FCC ID TE7WR841HPV5
300Mbps High Power Wireless N Router
by TP-Link Technologies Co., Ltd.
Grantee Code: TE7 Product Code: WR841HPV5
Latest application date: 2017-03-30
Device Images
FCC ID Device Details
| FCC ID | TE7WR841HPV5 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | TE7 |
| Product Code | WR841HPV5 |
| Applicant Business | TP-Link Technologies Co., Ltd. 🇨🇳 |
| Related Domains |  tp-link.com |
| Equipment Class | 300Mbps High Power Wireless N Router |
| Test Firm | Sporton International Inc |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2017-03-30 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| TE7WR841HPV5_TL-WR841HP_User manual | Users Manual | 2017-03-30 | PDF 5.6 MB |
| TE7WR841HPV5_TL-WR841HP_Internal photo | Internal Photos | 2017-03-30 | PDF 703.9 KB |
| TE7WR841HPV5_TL-WR841HP_External photo | External Photos | 2017-03-30 | PDF 536.8 KB |
| TE7WR841HPV5_TL-WR841HP_Label and location | ID Label/Location Info | 2017-03-30 | PDF 78.3 KB |
| TE7WR841HPV5_TL-WR841HP_TEST PHOTOS | Test Setup Photos | 2017-03-30 | PDF 233 KB |
| TE7WR841HPV5_TL-WR841HP_MPE Test Report | RF Exposure Info | 2017-03-30 | PDF 227.9 KB |
| TE7WR841HPV5_TL-WR841HP_RF Test Report | Test Report | 2017-03-30 | PDF 1.6 MB |
| TE7WR841HPV5_TL-WR841HP_Confidential letter | Cover Letter(s) | 2017-03-30 | PDF 46.7 KB |
| TE7WR841HPV5_TL-WR841HP_DOC letter | Cover Letter(s) | 2017-03-30 | PDF 20.7 KB |
| TE7WR841HPV5_TL-WR841HP_POA | Cover Letter(s) | 2017-03-30 | PDF 20.8 KB |
| Confidential_TE7WR841HPV5_TL-WR841HP_Block Diagram Metadata only | Block Diagram | PDF 91.9 KB | |
| Confidential_TE7WR841HPV5_TL-WR841HP_SCH Metadata only | Schematics | PDF 268.9 KB | |
| Confidential_TE7WR841HPV5_TL-WR841HP_Operating description_Rev.02 Metadata only | Operational Description | PDF 220.1 KB |
Application Information
| Application ID | dWAkIGrqghi8Iw4Rss3Vng== |
|---|---|
| Final Action Date | 2017-03-30 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0013661145 |
| Model | WR841HPV5 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | 300Mbps High Power Wireless N Router |
| Responsible Party | Jing Huang, Regulatory Compliance Manager, certification@tp-link.com , 75521534921 |
| Technical Contact | Elsa Lin, Sporton International Inc., elsalin@sporton.com.tw  , 886-3-656-9065 |
| Test Firm | Jim Tsai, Sporton International Inc, jimtsai@sporton.com.tw , 88633273456 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is conducted. Device is an 802.11b/g/n device in a 2x2 MIMO configuration as described in this filing. The device has been certified for mobile use and any co-location must be done through the use of FCC multitransmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20MHz and 40MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| dWAkIGrqghi8Iw4Rss3Vng== | 2017-03-30 | Original Equipment |
Grants
TCB Grant - Application dWAkIGrqghi8Iw4Rss3Vng==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 03/30/2017 Application Dated: 03/30/2017 |
| TP-Link Technologies Co., Ltd. |
| Building 24 (floors 1,3,4,5) and 28 (floors1-4), |
| Central Science and Technology Park,Nanshan |
| Shenzhen, 518057 China |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7WR841HPV5 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | 300Mbps High Power Wireless N Router |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.2399 |
| Power Output listed is conducted. Device is an 802.11b/g/n device in a 2x2 MIMO configuration as described in this filing. The device has been certified for mobile use and any co-location must be done through the use of FCC multitransmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20MHz and 40MHz bandwidth modes. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application dWAkIGrqghi8Iw4Rss3Vng==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TP-Link Technologies Co., Ltd. Building 24 (floors 1,3,4,5) and 28 (floors1-4), Central Science and Technology Park,Nanshan Shenzhen, 518057 China |
Date of Grant: 03/30/2017 Application Dated: 03/30/2017 |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7WR841HPV5 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | 300Mbps High Power Wireless N Router |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.2399 |
| Power Output listed is conducted. Device is an 802.11b/g/n device in a 2x2 MIMO configuration as described in this filing. The device has been certified for mobile use and any co-location must be done through the use of FCC multitransmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20MHz and 40MHz bandwidth modes. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
