ATC40G5AN DIGITAL CAR AVN SYSTEM Test... - FCC ID TQ8-ATC40G5AN

FCC ID TQ8-ATC40G5AN

Test Setup photos

DIGITAL CAR AVN SYSTEM

by HYUNDAI MOBIS CO., LTD.

Document preview loads when visible.

Document Details

FCC IDTQ8-ATC40G5AN
Document ID3245512
Document TypeTest Setup Photos
DescriptionTest Setup photos
Document TitleTest Setup Photos_ATC40G5AN
ApplicantHYUNDAI MOBIS CO., LTD.
Equipment ClassDIGITAL CAR AVN SYSTEM
Product CodeATC40G5AN
Application IDATNAbiJlpraGrCt7EpZ03w==
Application PurposeOriginal Equipment
Application Date2017-01-03
Frequency Range2402-2480 MHz
FRN0023347537
Test FirmSGS KOREA CO., Ltd.
Certified BySeung Hoon Choe Senior Researcher
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date07/02/2017
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2017-01-03
Available2017-07-02
Created2016-11-29
Modified2016-11-29
Pages4
File TypeAdobe Acrobat PDF
File Size1187736
File SHA-2565577ba1dc21d747c558bf178796e6f68c6dccd7d8deccb5e6c82a97b8720cbb1
PDF Metadata Authorgihee_hwang
PDF Metadata ProducerGaaiho PDF gihee_hwang
FCC.gov SourcesFCC.gov 3245512
