FCC ID TE7C2V3
Digital Transmission System/ Unlicensed National Information Infrastructure TX
by TP-Link Technologies Co., Ltd.
Grantee Code: TE7 Product Code: C2V3
Latest application date: 2016-10-20
Device Images
FCC ID Device Details
| FCC ID | TE7C2V3 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | TE7 |
| Product Code | C2V3 |
| Applicant Business | TP-Link Technologies Co., Ltd. 🇨🇳 |
| Related Domains |  tp-link.com  atl-lab.com.tw |
| Equipment Class | Digital Transmission System/ Unlicensed National Information Infrastructure TX |
| Test Firm | A Test Lab Techno Corp. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-10-20 |
| 5180-5240 MHz | Original Equipment | 2016-10-20 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Archer C2_User ManualRev | Users Manual | 2016-10-20 | PDF 4.4 MB |
| 12_Internal Photos | Internal Photos | 2016-10-20 | PDF 452.3 KB |
| 11_External Photos | External Photos | 2016-10-20 | PDF 309 KB |
| 04_ID Label Artwork & Label Location_R01 | ID Label/Location Info | 2016-10-20 | PDF 46.6 KB |
| 1609FR11-01_Part 15C Test Setup Photo (16-0683) | Test Setup Photos | 2016-10-20 | PDF 864 KB |
| 1609FR12_P15E Test Setup Photo (16-0683) | Test Setup Photos | 2016-10-20 | PDF 627.9 KB |
| 1609FR11-01_P15C (16-0683)Part 1 Metadata only | Test Report | 2016-10-20 | PDF 3 MB |
| 1609FR11-01_P15C (16-0683)Part 1v1 | Test Report | 2016-10-20 | PDF 3 MB |
| 1609FR11-01_P15C (16-0683)Part 1v2 | Test Report | 2016-10-20 | PDF 3.1 MB |
| 1609FR11-01_P15C (16-0683)Part 2 Metadata only | Test Report | 2016-10-20 | PDF 3.1 MB |
| 1609FR11-01_P15C (16-0683)_Part 1 | Test Report | 2016-10-20 | PDF 3 MB |
| 1609FR11-01_P15C (16-0683)_Part 2 | Test Report | 2016-10-20 | PDF 3.1 MB |
| 1609FR12_P15E BI & BIII (16-0683) | Test Report | 2016-10-20 | PDF 1.3 MB |
| Archer C2_Ad-hoc Mode Letter for all WLAN & DFS master devices | Cover Letter(s) | 2016-10-20 | PDF 98.9 KB |
| Archer C2_FCC DoC letter | Cover Letter(s) | 2016-10-20 | PDF 122.9 KB |
| Archer C2_FCC confidentiality Request Letter | Cover Letter(s) | 2016-10-20 | PDF 84.7 KB |
| Archer C2_POA_FCC | Cover Letter(s) | 2016-10-20 | PDF 86.5 KB |
| FCC Supersede Request Letter_rev.01 | Cover Letter(s) | 2016-10-20 | PDF 87.9 KB |
| 1609FS13_IEEE C95.1 MPE (16-0683) | RF Exposure Info | 2016-10-20 | PDF 127 KB |
| Confidential_Archer C2_Block Diagram Metadata only | Block Diagram | PDF 55.1 KB | |
| Confidential_Archer C2_Schematics Metadata only | Schematics | PDF 512.7 KB | |
| Archer C2_Operational DescriptionRev7 Metadata only | Operational Description | PDF 101.4 KB | |
| Confidential_Archer C2_Operational DescriptionRev4 Metadata only | Operational Description | PDF 99.7 KB | |
| Confidential_Archer C2_Software Security for U-NII Devices Metadata only | Operational Description | PDF 105.2 KB |
Application Information
| Application ID | vGOK2JaLcSm7365Oq9gzRQ== |
|---|---|
| Final Action Date | 2016-10-20 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0013661145 |
| Model | C2V3 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Digital Transmission System/ Unlicensed National Information Infrastructure TX |
| Responsible Party | Jing Huang, Regulatory Compliance Manager, certification@tp-link.com , 75521534921 |
| Technical Contact | Kevin TSAI, A Test Lab Techno Corp, Kevin@atl-lab.com.tw , 886-3-2710188 |
| Non-Technical Contact | Joyce Liao, A Test Lab Techno Corp, Joyce@atl-lab.com.tw , 886-3-2710188 |
| Test Firm | Fly LU, A Test Lab Techno Corp., fly@atl-lab.com.tw , 886-3-2710188 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is conducted. Device is an 802.11 a/b/g/n/ac device in a 3x3 Spatial Multiplexing MIMO configuration, enabled for either 2.4 or 5 GHz band of operations as described in this filing. Power out of the device at the lower and higher channels of 802.11b/g/n in 2.4G band are reduced for band edge compliance reasons. The device has been certified for mobile use and any co-location must be done through the use of FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40MHz bandwidth modes. |
