17506A07BT R/C SOAKER Test Setup Photos - FCC ID TB9-17506A07BT
FCC ID TB9-17506A07BT
TEST SETUP PHOTOS 1
R/C SOAKER
Document Details
| FCC ID | TB9-17506A07BT |
|---|---|
| Document ID | 738127 |
| Document Type | Test Setup Photos |
| Description | TEST SETUP PHOTOS 1 |
| Applicant | Swimways Corporation |
| Equipment Class | R/C SOAKER |
| Product Code | 17506A07BT |
| Application ID | GW70aqx4Nr+6H3KcdYv2tw== |
| Application Purpose | Original Equipment |
| Application Date | 2006-12-13 |
| Frequency Range | 49.86 MHz |
| FRN | 0013536388 |
| Test Firm | CMA Industrial Development Foundations Limited |
| Certified By | JOHN K YI |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2006-12-13 |
| Available | 2006-12-13 |
| Pages | 0 |
| File Type | JPEG Image |
| File Size | 56746 |
| File SHA-256 | 8d4f183db3c56ee69c0b59e4a2bd156987030fdbcf951563c8e04d5d0a249dc7 |
| FCC.gov Sources | FCC.gov 738127 |
