RAD03 Microwave Motion Detector Label Diagram - FCC ID TBZ-RAD03

FCC ID TBZ-RAD03

Label Location

Microwave Motion Detector

by Bircher Reglomat AG

Document preview loads when visible.

Document Details

FCC IDTBZ-RAD03
Document ID727343
Document TypeID Label/Location Info
DescriptionLabel Location
Document TitleID Label - Location Info Reflex ES
ApplicantBircher Reglomat AG
Equipment ClassMicrowave Motion Detector
Product CodeRAD03
Application IDD0aOuGEL9K9iHJMm6Mg8hA==
Application PurposeOriginal Equipment
Application Date2006-11-13
Frequency Range24125 MHz
FRN0013341888
Test FirmCTC advanced GmbH
Certified ByStephan Laeuchli Manager R+D
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2006-11-13
Available2006-11-13
Created2006-10-31
Modified2006-10-31
Pages1
File TypeAdobe Acrobat PDF
File Size312599
File SHA-256b51b7846f5eea783aa2496e2a0e7deaef1eb8aac3dfeb6bce4d998d5b836060c
PDF Metadata AuthorCosandeF01
PDF Metadata ProducerAFPL Ghostscript 8.51 FreePDF XP 3.07 - http://shbox.de
FCC.gov SourcesFCC.gov 727343
