FCC ID TTM-124P05P
ExtendAir G2 24GHz Radio
by Exalt Wireless, Inc.
Grantee Code: TTM Product Code: 124P05P
Latest application date: 2016-03-15
Device Images
FCC ID Device Details
| FCC ID | TTM-124P05P |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | TTM |
| Product Code | 124P05P |
| Applicant Business | Exalt Wireless, Inc. 🇺🇸 |
| Related Domains |  exaltcom.com |
| Equipment Class | ExtendAir G2 24GHz Radio |
| Test Firm | EUROFINS ELECTRICAL AND ELECTRONIC TESTING NA, INC |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 24075-24225 MHz | Original Equipment | 2016-03-15 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-04-29 | PDF 4 MB |
| Internal Photos | Internal Photos | 2016-03-15 | PDF 537.5 KB |
| External Photos | External Photos | 2016-03-15 | PDF 367.9 KB |
| Label and Location | ID Label/Location Info | 2016-03-15 | PDF 162.2 KB |
| Test Setup Photos | Test Setup Photos | 2016-03-15 | PDF 609.5 KB |
| Test Report | Test Report | 2016-03-15 | PDF 5.9 MB |
| Long Term Confidentiality Request Letter | Cover Letter(s) | 2016-03-15 | PDF 107.1 KB |
| Short Term Confidentiality Request Letter | Cover Letter(s) | 2016-03-15 | PDF 97.9 KB |
| Antenna Datasheet - WTC03-240DAR-QOETB | RF Exposure Info | 2016-03-15 | PDF 201.6 KB |
| Antenna Datasheet - WTC06-240DAR-QOETB | RF Exposure Info | 2016-03-15 | PDF 207.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 249.3 KB | |
| Schematics - Digital Metadata only | Schematics | PDF 573.4 KB | |
| Schematics - RX Metadata only | Schematics | PDF 162.1 KB | |
| Schematics - TX Metadata only | Schematics | PDF 167 KB | |
| Operational Description Metadata only | Operational Description | PDF 249.3 KB |
Application Information
| Application ID | 1pGOKpXYEnN8weRIz+FFBg== |
|---|---|
| Final Action Date | 2016-03-15 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0014287304 |
| Model | 124P05P |
| Frequency Range | 24075-24225 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | ExtendAir G2 24GHz Radio |
| Responsible Party | Tuyen Banh, tbanh@exaltcom.com , 469-331-0314 |
| Technical Contact | Tuyen Banh, Exalt Wireless, Inc., tbanh@exaltcom.com , 469-331-0314 |
| Test Firm | Greg Kovolenko, EUROFINS ELECTRICAL AND ELECTRONIC TESTING NA, INC, greg.kovolenko@metlabs.com  , 4108444071 |
| TCB Email | tcbinfo@metlabs.com |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 04/29/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | This device should be professionally installed and only used with the antenna’s documented in this filing. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 1pGOKpXYEnN8weRIz+FFBg== | 2016-03-15 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 24075-24225 MHz | 15C |
Grants
TCB Grant - Application 1pGOKpXYEnN8weRIz+FFBg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Electrical and Electronic Testing NA, Inc 914 W. Patapsco Avenue Baltimore, MD 21230-3432 |
Date of Grant: 03/15/2016 Application Dated: 03/15/2016 |
| Exalt Wireless, Inc. |
| 530 Division Street |
| Campbell, CA 95008 |
| Attention: Tuyen Banh |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TTM-124P05P |
| Name of Grantee: | Exalt Wireless, Inc. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | ExtendAir G2 24GHz Radio |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 24075.0 - 24225.0 |
| This device should be professionally installed and only used with the antenna’s documented in this filing. |
EAS Grant - Application 1pGOKpXYEnN8weRIz+FFBg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Exalt Wireless, Inc. 530 Division Street Campbell, CA 95008 United States |
Date of Grant: 03/15/2016 Application Dated: 03/15/2016 |
| Attention: Tuyen Banh |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TTM-124P05P |
| Name of Grantee: | Exalt Wireless, Inc. |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | ExtendAir G2 24GHz Radio |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 24075.0 - 24225.0 |
| This device should be professionally installed and only used with the antenna’s documented in this filing. |
| Mail To: |
