EAP225OD AC1200 Wireless MU-MIMO Gigabit... - FCC ID TE7EAP225OD

FCC ID TE7EAP225OD

5. Test Report_WLAN 5G R01

AC1200 Wireless MU-MIMO Gigabit Indoor/Outdoor Access Point

by TP-Link Technologies Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDTE7EAP225OD
Document ID5864361
Document TypeTest Report
Description5. Test Report_WLAN 5G R01
Document TitleMeasurement Report
ApplicantTP-Link Technologies Co., Ltd.
Equipment ClassAC1200 Wireless MU-MIMO Gigabit Indoor/Outdoor Access Point
Product CodeEAP225OD
Application IDbgOcALirnNl6N6reSNL4vQ==
Application PurposeClass II Permissive Change
Application Date2022-05-08
Frequency Range5180-5240 MHz
FRN0013661145
Test FirmBTL Inc.
Certified ByRose Liu Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2022-05-07
Available2022-05-08
Created2022-05-07
Modified2022-05-07
Pages51
File TypeAdobe Acrobat PDF
File Size1998301
File SHA-256a8429c4724ccdc5386be0832da92cdf816e7ed2fea3db1eaf2e49dda5c247109
PDF Metadata AuthorTT Microsoft
PDF Metadata ProducerTT Adobe PDF Library 19.12.66
FCC.gov SourcesFCC.gov 5864361
