FCC ID TE7EAP330
AC1900 Wireless Dual Band Gigabit Access Point
by TP-Link Technologies Co., Ltd.
Grantee Code: TE7 Product Code: EAP330
Latest application date: 2016-09-13
Device Images
FCC ID Device Details
| FCC ID | TE7EAP330 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | TE7 |
| Product Code | EAP330 |
| Applicant Business | TP-Link Technologies Co., Ltd. 🇨🇳 |
| Related Domains |  tp-link.com |
| Equipment Class | AC1900 Wireless Dual Band Gigabit Access Point |
| Test Firm | SPORTON International(KunShan) Inc |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Class II permissive change or modification of presently authorized equipment | 2016-09-13 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-09-13 |
| 5180-5240 MHz | Original Equipment | 2016-07-12 |
| 2412-2462 MHz | Original Equipment | 2016-07-12 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-07-12 | PDF 1.9 MB |
| Internal Photos | Internal Photos | 2016-07-12 | PDF 3.6 MB |
| External Photos | External Photos | 2016-07-12 | PDF 881.9 KB |
| Label | ID Label/Location Info | 2016-07-12 | PDF 952.4 KB |
| Label Location | ID Label/Location Info | 2016-07-12 | PDF 31.7 KB |
| Test Setup Photos DTS | Test Setup Photos | 2016-09-13 | PDF 204.5 KB |
| Test Setup Photos NII 5G B1 | Test Setup Photos | 2016-09-13 | PDF 205.1 KB |
| Test Setup Photos NII 5G B4 | Test Setup Photos | 2016-09-13 | PDF 204.9 KB |
| Test Setup Photos 5G Band 1 | Test Setup Photos | 2016-07-12 | PDF 269.9 KB |
| Test Setup Photos DTS | Test Setup Photos | 2016-07-12 | PDF 278.6 KB |
| Test Setup Photosn 5G Band 4 | Test Setup Photos | 2016-07-12 | PDF 269.7 KB |
| Test Report DTS | Test Report | 2016-09-13 | PDF 1,011.4 KB |
| Test Report NII 5G B1 | Test Report | 2016-09-13 | PDF 975.3 KB |
| Test Report NII 5G B4 | Test Report | 2016-09-13 | PDF 1,009.9 KB |
| Test Report DTS | Test Report | 2016-07-12 | PDF 5.8 MB |
| Test Report MPE | RF Exposure Info | 2016-07-12 | PDF 240.2 KB |
| Test Report NII 5G Band 1 | Test Report | 2016-07-12 | PDF 1.2 MB |
| Test Report NII 5G Band 4 | Test Report | 2016-07-12 | PDF 1.2 MB |
| Class II Permissive Change Letter | Cover Letter(s) | 2016-09-13 | PDF 74.9 KB |
| Declaration Letter | Cover Letter(s) | 2016-09-13 | PDF 68 KB |
| POA | Cover Letter(s) | 2016-09-13 | PDF 79.6 KB |
| 5GHz Declaration Letter | Cover Letter(s) | 2016-07-12 | PDF 83.9 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-07-12 | PDF 66.3 KB |
| Cover Letter | Cover Letter(s) | 2016-07-12 | PDF 87.1 KB |
| DOC Letter | Cover Letter(s) | 2016-07-12 | PDF 69.4 KB |
| Declaration Letter 5GHz | Cover Letter(s) | 2016-07-12 | PDF 83.9 KB |
| Declaration Letter for WiFi Channel | Cover Letter(s) | 2016-07-12 | PDF 69.5 KB |
| Declaration letter for WiFi Channel | Cover Letter(s) | 2016-07-12 | PDF 69.5 KB |
| POA | Cover Letter(s) | 2016-07-12 | PDF 75.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 41.7 KB | |
| Schematics Diagram Metadata only | Schematics | PDF 1.1 MB | |
| Operational Description Metadata only | Operational Description | PDF 215.6 KB | |
| Operational Description Software Security Metadata only | SDR Software/Security Inf | PDF 68.8 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 71.9 KB |
Application Information
| Application ID | wLeQjI3ZOC4DteloPJe2Zg== |
|---|---|
| Final Action Date | 2016-09-13 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0013661145 |
| Model | EAP330 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | AC1900 Wireless Dual Band Gigabit Access Point |
| Responsible Party | Jing Huang, Regulatory Compliance Manager, certification@tp-link.com , 75521534921 |
| Test Firm | Michael Lin, SPORTON International(KunShan) Inc, Michael@sporton.com.tw  , 86-512-57900158 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is maximum combined output power conducted. This device is restricted to indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 46 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 and 40 MHz bandwidth modes. Class II Permissive Change |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| wLeQjI3ZOC4DteloPJe2Zg== | 2016-09-13 | Class II permissive change or modification of presently authorized equipment |
| EKZhOGeX6Ivvr9fE/vhY3w== | 2016-09-13 | Class II permissive change or modification of presently authorized equipment |
| dSaFwB8TAOnNUK2BdlAg3w== | 2016-07-12 | Original Equipment |
| 7+lYzzmDdoVyCtYqno438Q== | 2016-07-12 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application wLeQjI3ZOC4DteloPJe2Zg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 09/13/2016 Application Dated: 09/09/2016 |
| TP-Link Technologies Co., Ltd. |
| Building 24 (floors 1,3,4,5) and 28 (floors1-4), |
| Central Science and Technology Park,Nanshan |
| Shenzhen, 518057 China |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7EAP330 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | AC1900 Wireless Dual Band Gigabit Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.7244 |
| Power listed is maximum combined output power conducted. This device is restricted to indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 46 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 and 40 MHz bandwidth modes. Class II Permissive Change |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application wLeQjI3ZOC4DteloPJe2Zg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TP-Link Technologies Co., Ltd. Building 24 (floors 1,3,4,5) and 28 (floors1-4), Central Science and Technology Park,Nanshan Shenzhen, 518057 China |
Date of Grant: 09/13/2016 Application Dated: 09/09/2016 |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7EAP330 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | AC1900 Wireless Dual Band Gigabit Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.7244 |
| Power listed is maximum combined output power conducted. This device is restricted to indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 46 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 and 40 MHz bandwidth modes. Class II Permissive Change |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 09/13/2016 Application Dated: 09/09/2016 |
| TP-Link Technologies Co., Ltd. |
| Building 24 (floors 1,3,4,5) and 28 (floors1-4), |
| Central Science and Technology Park,Nanshan |
| Shenzhen, 518057 China |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7EAP330 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | AC1900 Wireless Dual Band Gigabit Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.271 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.7499 |
| Power listed is maximum combined output power conducted. This device is restricted to indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 46 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20, 40, and 80 MHz bandwidth modes. Class II Permissive Change |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application EKZhOGeX6Ivvr9fE/vhY3w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TP-Link Technologies Co., Ltd. Building 24 (floors 1,3,4,5) and 28 (floors1-4), Central Science and Technology Park,Nanshan Shenzhen, 518057 China |
Date of Grant: 09/13/2016 Application Dated: 09/09/2016 |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7EAP330 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | AC1900 Wireless Dual Band Gigabit Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.271 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.7499 |
| Power listed is maximum combined output power conducted. This device is restricted to indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 46 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20, 40, and 80 MHz bandwidth modes. Class II Permissive Change |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 07/12/2016 Application Dated: 07/11/2016 |
| TP-Link Technologies Co., Ltd. |
| Building 24 (floors 1,3,4,5) and 28 (floors1-4), |
| Central Science and Technology Park,Nanshan |
| Shenzhen, 518057 China |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7EAP330 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | AC1900 Wireless Dual Band Gigabit Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.271 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.7499 |
| Power listed is maximum combined output power conducted. This device is restricted to indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 46 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20, 40, and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application dSaFwB8TAOnNUK2BdlAg3w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TP-Link Technologies Co., Ltd. Building 24 (floors 1,3,4,5) and 28 (floors1-4), Central Science and Technology Park,Nanshan Shenzhen, 518057 China |
Date of Grant: 07/12/2016 Application Dated: 07/11/2016 |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7EAP330 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | AC1900 Wireless Dual Band Gigabit Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.271 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.7499 |
| Power listed is maximum combined output power conducted. This device is restricted to indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 46 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20, 40, and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 07/12/2016 Application Dated: 07/11/2016 |
| TP-Link Technologies Co., Ltd. |
| Building 24 (floors 1,3,4,5) and 28 (floors1-4), |
| Central Science and Technology Park,Nanshan |
| Shenzhen, 518057 China |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7EAP330 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | AC1900 Wireless Dual Band Gigabit Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.7244 |
| Power listed is maximum combined output power conducted. This device is restricted to indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 46 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 and 40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 7+lYzzmDdoVyCtYqno438Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TP-Link Technologies Co., Ltd. Building 24 (floors 1,3,4,5) and 28 (floors1-4), Central Science and Technology Park,Nanshan Shenzhen, 518057 China |
Date of Grant: 07/12/2016 Application Dated: 07/11/2016 |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7EAP330 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | AC1900 Wireless Dual Band Gigabit Access Point |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.7244 |
| Power listed is maximum combined output power conducted. This device is restricted to indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 46 cm from all persons and must not transmit simultaneously with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20 and 40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
