U7LITE Digital Transmission Radio Teardown... - FCC ID SWX-U7LITE

FCC ID SWX-U7LITE

Internal Photos

Digital Transmission Radio

by Ubiquiti Inc.

Document preview loads when visible.

Document Details

FCC IDSWX-U7LITE
Document ID7965835
Document TypeInternal Photos
DescriptionInternal Photos
ApplicantUbiquiti Inc.
Equipment ClassDigital Transmission Radio
Product CodeU7LITE
Application ID1/Y8NB4AGDRnZTmbcPaIog==
Application PurposeOriginal Equipment
Application Date2025-01-10
Frequency Range2412-2462 MHz
FRN0012268215
Test FirmUnified Compliance Laboratory
Certified ByAlex Macon Compliance
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date07/09/2025
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2025-01-09
Available2025-07-09
Created2025-01-04
Modified2025-01-04
Pages7
File TypeAdobe Acrobat PDF
File Size1077983
File SHA-256bbc703d2f1420a367afb65fe7bfbced6f92e857ec3bb05fe061934624d77e1ac
PDF Metadata AuthorAlex Macon
PDF Metadata ProducerMicrosoft® Word 2016 Microsoft® Word 2016
FCC.gov SourcesFCC.gov 7965835, FCC.gov 7965773
