| Antenna Expiration | Cover Letter(s) | 2016-09-26 | PDF 35 KB |
| Confidentiality Request | Cover Letter(s) | 2016-09-26 | PDF 43.4 KB |
| Confidentiality Letter(Long-term) | Cover Letter(s) | 2014-04-15 | PDF 43.3 KB |
| Confidentiality Letter(Short-term) | Cover Letter(s) | 2014-04-15 | PDF 19.5 KB |
| POA | Cover Letter(s) | 2014-04-15 | PDF 18.5 KB |
| MPE | RF Exposure Info | 2016-09-26 | PDF 575 KB |
| RF Exposure | RF Exposure Info | 2014-04-15 | PDF 161 KB |
| Block Diagram Metadata only | Block Diagram | PDF 38.8 KB | |
| Block Diagram Metadata only | Block Diagram | PDF 48.1 KB | |
| Schematic Metadata only | Schematics | PDF 394.9 KB | |
| Schematic Metadata only | Schematics | PDF 476 KB | |
| Operation Description Metadata only | Operational Description | PDF 242.8 KB | |
| Theory of Operation Metadata only | Operational Description | PDF 110 KB | |
| Security Exhibit Metadata only | SDR Software/Security Inf | PDF 451.7 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 181.3 KB |
Application Information
| Application ID | PuokpXf5J6wxbxtA2cF4aQ== |
|---|---|
| Final Action Date | 2016-09-26 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0012268215 |
| Model | RM5ACL |
| Frequency Range | 5745-5825 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Access Point |
| Responsible Party | Mark Feil, Compliance Director, compliance@ui.com  , 385-293-3532 |
| Agent | Amanda Amanda Amanda, Compliance Testing, LLC, 480-926-3100 |
| Test Firm | Jim Tsai, Sporton International Inc, jimtsai@sporton.com.tw  , 88633273456 |
| TCB Email | amandar@compliancetesting.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output Power listed is the maximum combined conducted peak output power as indicated in the filing. This device must be professionally installed and operated to provide a separation distance of at least 120 cm from all persons to meet RF exposure requirements as defined for occupational/controlled exposures. End-users must be provided transmitter operating conditions for satisfying RF exposure compliance. Device is operating in a 2T2R Spatial Multiplexing MIMO configuration as described in this filing and supports 20, 40 and 80 MHz modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| PuokpXf5J6wxbxtA2cF4aQ== | 2016-09-26 | Original Equipment |
| 0ECAXE+LNEfnb+IzwvoK+w== | 2014-04-15 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application PuokpXf5J6wxbxtA2cF4aQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Compliance Testing, LLC 1724 S. Nevada Way Mesa, AZ 85204 |
Date of Grant: 09/26/2016 Application Dated: 09/26/2016 |
| Ubiquiti Inc. |
| 685 Third Avenue |
| New York, NY 10017 |
| Attention: Mark Feil , Compliance Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | SWX-RM5ACL |
| Name of Grantee: | Ubiquiti Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 48 49 MO | 15E | 5745.0 - 5825.0 | 0.9772 |
| Output Power listed is the maximum combined conducted peak output power as indicated in the filing. This device must be professionally installed and operated to provide a separation distance of at least 120 cm from all persons to meet RF exposure requirements as defined for occupational/controlled exposures. End-users must be provided transmitter operating conditions for satisfying RF exposure compliance. Device is operating in a 2T2R Spatial Multiplexing MIMO configuration as described in this filing and supports 20, 40 and 80 MHz modes. |
| 48: | The device has been approved under § 15.407(b)(4)(ii) for antenna gains greater than 10 dBi and cannot be manufactured, marketed, sold or imported after March 2, 2018. |
| 49: | The device has been approved under § 15.407(b)(4)(ii) for antenna gains of 10 dBi or less and cannot be manufactured, marketed, sold or imported after March 2, 2020. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
