B01007 Data Collector External Photos - FCC ID SY4-B01007

FCC ID SY4-B01007

Ext Photos

Data Collector

by Shanghai Huace Navigation Technology Ltd.

Document preview loads when visible.

Document Details

FCC IDSY4-B01007
Document ID3628296
Document TypeExternal Photos
DescriptionExt Photos
Document TitleEXHIBIT B_EUT EXTERNAL PHOTOGRAPHS
ApplicantShanghai Huace Navigation Technology Ltd.
Equipment ClassData Collector
Product CodeB01007
Application ID0bAxJ79Ju8hI8u50tG9XkQ==
Application PurposeOriginal Equipment
Application Date2017-11-03
Frequency Range1850.2-1909.8 MHz
FRN0022641393
Test FirmBay Area Compliance Laboratories Corp. (Kunshan)
Certified ByZhang Dan
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2017-11-03
Available2017-11-03
Created2017-09-18
Modified2017-11-03
Pages5
File TypeAdobe Acrobat PDF
File Size316596
File SHA-256ef604ec9d75166a4dc274c75f0633b68b7a77c411914ab37ff43f3bcb4f3dded
PDF Metadata Authorbaclks37
PDF Metadata ProducerAcrobat Distiller 11.0 (Windows) baclks37
FCC.gov SourcesFCC.gov 3628296, FCC.gov 3628376, FCC.gov 3628338, FCC.gov 3628310
