NTG6NH1 Automotive head unit FM AM DAB USB... - FCC ID T8GNTG6NH1

FCC ID T8GNTG6NH1

Label NTG6N HIGH_H1 pdf

Automotive head unit FM AM DAB USB Bluetooth WLAN and GNSS

by Harman Becker Automotive Systems

Document preview loads when visible.

Document Details

FCC IDT8GNTG6NH1
Document ID5225935
Document TypeID Label/Location Info
DescriptionLabel NTG6N HIGH_H1 pdf
ApplicantHarman Becker Automotive Systems
Equipment ClassAutomotive head unit FM AM DAB USB Bluetooth WLAN and GNSS
Product CodeNTG6NH1
Application IDNeJ2X73axguN9qsP9AmnHA==
Application PurposeOriginal Equipment
Application Date2021-04-28
Frequency Range5180-5240 MHz
FRN0014703417
Test FirmDEKRA Testing and Certification, S.A.U.
Certified ByStefan Flaschek Simon Voegele Regulatory Compliance Expert
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date10/25/2021
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2021-04-28
Available2021-04-28
Created2021-03-18
Modified2021-04-26
Pages1
File TypeAdobe Acrobat PDF
File Size306525
File SHA-25675fc9fd3b4e409da74233999bc12e22f62566397748622b71268b8a277d8903d
PDF Metadata ProducerAdobe Acrobat 15.6 Adobe Acrobat 15.6 Image Conversion Plug-in
FCC.gov SourcesFCC.gov 5225935, FCC.gov 5225890, FCC.gov 5225765
