CH8050 Charger Test Setup Photos - FCC ID T7HCH8050

FCC ID T7HCH8050

Setup Photos

Desktop Charger

by RTX Hong Kong Ltd.

Document preview loads when visible.

Document Details

FCC IDT7HCH8050
Document ID2239020
Document TypeTest Setup Photos
DescriptionSetup Photos
Document TitleTest Setup Photos
ApplicantRTX Hong Kong Ltd.
Equipment ClassDesktop Charger
Product CodeCH8050
Application IDM36mVqyCz1uxbL4kKroyLg==
Application PurposeClass II Permissive Change
Application Date2014-04-10
Frequency Range5.95 MHz
FRN0017849076
Test FirmBay Area Compliance Laboratory Corp. (Shenzhen)
Certified ByTed Chong
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2014-04-10
Available2014-04-10
Created2014-04-04
Modified2014-04-04
Pages3
File TypeAdobe Acrobat PDF
File Size402296
File SHA-256f5fc86b9d85448942e5a9331faeaa8b4fc8e52c5732b7e3da9570e7d097524a7
PDF Metadata Authora
PDF Metadata ProducerAcrobat Distiller 9.0.0 (Windows) a
FCC.gov SourcesFCC.gov 2239020
