FCC ID TE7WR940NV4
450Mbps Wireless N Router
by TP-Link Technologies Co., Ltd.
Grantee Code: TE7 Product Code: WR940NV4
Latest application date: 2016-10-26
Device Images
FCC ID Device Details
| FCC ID | TE7WR940NV4 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | TE7 |
| Product Code | WR940NV4 |
| Applicant Business | TP-Link Technologies Co., Ltd. 🇨🇳 |
| Related Domains |  tp-link.com  quietek.com.cn |
| Equipment Class | 450Mbps Wireless N Router |
| Test Firm | DEKRA Testing and Certification (Suzhou) Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-10-26 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| TL-WR940N-User Manual | Users Manual | 2016-10-26 | PDF 4.7 MB |
| TL-WR940N-Internal Photograph | Internal Photos | 2016-10-26 | PDF 217.1 KB |
| TL-WR940N-External Photograph | External Photos | 2016-10-26 | PDF 357.9 KB |
| TL-WR940N-Label Location | ID Label/Location Info | 2016-10-26 | PDF 2.3 MB |
| TL-WR940N-FCC-Test Setup Photographs | Test Setup Photos | 2016-10-26 | PDF 141.2 KB |
| 1672003R-RF-FCC-FCC Part15.247-450Mbps Wireless N Router-TL-WR940N-V1.3-2016-10- | Test Report | 2016-10-26 | PDF 2.8 MB |
| TL-WR940N-DoC Attestation | Cover Letter(s) | 2016-10-26 | PDF 49.1 KB |
| TL-WR940N-Ad-hoc Letter | Cover Letter(s) | 2016-10-26 | PDF 288.2 KB |
| TL-WR940N-Declaration of authorization | Cover Letter(s) | 2016-10-26 | PDF 123.5 KB |
| TL-WR940N-FCC Confidentiality long Term Letter | Cover Letter(s) | 2016-10-26 | PDF 164.8 KB |
| TL-WR940N-FCC Cover Letter-2016-09-22 | Cover Letter(s) | 2016-10-26 | PDF 108.7 KB |
| 1672003R-FCC statement for MPE not required-450Mbps Wireless N Router-TL-WR940N- | RF Exposure Info | 2016-10-26 | PDF 117.6 KB |
| Confidential_TL-WR940N-Block Diagram Metadata only | Block Diagram | PDF 99 KB | |
| Confidential_TL-WR940N-Schematic Diagram Metadata only | Schematics | PDF 315.7 KB | |
| Confidential_TL-WR810N-Operational Description-2016-10-20 Metadata only | Operational Description | PDF 75.9 KB | |
| Confidential_TL-WR940-Operational Description-2016-10-20 Metadata only | Operational Description | PDF 315.3 KB | |
| Confidential_TL-WR940-Operational Description-2016-10-26 Metadata only | Operational Description | PDF 362.8 KB |
Application Information
| Application ID | FRUXsxfM91HaMKuUow0mPA== |
|---|---|
| Final Action Date | 2016-10-26 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0013661145 |
| Model | WR940NV4 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | 450Mbps Wireless N Router |
| Responsible Party | Jing Huang, Regulatory Compliance Manager, certification@tp-link.com , 75521534921 |
| Agent | Harry Harry Harry, QuieTek Technology (Suzhou) Co., Ltd., harryzhao@quietek.com.cn , 0512-62515088-5160 |
| Technical Contact | Harry Zhao, QuieTek Technology (Suzhou) Co.,Ltd., harryzhao@quietek.com.cn , 86-0512-6251-5088 |
| Non-Technical Contact | Yuki Li, QuieTek Technology (Suzhou) Co.,Ltd., yukili@quietek.com.cn , 86-0512-6251-5088 |
| Test Firm | Jerry Pan, DEKRA Testing and Certification (Suzhou) Co., Ltd., jerrypan@quietek.com.cn , 86-512-62515088 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is conducted. Device is an 802.11 b/g/n device in a 3x3 MIMO configuration as described in this filing. Power out of the device at the lower and higher channels of 802.11g/n are reduced for band edge compliance reasons. The device has been certified for mobile use and any co-location must be done through the use of FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| FRUXsxfM91HaMKuUow0mPA== | 2016-10-26 | Original Equipment |
Grants
TCB Grant - Application FRUXsxfM91HaMKuUow0mPA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 10/26/2016 Application Dated: 10/24/2016 |
| TP-Link Technologies Co., Ltd. |
| Building 24 (floors 1,3,4,5) and 28 (floors1-4), |
| Central Science and Technology Park,Nanshan |
| Shenzhen, 518057 China |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7WR940NV4 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | 450Mbps Wireless N Router |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.20068 |
| Power output listed is conducted. Device is an 802.11 b/g/n device in a 3x3 MIMO configuration as described in this filing. Power out of the device at the lower and higher channels of 802.11g/n are reduced for band edge compliance reasons. The device has been certified for mobile use and any co-location must be done through the use of FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40MHz bandwidth modes. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application FRUXsxfM91HaMKuUow0mPA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TP-Link Technologies Co., Ltd. Building 24 (floors 1,3,4,5) and 28 (floors1-4), Central Science and Technology Park,Nanshan Shenzhen, 518057 China |
Date of Grant: 10/26/2016 Application Dated: 10/24/2016 |
| Attention: Jing Huang , Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TE7WR940NV4 |
| Name of Grantee: | TP-Link Technologies Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | 450Mbps Wireless N Router |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.20068 |
| Power output listed is conducted. Device is an 802.11 b/g/n device in a 3x3 MIMO configuration as described in this filing. Power out of the device at the lower and higher channels of 802.11g/n are reduced for band edge compliance reasons. The device has been certified for mobile use and any co-location must be done through the use of FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40MHz bandwidth modes. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
