FCC ID SWX-SR71
SR71
by Ubiquiti Inc.
Grantee Code: SWX Product Code: SR71
Latest application date: 2016-08-30
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5745-5825 MHz | Original Equipment | 2016-08-30 |
| 2412-2462 MHz | Original Equipment | 2008-07-17 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-08-30 | PDF 1.4 MB |
| Manual | Users Manual | 2008-07-17 | PDF 1.4 MB |
| Internal Photos | Internal Photos | 2016-08-30 | PDF 317.6 KB |
| Internal Photos | Internal Photos | 2008-07-17 | PDF 317.2 KB |
| External Photos | External Photos | 2016-08-30 | PDF 1.9 MB |
| External Photos | External Photos | 2008-07-17 | PDF 1.9 MB |
| Label_Label Location | ID Label/Location Info | 2016-08-30 | PDF 826.7 KB |
| Label | ID Label/Location Info | 2008-07-17 | PDF 823.2 KB |
| Test Setup Photos | Test Setup Photos | 2016-08-30 | PDF 415.8 KB |
| Test Photos | Test Setup Photos | 2008-07-17 | PDF 419.1 KB |
| Test Report | Test Report | 2016-08-30 | PDF 2.7 MB |
| Test Report | Test Report | 2008-07-17 | PDF 2.7 MB |
| Agent Authoization | Cover Letter(s) | 2016-08-30 | PDF 33.8 KB |
| Antenna Expiration Dates | Cover Letter(s) | 2016-08-30 | PDF 84.1 KB |
| Antenna Info | Cover Letter(s) | 2016-08-30 | PDF 1 MB |
| Confidentiality Request | Cover Letter(s) | 2016-08-30 | PDF 122 KB |
| Confidentiality | Cover Letter(s) | 2008-07-17 | PDF 134.3 KB |
| Cover Letter | Cover Letter(s) | 2008-07-17 | PDF 190.2 KB |
| Modular Approval Letter | Cover Letter(s) | 2008-07-17 | PDF 135.9 KB |
| MPE | RF Exposure Info | 2016-08-30 | PDF 85.1 KB |
| Antenna Info | RF Exposure Info | 2008-07-17 | PDF 1 MB |
| MPE Calculation | RF Exposure Info | 2008-07-17 | PDF 116.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 152.3 KB | |
| Schematics Metadata only | Schematics | PDF 1.1 MB | |
| Theory of Operation Metadata only | Operational Description | PDF 106.1 KB | |
| Security Exhibit Metadata only | SDR Software/Security Inf | PDF 456.5 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 22.4 KB |
Application Information
| Application ID | BuQBKe6SXtlTkqln7luGGA== |
|---|---|
| Final Action Date | 2016-08-30 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0012268215 |
| Model | SR71 |
| Frequency Range | 5745-5825 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | SR71 |
| Responsible Party | Mark Feil, Compliance Director, compliance@ui.com  , 385-293-3532 |
| Agent | Amanda Amanda Amanda, Compliance Testing, LLC, 480-926-3100 |
| Test Firm | Greg Kovolenko, EUROFINS ELECTRICAL AND ELECTRONIC TESTING NA, INC, greg.kovolenko@metlabs.com  , 4108444071 |
| TCB Email | amandar@compliancetesting.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Modular Approval. Power listed is the maximum combined conducted output power as indicated in the filing. Device is a PCI-E Mini Card operating in 2x2 Spatial Multiplexing/Cyclic Delay Diversity MIMO configurations as described in this filing. Approval is limited to OEM installation only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. |
