TS2547 Wireless TPMS Sensor External Photos - FCC ID TH9TS2547
FCC ID TH9TS2547
External Photos
Wireless TPMS Sensor
Document preview loads when visible.
Document Details
| FCC ID | TH9TS2547 |
|---|---|
| Document ID | 7194314 |
| Document Type | External Photos |
| Description | External Photos |
| Applicant | Orange Electronic CO., LTD |
| Equipment Class | Wireless TPMS Sensor |
| Product Code | TS2547 |
| Application ID | fTLFtFrHqya4eDkMsNwNHA== |
| Application Purpose | Original Equipment |
| Application Date | 2024-03-26 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0019002419 |
| Test Firm | TUV Rheinland Taiwan Ltd. Taipei Testing Lab. |
| Certified By | Carter Yu |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 09/20/2024 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2024-03-25 |
| Available | 2024-09-20 |
| Created | 2023-07-18 |
| Modified | 2024-03-18 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 656770 |
| File SHA-256 | 4aeaea19ccbc62bf622ccadf7bcabedfe9c0871803fcc99244f362a5da7a2289 |
| PDF Metadata Author | TUV Rheinland Group |
| PDF Metadata Producer | Microsoft® Word for Microsoft 365 TUV Rheinland Group |
| FCC.gov Sources | FCC.gov 7194314 |
