FCC ID T68-FWBA
USB1 FC WiFi-BLE Adapter
by Fluke Electronics
Grantee Code: T68 Product Code: FWBA
Latest application date: 2015-10-28
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-10-28 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Installation Instructions | Users Manual | 2015-10-28 | PDF 1.1 MB |
| Logger Manual | Users Manual | 2015-10-28 | PDF 3.3 MB |
| Regulatory Information | Users Manual | 2015-10-28 | PDF 493.9 KB |
| Internal Photos | Internal Photos | 2015-10-28 | PDF 661.6 KB |
| External Photos | External Photos | 2015-10-28 | PDF 139.1 KB |
| Label and location | ID Label/Location Info | 2015-10-28 | PDF 103.5 KB |
| Antenna Description | Operational Description | 2015-10-28 | PDF 113.4 KB |
| Channel Plan | Operational Description | 2015-10-28 | PDF 283.2 KB |
| Theory of Operation | Operational Description | 2015-10-28 | PDF 395 KB |
| Test Set- Up Photos | Test Setup Photos | 2015-10-28 | PDF 460.9 KB |
| EMC Test Report | Test Report | 2015-10-28 | PDF 3.1 MB |
| Authorization Letter | Cover Letter(s) | 2015-10-28 | PDF 25.6 KB |
| BLE support confirmation | Cover Letter(s) | 2015-10-28 | PDF 91.3 KB |
| Confidentiality Request | Cover Letter(s) | 2015-10-28 | PDF 25.9 KB |
| SAR Test Exclusion Exhibit | RF Exposure Info | 2015-10-28 | PDF 795.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 37 KB | |
| Schematics Metadata only | Schematics | PDF 157.6 KB |
Application Information
| Application ID | ne/D0kuA1kM/9K24aQKO6Q== |
|---|---|
| Final Action Date | 2015-10-28 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0001567254 |
| Model | FWBA |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | USB1 FC WiFi-BLE Adapter |
| Responsible Party | James E Lenker, Test Engineer, james.lenker@fluke.com  , 4254465929 |
| Agent | Thomas Thomas Thomas, LS Research, LLC, tsmith@lsr.com  , 262-375-4400 |
| Technical Contact | Reed Nelson, Fluke Thermography, reed.nelson@fluke.com |
| Test Firm | Ryan Urness, LS Research, LLC, rurness@lsr.com , 262-375-4400 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power is conducted. This device supports 20 and 40 MHz BW modes, and is authorized for use with Fluke measurement devices, as described in the filing. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| ne/D0kuA1kM/9K24aQKO6Q== | 2015-10-28 | Original Equipment |
Grants
TCB Grant - Application ne/D0kuA1kM/9K24aQKO6Q==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 10/28/2015 Application Dated: 10/27/2015 |
| Fluke Electronics |
| 6920 Seaway Blvd |
| P.O. Box 9090, |
| Everett, WA 98203 |
| Attention: James Lenker , Test Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | T68-FWBA |
| Name of Grantee: | Fluke Electronics |
| Equipment Class: | Digital Transmission System |
| Notes: | USB1 FC WiFi-BLE Adapter |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.014 | |||
| 15C | 2402.0 - 2480.0 | 0.0013 |
| Output power is conducted. This device supports 20 and 40 MHz BW modes, and is authorized for use with Fluke measurement devices, as described in the filing. |
EAS Grant - Application ne/D0kuA1kM/9K24aQKO6Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Fluke Electronics 6920 Seaway Blvd P.O. Box 9090, Everett, WA 98203 United States |
Date of Grant: 10/28/2015 Application Dated: 10/27/2015 |
| Attention: James Lenker , Test Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | T68-FWBA |
| Name of Grantee: | Fluke Electronics |
| Equipment Class: | Digital Transmission System |
| Notes: | USB1 FC WiFi-BLE Adapter |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.014 | |||
| 15C | 2402.0 - 2480.0 | 0.0013 |
| Output power is conducted. This device supports 20 and 40 MHz BW modes, and is authorized for use with Fluke measurement devices, as described in the filing. |
