AH001003 REMOTE CONTROL SWITCH/ CONTROL... - FCC ID T9YAH001003

FCC ID T9YAH001003

BLOCK DIAGRAM

REMOTE CONTROL SWITCH/ CONTROL SOCKET

by Tong Steng Lighting Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDT9YAH001003
Document ID682304
Document TypeBlock Diagram
DescriptionBLOCK DIAGRAM
ApplicantTong Steng Lighting Co., Ltd.
Equipment ClassREMOTE CONTROL SWITCH/ CONTROL SOCKET
Product CodeAH001003
Application ID6acSVXwJdw+0J9KXK5uP2A==
Application PurposeOriginal Equipment
Application Date2006-07-18
Frequency Range314.5-315.5 MHz
FRN0015066301
Test FirmSGS-CSTC Standards Technical Services Co.,Ltd.
Certified ByXUEDONG ZHANG MANAGER
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2006-07-18
Available2006-07-18
Created2006-05-16
Modified2006-05-23
Pages1
File TypeAdobe Acrobat PDF
File Size34015
File SHA-25614d962b595586da910a69ef1e93f74bae535c10dca1551857bf459ced3ef0835
PDF Metadata ProducerAdobe Acrobat 6.0 Paper Capture CanoScan 3200/3200F
FCC.gov SourcesFCC.gov 682304
