FCC ID TE7EAP115
300Mbps Wireless N Ceiling Mount Acess Point
by TP-Link Technologies Co., Ltd.
Grantee Code: TE7 Product Code: EAP115
Latest application date: 2016-09-19
Device Images
FCC ID Device Details
| FCC ID | TE7EAP115 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | TE7 |
| Product Code | EAP115 |
| Applicant Business | TP-Link Technologies Co., Ltd. 🇨🇳 |
| Related Domains |  tp-link.com  cn.bureauveritas.com |
| Equipment Class | 300Mbps Wireless N Ceiling Mount Acess Point |
| Test Firm | Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-09-19 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| TE7EAP115_User Guide | Users Manual | 2016-09-19 | PDF 2.4 MB |
| TE7EAP115_internal Photos | Internal Photos | 2016-09-19 | PDF 405.2 KB |
| TE7EAP115_External Photos | External Photos | 2016-09-19 | PDF 330.7 KB |
| TE7EAP115_ID label and Location | ID Label/Location Info | 2016-09-19 | PDF 1 MB |
| TE7EAP115_Test photos | Test Setup Photos | 2016-09-19 | PDF 496 KB |
| TE7EAP115_FCC 15.247_WIFI report | Test Report | 2016-09-19 | PDF 1.2 MB |
| TE7EAP115_FCC DoC letter(BV) | Cover Letter(s) | 2016-09-19 | PDF 279.6 KB |
| TE7EAP115_FCC confidentiality Request Letter | Cover Letter(s) | 2016-09-19 | PDF 81.9 KB |
| TE7EAP115_POA_FCC(BV) | Cover Letter(s) | 2016-09-19 | PDF 275.5 KB |
| TE7EAP115_FCC MPE Report | RF Exposure Info | 2016-09-19 | PDF 164.8 KB |
| TE7EAP115_Block Diagram Metadata only | Block Diagram | PDF 144.9 KB | |
| TE7EAP115_Schematics Metadata only | Schematics | PDF 599.3 KB | |
| EAP115_Operational Description_Rev 1 Metadata only | Operational Description | PDF 369.4 KB |
Application Information
| Application ID | UUhF7jyKVC2Me6gkeSR1lg== |
|---|---|
| Final Action Date | 2016-09-19 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0013661145 |
| Model | EAP115 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | 300Mbps Wireless N Ceiling Mount Acess Point |
| Responsible Party | Jing Huang, Regulatory Compliance Manager, certification@tp-link.com , 75521534921 |
| Agent | Bureau Veritas Shenzhen Co., Ltd., Dongguan Branch |
| Technical Contact | Sam Tung, Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch, sam.tung@cn.bureauveritas.com , 86-769-85935656 |
| Non-Technical Contact | Rita Li, Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch, Rita.Li@cn.bureauveritas.com , 86-769-85935656 |
| Test Firm | Alec Hu, Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch, alec.hu@cn.bureauveritas.com , 86-769-85935656 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is conducted. Device is an 802.11n device in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz and 40 MHz Bandwidths. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| UUhF7jyKVC2Me6gkeSR1lg== | 2016-09-19 | Original Equipment |
Grants
TCB Grant - Application UUhF7jyKVC2Me6gkeSR1lg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 09/19/2016 Application Dated: 09/14/2016 |
| TP-Link Technologies Co., Ltd. |
| Building 24 (floors 1,3,4,5) and 28 (floors1-4), |
| Central Science and Technology Park,Nanshan |
| Shenzhen, 518057 China |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7EAP115 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | 300Mbps Wireless N Ceiling Mount Acess Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.631008 |
| Power Output listed is conducted. Device is an 802.11n device in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz and 40 MHz Bandwidths. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application UUhF7jyKVC2Me6gkeSR1lg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TP-Link Technologies Co., Ltd. Building 24 (floors 1,3,4,5) and 28 (floors1-4), Central Science and Technology Park,Nanshan Shenzhen, 518057 China |
Date of Grant: 09/19/2016 Application Dated: 09/14/2016 |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7EAP115 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | 300Mbps Wireless N Ceiling Mount Acess Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.631008 |
| Power Output listed is conducted. Device is an 802.11n device in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 MHz and 40 MHz Bandwidths. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
