FCC ID TE7WBS510
5GHz 300Mbps Outdoor Wireless Base Station
by TP-Link Technologies Co., Ltd.
Grantee Code: TE7 Product Code: WBS510
Latest application date: 2016-07-30
Device Images
FCC ID Device Details
| FCC ID | TE7WBS510 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | TE7 |
| Product Code | WBS510 |
| Applicant Business | TP-Link Technologies Co., Ltd. 🇨🇳 |
| Related Domains |  tp-link.com |
| Equipment Class | 5GHz 300Mbps Outdoor Wireless Base Station |
| Test Firm | DEKRA Testing and Certification (Suzhou) Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-07-30 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| WBS510-User Manual-1 | Users Manual | 2016-07-30 | PDF 2.7 MB |
| WBS510-User Manual-2 | Users Manual | 2016-07-30 | PDF 3.7 MB |
| 1632114R-Internal Photograph-2016-07-21 | Internal Photos | 2016-07-30 | PDF 177.9 KB |
| 1632114R-External Photograph-2016-07-27 | External Photos | 2016-07-30 | PDF 922.4 KB |
| WBS510-Label Location | ID Label/Location Info | 2016-07-30 | PDF 802.1 KB |
| WBS510-Test Setup Photographs | Test Setup Photos | 2016-07-30 | PDF 509.2 KB |
| 1632114R-RF-FCC-FCC 15.407-WBS510-V3.2-Part1-2016-07-27 | Test Report | 2016-07-30 | PDF 3.4 MB |
| 1632114R-RF-FCC-FCC 15.407-WBS510-V3.2-Part2-2016-07-27 | Test Report | 2016-07-30 | PDF 5 MB |
| 1632114R-RF-FCC-FCC 15.407-WBS510-V3.3-Part1-2016-08-30 | Test Report | 2016-07-30 | PDF 5.5 MB |
| 1632114R-RF-FCC-FCC 15.407-WBS510-V3.3-Part2-2016-08-30 | Test Report | 2016-07-30 | PDF 3 MB |
| WBS510-Attestation | Cover Letter(s) | 2016-07-30 | PDF 65.5 KB |
| WBS510-Declaration of authorization | Cover Letter(s) | 2016-07-30 | PDF 78 KB |
| WBS510-FCC Confidentiality long Term Letter | Cover Letter(s) | 2016-07-30 | PDF 57.8 KB |
| WBS510-cover latter for professional Installation | Cover Letter(s) | 2016-07-30 | PDF 74 KB |
| 1632114R-RF-FCC Exposure -WBS510-V1.2-2016-07-27 | RF Exposure Info | 2016-07-30 | PDF 172.4 KB |
| WBS510-Block Diagram Metadata only | Block Diagram | PDF 113.3 KB | |
| Confidential_WBS510-Schematic Diagram Metadata only | Schematics | PDF 321.4 KB | |
| WBS510-Operational Description-2016-07-21 Metadata only | Operational Description | PDF 98.6 KB | |
| WBS510-Software Operating Description-2016-07-21 Metadata only | Operational Description | PDF 155 KB |
Application Information
| Application ID | HOQWP4CPEtrBcm3ZXK9VnA== |
|---|---|
| Final Action Date | 2016-07-30 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0013661145 |
| Model | WBS510 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | 5GHz 300Mbps Outdoor Wireless Base Station |
| Responsible Party | Jing Huang, Regulatory Compliance Manager, certification@tp-link.com , 75521534921 |
| Technical Contact | Harry Zhao, QuieTek Technology (Suzhou) Co.,Ltd., harryzhao@quietek.com.cn  |
| Test Firm | Jerry Pan, DEKRA Testing and Certification (Suzhou) Co., Ltd., jerrypan@quietek.com.cn , 86-512-62515088 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is conducted. Device is an 802.11n device in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. This device must be professionally installed. Installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Antenna Installation - The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter not described in this application. This device was certified along with 2 different antenna types and each type of the antenna has its own power value, as documented in this filing. This device has a 10 MHz, 20 MHz and 40 MHz bandwidth mode. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| HOQWP4CPEtrBcm3ZXK9VnA== | 2016-07-30 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application HOQWP4CPEtrBcm3ZXK9VnA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 07/30/2016 Application Dated: 07/28/2016 |
| TP-Link Technologies Co., Ltd. |
| Building 24 (floors 1,3,4,5) and 28 (floors1-4), |
| Central Science and Technology Park,Nanshan |
| Shenzhen, 518057 China |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7WBS510 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 5GHz 300Mbps Outdoor Wireless Base Station |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 MO | 15E | 5180.0 - 5240.0 | 0.51523 | ||
| 38 MO | 15E | 5745.0 - 5825.0 | 0.30761 | ||
| 38 MO | 15E | 5180.0 - 5240.0 | 0.02291 | ||
| 38 MO | 15E | 5745.0 - 5825.0 | 0.03724 |
| Power Output listed is conducted. Device is an 802.11n device in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. This device must be professionally installed. Installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. Antenna Installation - The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter not described in this application. This device was certified along with 2 different antenna types and each type of the antenna has its own power value, as documented in this filing. This device has a 10 MHz, 20 MHz and 40 MHz bandwidth mode. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
