AM510 IEEE 802.11 1X1 a/b/g/n Wireless LAN +... - FCC ID TLZ-AM510

FCC ID TLZ-AM510

Modular Approval Letter

IEEE 802.11 1X1 a/b/g/n Wireless LAN + Bluetooth 5.1 Combo 12 x 12 LGA Module

by AzureWave Technologies, Inc.

Document preview loads when visible.

Document Details

FCC IDTLZ-AM510
Document ID5261672
Document TypeCover Letter(s)
DescriptionModular Approval Letter
Document TitleFCC and IC Applicant form_拆開_2020.12.3 _RSP100 Issue 11…
ApplicantAzureWave Technologies, Inc.
Equipment ClassIEEE 802.11 1X1 a/b/g/n Wireless LAN + Bluetooth 5.1 Combo 12 x 12 LGA Module
Product CodeAM510
Application ID+/63vN/SXfOKv+IPqCXp2A==
Application PurposeOriginal Equipment
Application Date2021-05-25
Frequency Range2402-2480 MHz
FRN0013946611
Test FirmSporton International Inc. Hsinchu Laboratory
Certified ByLeo Huang Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date08/23/2021
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2021-05-24
Available2021-05-25
Created2021-05-14
Modified2021-05-14
Pages1
File TypeAdobe Acrobat PDF
File Size13822
File SHA-2566df89e63c70ea0084a629c0f05989afed8fd4a0a5ebceea28da7f45fc1c5b68b
PDF Metadata AuthorEmilyChen
PDF Metadata ProducerAcrobat Distiller 17.0 (Windows) EmilyChen
FCC.gov SourcesFCC.gov 5261672, FCC.gov 5261639, FCC.gov 5261622
