FCC ID TC2-R1011
IP-STB
by Roku, Inc.
Grantee Code: TC2 Product Code: R1011
Latest application date: 2015-09-23
Device Images
FCC ID Device Details
| FCC ID | TC2-R1011 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | TC2 |
| Product Code | R1011 |
| Applicant Business | Roku, Inc. 🇺🇸 |
| Related Domains |  roku.com  quietek.com.cn |
| Equipment Class | IP-STB |
| Test Firm | DEKRA Testing and Certification (Suzhou) Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2015-09-23 |
| 5180-5240 MHz | Original Equipment | 2015-09-23 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| R1011-User Manual-2015-09-17 | Users Manual | 2015-09-23 | PDF 1 MB |
| 4210X&4230X-Internal Photograph | Internal Photos | 2015-09-23 | PDF 1.9 MB |
| 4210X&4230X-External Photograph | External Photos | 2015-09-23 | PDF 2 MB |
| R1011-Label & Label Location-2015-09-18 | ID Label/Location Info | 2015-09-23 | PDF 1.2 MB |
| 4210X&4230X-Test Setup Photograph | Test Setup Photos | 2015-09-23 | PDF 173.7 KB |
| 1570212R-RF-FCC-15.247(Tx)-IP-STB-V2.0-2015-09-18 | Test Report | 2015-09-23 | PDF 4.6 MB |
| 1570212R-RF-FCC-15.407_Tx_-IP-STB-V2.0-2015-09-18-1 | Test Report | 2015-09-23 | PDF 4.3 MB |
| 1570212R-RF-FCC-15.407_Tx_-IP-STB-V2.0-2015-09-18-2 Metadata only | Test Report | 2015-09-23 | PDF 3.2 MB |
| 1570212R-RF-FCC-15.407_Tx_-IP-STB-V2.0-2015-09-21-1 | Test Report | 2015-09-23 | PDF 4.3 MB |
| R1011 - FCC-Attestation-2015-09-17 | Cover Letter(s) | 2015-09-23 | PDF 65.6 KB |
| R1011 - P15B Attestation-2015-09-17 | Cover Letter(s) | 2015-09-23 | PDF 79.7 KB |
| R1011 - Cover Letter for FCC famliy certificate-2015-09-17 | Cover Letter(s) | 2015-09-23 | PDF 60.8 KB |
| R1011 - FCC Confidentiality long Term Letter-2015-09-17 | Cover Letter(s) | 2015-09-23 | PDF 55 KB |
| R1011 - FCC-Declaration of authorization-2015-09-17 | Cover Letter(s) | 2015-09-23 | PDF 75.4 KB |
| _4210X&4230X_ Cover Letter for FCC&IC LOGO Metadata only | Cover Letter(s) | 2015-09-23 | PDF 56.9 KB |
| 1570212R-RF-FCC-RF Exposure-IP-STB-V1.0-2015-09-18 | RF Exposure Info | 2015-09-23 | PDF 290.3 KB |
| Confidential_4210X&4230X-Block Diagram Metadata only | Block Diagram | PDF 245.7 KB | |
| Confidential_4210X&4230X-Schematic Diagram Metadata only | Schematics | PDF 153.1 KB | |
| Confidential_4210X&4230X-Operational Description Metadata only | Operational Description | PDF 124.7 KB | |
| Confidential_Software Security Description-2015-09-17 Metadata only | Operational Description | PDF 62.7 KB |
Application Information
| Application ID | Uo6Q0FUCDem3ATBrT4m3Cw== |
|---|---|
| Final Action Date | 2015-09-23 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0013581079 |
| Model | R1011 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | IP-STB |
| Responsible Party | Robert Curtis, Director SW Engineer, RCurtis@roku.com , 707-365-0353 |
| Agent | Dream Dream Dream, QuieTek Technology (Suzhou) Co., Ltd., dreamcao@quietek.com.cn , 0512-62515088-5108 |
| Technical Contact | Harry Zhao, QuieTek Technology (Suzhou) Co.,Ltd., harryzhao@quietek.com.cn , 86-0512-6251-5088 |
| Non-Technical Contact | Yuki Li, QuieTek Technology (Suzhou) Co.,Ltd., yukili@quietek.com.cn , 86-0512-6251-5088 |
| Test Firm | Jerry Pan, DEKRA Testing and Certification (Suzhou) Co., Ltd., jerrypan@quietek.com.cn , 86-512-62515088 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is conducted. Device is an 802.11n device in a 2x2 MIMO configuration as described in this filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This devcie has a 20 MHz and 40 MHz bandwidth mode. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| Uo6Q0FUCDem3ATBrT4m3Cw== | 2015-09-23 | Original Equipment |
| C9gBD0JpSr6moZvOc4uA8g== | 2015-09-23 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application Uo6Q0FUCDem3ATBrT4m3Cw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 09/23/2015 Application Dated: 09/22/2015 |
| Roku, Inc. |
| 1155 Coleman Ave |
| San Jose, CA 95110 |
| Attention: Robert Curtis , Director SW Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TC2-R1011 |
| Name of Grantee: | Roku, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | IP-STB |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.49317 |
| Power Output listed is conducted. Device is an 802.11n device in a 2x2 MIMO configuration as described in this filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This devcie has a 20 MHz and 40 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application Uo6Q0FUCDem3ATBrT4m3Cw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Roku, Inc. 1155 Coleman Ave San Jose, CA 95110 United States |
Date of Grant: 09/23/2015 Application Dated: 09/22/2015 |
| Attention: Robert Curtis , Director SW Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TC2-R1011 |
| Name of Grantee: | Roku, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | IP-STB |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.49317 |
| Power Output listed is conducted. Device is an 802.11n device in a 2x2 MIMO configuration as described in this filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This devcie has a 20 MHz and 40 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 09/23/2015 Application Dated: 09/22/2015 |
| Roku, Inc. |
| 1155 Coleman Ave |
| San Jose, CA 95110 |
| Attention: Robert Curtis , Director SW Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TC2-R1011 |
| Name of Grantee: | Roku, Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | IP-STB |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15E | 5745.0 - 5825.0 | 0.04699 | ||
| CC | 15E | 5180.0 - 5240.0 | 0.04467 |
| Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This devcie has a 20 MHz and 40 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application C9gBD0JpSr6moZvOc4uA8g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Roku, Inc. 1155 Coleman Ave San Jose, CA 95110 United States |
Date of Grant: 09/23/2015 Application Dated: 09/22/2015 |
| Attention: Robert Curtis , Director SW Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TC2-R1011 |
| Name of Grantee: | Roku, Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | IP-STB |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15E | 5745.0 - 5825.0 | 0.04699 | ||
| CC | 15E | 5180.0 - 5240.0 | 0.04467 |
| Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This devcie has a 20 MHz and 40 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: |
