UAPACL Access Point Test Setup Photos - FCC ID SWX-UAPACL

FCC ID SWX-UAPACL

Test setup photo

Access Point

by Ubiquiti Inc.

Document preview loads when visible.

Document Details

FCC IDSWX-UAPACL
Document ID2713107
Document TypeTest Setup Photos
DescriptionTest setup photo
Document Title1507FR24_Part 15E U-NII Test Setup Photo _15-0297_
ApplicantUbiquiti Inc.
Equipment ClassAccess Point
Product CodeUAPACL
Application IDo98V3d5EGzjTkSMwsbGRrg==
Application PurposeOriginal Equipment
Application Date2015-08-13
Frequency Range5180-5240 MHz
FRN0012268215
Test FirmA Test Lab Techno Corp.
Certified ByMichael Taylor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date09/27/2015
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2015-08-13
Available2015-09-27
Created2015-07-29
Modified2015-08-04
Pages3
File TypeAdobe Acrobat PDF
File Size413387
File SHA-2568d07d69e0e15f0e2abc662a1cf3f6c8f591eb1ff3fc9463a49c64caa0700ad12
PDF Metadata Authorpeggy.chang
PDF Metadata Producerpeggy.chang Acrobat Distiller 8.1.0 (Windows)
FCC.gov SourcesFCC.gov 2713107
