FCC ID TO9TMO-100
800 MHZ TETRA RADIO
by Funk-Electronic Piciorgros GmbH
Grantee Code: TO9 Product Code: TMO100
Latest application date: 2017-02-22
Device Images
FCC ID Device Details
| FCC ID | TO9TMO-100 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | TO9 |
| Product Code | TMO100 |
| Applicant Business | Funk-Electronic Piciorgros GmbH 🇩🇪 |
| Related Domains |  piciorgros.com |
| Equipment Class | 800 MHZ TETRA RADIO |
| Test Firm | Timco Engineering, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 809-824 MHz | Original Equipment | 2017-02-22 |
| 450.025-469.975 MHz | Class II permissive change or modification of presently authorized equipment | 2014-05-07 |
| 450.025-469.975 MHz | Original Equipment | 2013-01-16 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-02-22 | PDF 1.8 MB |
| Instruction Leaflet TMO-100_engl | Users Manual | 2013-01-16 | PDF 1.3 MB |
| TMO-100_E_V1.821.pdf | Users Manual | 2013-01-16 | PDF 852.9 KB |
| User guide | Users Manual | 2013-01-16 | PDF 4.3 MB |
| User manual | Users Manual | 2013-01-16 | PDF 1.3 MB |
| User manual update | Users Manual | 2013-01-16 | PDF 932.9 KB |
| Internal Photos | Internal Photos | 2017-02-22 | PDF 4.1 MB |
| 75915769 FCC IC Internal Photos | Internal Photos | 2013-01-16 | PDF 1.3 MB |
| External Photos | External Photos | 2017-02-22 | PDF 904.4 KB |
| 75915769 FCC IC External Photos | External Photos | 2013-01-16 | PDF 1.2 MB |
| Label Location | ID Label/Location Info | 2017-02-22 | PDF 859.8 KB |
| Label Sample | ID Label/Location Info | 2017-02-22 | PDF 364.6 KB |
| Label | ID Label/Location Info | 2013-01-16 | PDF 278.3 KB |
| Label location | ID Label/Location Info | 2013-01-16 | PDF 78.1 KB |
| Test Setup Photos | Test Setup Photos | 2017-02-22 | PDF 390.8 KB |
| Test Setup Photos | Test Setup Photos | 2014-05-07 | PDF 109.7 KB |
| 75915769 FCC IC Set up Photos | Test Setup Photos | 2013-01-16 | PDF 716.4 KB |
| Test Report | Test Report | 2017-02-22 | PDF 1.5 MB |
| Test Report | Test Report | 2014-05-07 | PDF 430.5 KB |
| 75915769 Report 01 Issue 2 | Test Report | 2013-01-16 | PDF 221.9 KB |
| 75915769 Report 02 Issue 1 | Test Report | 2013-01-16 | PDF 685.2 KB |
| Part 90 EMC report | Test Report | 2013-01-16 | PDF 686.9 KB |
| Tuning Attestation | Attestation Statements | 2017-02-22 | PDF 133.9 KB |
| Attestation Statement FCC | Attestation Statements | 2013-01-16 | PDF 127.6 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2017-02-22 | PDF 237.1 KB |
| POA | Cover Letter(s) | 2017-02-22 | PDF 133.2 KB |
| Cover Letter | Cover Letter(s) | 2014-05-07 | PDF 184.2 KB |
| Frequency Justification Letter | Cover Letter(s) | 2014-05-07 | PDF 103.4 KB |
| Confidentiality letter | Cover Letter(s) | 2013-01-16 | PDF 192.1 KB |
| MPE Report | RF Exposure Info | 2017-02-22 | PDF 177.5 KB |
| 75915769 Report 03 Issue 1 | RF Exposure Info | 2013-01-16 | PDF 121.8 KB |
| FCC RF Exposure Calculation Example | RF Exposure Info | 2013-01-16 | PDF 234.7 KB |
| Necessary distance calculations | RF Exposure Info | 2013-01-16 | PDF 32 KB |
| RF Evaluation | RF Exposure Info | 2013-01-16 | PDF 121.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 35.5 KB | |
| TETRA Schematics Metadata only | Schematics | PDF 335.5 KB | |
| TMO Displayboard Schematics Metadata only | Schematics | PDF 35.1 KB | |
| TMO IOBoard Schematics Metadata only | Schematics | PDF 79.1 KB | |
| TMO Mainboard Schematics Metadata only | Schematics | PDF 161.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 105.6 KB | |
| TETRA BOM Parts List Metadata only | Parts List/Tune Up Info | PDF 69.7 KB | |
| TMO Displayboard BOM Parts List Metadata only | Parts List/Tune Up Info | PDF 38.8 KB | |
| TMO IOBoard BOM Parts List Metadata only | Parts List/Tune Up Info | PDF 47.2 KB | |
| TMO Mainboard BOM Parts List Metadata only | Parts List/Tune Up Info | PDF 48.1 KB | |
| Tune Up Procedure Metadata only | Parts List/Tune Up Info | PDF 212.9 KB |
Application Information
| Application ID | 4qjKjspgFb8jL4GfUq/PHQ== |
|---|---|
| Final Action Date | 2017-02-22 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0022117345 |
| Model | TMO-100 |
| Frequency Range | 809-824 MHz |
| Equipment Class | TNB - Licensed Non-Broadcast Station Transmitter |
| Device Description | 800 MHZ TETRA RADIO |
| Responsible Party | Michael D. Piciorgros, Dipl.-Ing., info@piciorgros.com , 011491722490191 |
| Test Firm | Bruno Clavier, Timco Engineering, Inc., bruno@timcoengr.com  , 352-472-5500 |
| TCB Email | TEI@TIMCOENGR.COM |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Professional installation required. Power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 0.69-m from all persons and must not exceed an antenna gain of +13 dBi. Users must be provided with instructions and transmitter operating conditions for satisfying RF exposure compliance. |
