Testing
NVLAP Lab Code 200087-0
Submittal Application
Report
For
Grant of Certification of Modular Device
Model: RB953GS-5HnT-RP-US
5180-5240, and 5745-5825 MHz
Unlicensed National Information Infrastructure (U-NII)
Indoor/Outdoor Operation Device
U-NII-1, U-NII-3 Operation (New Rules)
FCC ID: TV7RB953GS5HNTM
IC: 7442A-RB953GS5HNT
FOR
Mikrotikls SIA
Pernavas 46 Str.
Riga LV-1009 Latvia
Test Report Number: 170316
FCC Site Registration: 90910, 315994
IC Test Site Registration: 3041A-1
Authorized Signatory:
Scot D. Rogers
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 1 of 85
Testing
NVLAP Lab Code 200087-0
ROGERS LABS, INC.
4405 West 259th Terrace
Louisburg, KS 66053
Phone / Fax (913) 837-3214
Engineering Test Report for
Grant of Certification Application
FOR
Unlicensed National Information Infrastructure (U-NII)
Indoor/Outdoor Operation Device
47CFR, Part 15E 15.407 (New Rules)
Industry Canada RSS-247 Issue 2
License Exempt Intentional Radiator
For
Mikrotikls SIA
Pernavas 46 Str.
Riga LV-1009 Latvia
Broadband Digital Transmission System Module
U-NII-1 and U-NII-3 operation
Model: RB953GS-5HnT-RP-US
Frequency Range 5180-5240 and 5745-5825 MHz
FCC ID#: TV7RB953GS5HNTM
IC: 7442A-RB953GS5HNT
Test Date: March 16, 2017
Certifying Engineer:
Scot D. Rogers
Rogers Labs, Inc.
4405 West 259th Terrace
Louisburg, KS 66053
Telephone/Facsimile: (913) 837-3214
This report shall not be reproduced except in full, without the written approval of the laboratory.
This report must not be used by the client to claim product certification, approval, or
endorsement by NVLAP, NIST, or any agency of the Federal Government.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 2 of 85
Testing
NVLAP Lab Code 200087-0
Table of Contents
TABLE OF CONTENTS .................................................................................................. 3
REVISIONS..................................................................................................................... 8
FORWARD ..................................................................................................................... 9
OPINION / INTERPRETATION OF RESULTS ............................................................... 9
EQUIPMENT TESTED .................................................................................................. 10
EQUIPMENT FUNCTION AND CONFIGURATION...................................................... 11
Equipment Configuration.................................................................................................................................. 12
APPLICANT COMPANY INFORMATION .................................................................... 13
EQUIPMENT INFORMATION ....................................................................................... 13
Product Details ................................................................................................................................................... 14
Accessories .......................................................................................................................................................... 15
Table for Filed Antennas ................................................................................................................................... 15
Antenna and Bandwidth .................................................................................................................................... 15
IEEE 11a/n Spec. ................................................................................................................................................ 15
Table for Carrier Frequencies .......................................................................................................................... 16
Table for Test Modes ......................................................................................................................................... 16
Test Result of Occupied Bandwidth ................................................................................................................. 17
APPLICATION FOR CERTIFICATION ......................................................................... 19
APPLICABLE STANDARDS & TEST PROCEDURES ................................................ 20
EQUIPMENT TESTING PROCEDURES ...................................................................... 20
AC Line Conducted Emission Test Procedure ................................................................................................ 20
Radiated Emission Test Procedure ................................................................................................................... 20
Diagram 1 Test arrangement for Conducted emissions ..................................................................................... 21
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 3 of 85
Testing
NVLAP Lab Code 200087-0
Diagram 2 Test arrangement for radiated emissions of tabletop equipment ...................................................... 22
Diagram 3 Test arrangement for radiated emissions tested on Open Area Test Site (OATS) ........................... 23
TEST SITE LOCATIONS .............................................................................................. 23
LIST OF TEST EQUIPMENT ........................................................................................ 24
UNITS OF MEASUREMENTS ...................................................................................... 25
ENVIRONMENTAL CONDITIONS................................................................................ 25
INTENTIONAL RADIATORS ........................................................................................ 25
Antenna Requirements ...................................................................................................................................... 25
Restricted Bands of Operation .......................................................................................................................... 25
Table 1 Radiated Emissions in Restricted Bands Data (MT-482016/N/A) ....................................................... 26
Table 2 Radiated Emissions in Restricted Bands Data (PA58-24-ANT)........................................................... 27
Table 3 Radiated Emissions in Restricted Bands Data (HDDA5W-32-DP2).................................................... 28
Summary of Results for Radiated Emissions in Restricted Bands ................................................................ 28
AC Line Conducted Emissions Procedure ....................................................................................................... 29
Figure 1 AC Line Conducted Emissions Line 1 ................................................................................................ 30
Figure 2 AC Line Conducted Emissions Line 2 ................................................................................................ 30
Table 4 AC Line Conducted Emissions Data (Highest Emissions Line L1) ..................................................... 31
Table 5 AC Line Conducted Emissions Data (Highest Emissions Line L2) ..................................................... 31
Summary of Results for AC Line Conducted Emissions ................................................................................ 31
General Radiated Emissions Procedure ........................................................................................................... 32
Table 6 General Radiated Emissions from EUT Data (Highest Emissions) ...................................................... 33
Summary of Results for General Radiated Emissions .................................................................................... 33
Operation in the 5150-5250 and 5725-5850 MHz Frequency U-NII-1 and U-NII-3 Bands ......................... 34
Elevation Compliance Omni Directional (8.5 dBi) MT-482016/N/A ............................................................... 36
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 4 of 85
Testing
NVLAP Lab Code 200087-0
Elevation Compliance Panel Antenna (24 dBi) PA58-24-ANT ........................................................................ 37
Elevation Compliance Dish Antenna (32 dBi) HDDA5W-32-DP2 .................................................................. 38
Figure 3 Plot of Transmitter Emissions (Chain 0, Across 5150-5250 MHz Band, 802.11a) ............................. 39
Figure 4 Plot of Transmitter Emissions (Chain 1, Across 5150-5250 MHz Band, 802.11a) ............................. 39
Figure 5 Plot of Transmitter Emissions (Chain 2, Across 5150-5250 MHz Band, 802.11a) ............................. 40
Figure 6 Plot of Transmitter Emissions (Chain 0, Across 5150-5250 MHz Band, 802.11n40) ........................ 40
Figure 7 Plot of Transmitter Emissions (Chain 1, Across 5150-5250 MHz Band, 802.11n40) ........................ 41
Figure 8 Plot of Transmitter Emissions (Chain 2, Across 5150-5250 MHz Band, 802.11n40) ........................ 41
Figure 9 Plot of Transmitter Low Band Edge (Chain 0, 5150-5250 MHz Band, 802.11a) ............................... 42
Figure 10 Plot of Transmitter Low Band Edge (Chain 1, 5150-5250 MHz Band, 802.11a) ............................. 42
Figure 11 Plot of Transmitter Low Band Edge (Chain 2, 5150-5250 MHz Band, 802.11a) ............................. 43
Figure 12 Plot of Transmitter Low Band Edge (Chain 0, 5150-5250 MHz Band, 802.11n40) ......................... 43
Figure 13 Plot of Transmitter Low Band Edge (Chain 1, 5150-5250 MHz Band, 802.11n40) ......................... 44
Figure 14 Plot of Transmitter Low Band Edge (Chain 2, 5150-5250 MHz Band, 802.11n40) ......................... 44
Figure 15 Plot of Transmitter High Band Edge (Chain 0, 5150-5250 MHz Band, 802.11a)............................. 45
Figure 16 Plot of Transmitter High Band Edge (Chain 1, 5150-5250 MHz Band, 802.11a)............................. 45
Figure 17 Plot of Transmitter High Band Edge (Chain 2, 5150-5250 MHz Band, 802.11a)............................. 46
Figure 18 Plot of Transmitter High Band Edge (Chain 0, 5150-5250 MHz Band, 802.11n40) ........................ 46
Figure 19 Plot of Transmitter High Band Edge (Chain 1, 5150-5250 MHz Band, 802.11n40) ........................ 47
Figure 20 Plot of Transmitter High Band Edge (Chain 2, 5150-5250 MHz Band, 802.11n40) ........................ 47
Figure 21 Plot of Transmitter Emissions (Chain 0, 5150-5250 MHz Band, 802.11a, 99% OBW) ................... 48
Figure 22 Plot of Transmitter Emissions (Chain 1, 5150-5250 MHz Band, 802.11a, 99% OBW) ................... 48
Figure 23 Plot of Transmitter Emissions (Chain 2, 5150-5250 MHz Band, 802.11a, 99% OBW) ................... 49
Figure 24 Plot of Transmitter Emissions (Chain 0, 5150-5250 MHz Band, 802.11a, 26 dB OBW) ................. 49
Figure 25 Plot of Transmitter Emissions (Chain 1, 5150-5250 MHz Band, 802.11a, 26 dB OBW) ................. 50
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 5 of 85
Testing
NVLAP Lab Code 200087-0
Figure 26 Plot of Transmitter Emissions (Chain 2, 5150-5250 MHz Band, 802.11a, 26 dB OBW) ................. 50
Figure 27 Plot of Transmitter Emissions (Chain 0, 5150-5250 MHz Band, 802.11n40, 99% OBW) ............... 51
Figure 28 Plot of Transmitter Emissions (Chain 1, 5150-5250 MHz Band, 802.11n40, 99% OBW) ............... 51
Figure 29 Plot of Transmitter Emissions (Chain 2, 5150-5250 MHz Band, 802.11n40, 99% OBW) ............... 52
Figure 30 Plot of Transmitter Emissions (Chain 0, 5150-5250 MHz Band, 802.11n40, 26 dB OBW) ............. 52
Figure 31 Plot of Transmitter Emissions (Chain 1, 5150-5250 MHz Band, 802.11n40, 26 dB OBW) ............. 53
Figure 32 Plot of Transmitter Emissions (Chain 2, 5150-5250 MHz Band, 802.11n40, 26 dB OBW) ............. 53
Figure 33 Plot of Transmitter Emissions (Chain 0, Across 5725-5850 MHz Band, 802.11a) ........................... 54
Figure 34 Plot of Transmitter Emissions (Chain 1, Across 5725-5850 MHz Band, 802.11a) ........................... 54
Figure 35 Plot of Transmitter Emissions (Chain 2, Across 5725-5850 MHz Band, 802.11a) ........................... 55
Figure 36 Plot of Transmitter Emissions (Chain 0, Across 5725-5850 MHz Band, 802.11n40) ...................... 55
Figure 37 Plot of Transmitter Emissions (Chain 1, Across 5725-5850 MHz Band, 802.11n40) ...................... 56
Figure 38 Plot of Transmitter Emissions (Chain 2, Across 5725-5850 MHz Band, 802.11n40) ...................... 56
Figure 39 Plot of Transmitter Low Band Edge (Chain 0, 5725-5850 MHz Band, 802.11a) ............................. 57
Figure 40 Plot of Transmitter Low Band Edge (Chain 1, 5725-5850 MHz Band, 802.11a) ............................. 57
Figure 41 Plot of Transmitter Low Band Edge (Chain 2, 5725-5850 MHz Band, 802.11a) ............................. 58
Figure 42 Plot of Transmitter Low Band Edge (Chain 0, 5725-5850 MHz Band, 802.11n40) ......................... 58
Figure 43 Plot of Transmitter Low Band Edge (Chain 1, 5725-5850 MHz Band, 802.11n40) ......................... 59
Figure 44 Plot of Transmitter Low Band Edge (Chain 2, 5725-5850 MHz Band, 802.11n40) ......................... 59
Figure 45 Plot of Transmitter High Band Edge (Chain 0, 5725-5850 MHz Band, 802.11a)............................. 60
Figure 46 Plot of Transmitter High Band Edge (Chain 1, 5725-5850 MHz Band, 802.11a)............................. 60
Figure 47 Plot of Transmitter High Band Edge (Chain 2, 5725-5850 MHz Band, 802.11a)............................. 61
Figure 48 Plot of Transmitter High Band Edge (Chain 0, 5725-5850 MHz Band, 802.11n40) ........................ 61
Figure 49 Plot of Transmitter High Band Edge (Chain 1, 5725-5850 MHz Band, 802.11n40) ........................ 62
Figure 50 Plot of Transmitter High Band Edge (Chain 2, 5725-5850 MHz Band, 802.11n40) ........................ 62
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 6 of 85
Testing
NVLAP Lab Code 200087-0
Figure 51 Plot of Transmitter Emissions (Chain 0, 5725-5850 MHz Band, 802.11a, 99% OBW) ................... 63
Figure 52 Plot of Transmitter Emissions (Chain 1, 5725-5850 MHz Band, 802.11a, 99% OBW) ................... 63
Figure 53 Plot of Transmitter Emissions (Chain 2, 5725-5850 MHz Band, 802.11a, 99% OBW) ................... 64
Figure 54 Plot of Transmitter Emissions (Chain 0, 5725-5850 MHz Band, 802.11a, 6-dB OBW) .................. 64
Figure 55 Plot of Transmitter Emissions (Chain 1, 5725-5850 MHz Band, 802.11a, 6-dB OBW) .................. 65
Figure 56 Plot of Transmitter Emissions (Chain 2, 5725-5850 MHz Band, 802.11a, 6-dB OBW) .................. 65
Figure 57 Plot of Transmitter Emissions (Chain 0, 5725-5850 MHz Band, 802.11n40, 99% OBW) ............... 66
Figure 58 Plot of Transmitter Emissions (Chain 1, 5725-5850 MHz Band, 802.11n40, 99% OBW) ............... 66
Figure 59 Plot of Transmitter Emissions (Chain 2, 5725-5850 MHz Band, 802.11n40, 99% OBW) ............... 67
Figure 60 Plot of Transmitter Emissions (Chain 0, 5725-5850 MHz Band, 802.11n40, 6-dB OBW) .............. 67
Figure 61 Plot of Transmitter Emissions (Chain 1, 5725-5850 MHz Band, 802.11n40, 6-dB OBW) .............. 68
Figure 62 Plot of Transmitter Emissions (Chain 2, 5725-5850 MHz Band, 802.11n40, 6-dB OBW) .............. 68
Transmitter Emissions Data .............................................................................................................................. 69
Table 7 Transmitter Radiated Emission (5150-5250 MHz Band, MT-482016/N/A) ........................................ 69
Table 8 Transmitter Radiated Emission (5150-5250 MHz Band, PA58-24-ANT) ........................................... 70
Table 9 Transmitter Radiated Emission (5150-5250 MHz Band, HDDA5W-32-DP2) .................................... 71
Table 10 Transmitter Radiated Emission (5725-5850 MHz Band, MT-482016/N/A) ...................................... 72
Table 11 Transmitter Radiated Emission (5725-5850 MHz Band, PA58-24-ANT) ......................................... 73
Table 12 Transmitter Radiated Emission (5725-5850 MHz Band, HDDA5W-32-DP2) .................................. 74
Table 13 Transmitter Antenna Port Conducted Power and Emissions Chain 0 ................................................. 75
Table 14 Transmitter Antenna Port Conducted Power and Emissions Chain 1 ................................................. 76
Table 15 Transmitter Antenna Port Conducted Power and Emissions Chain 2 ................................................. 77
Table 16 Transmitter all antenna Ports Total Power and PSD U-NII-1 Band ................................................... 78
Table 17 Transmitter all antenna Ports Total Power and PSD U-NII-3 Band ................................................... 78
Summary of Results for Transmitter Radiated Emissions of Intentional Radiator ..................................... 79
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 7 of 85
Testing
NVLAP Lab Code 200087-0
STATEMENT OF MODIFICATIONS AND DEVIATIONS ............................................. 79
ANNEX .......................................................................................................................... 80
Annex A Measurement Uncertainty Calculations ........................................................................................... 81
Annex B Rogers Labs Test Equipment List ..................................................................................................... 82
Annex C Rogers Qualifications ......................................................................................................................... 83
Annex D FCC Site Registration Letter ............................................................................................................. 84
Annex E Industry Canada Site Registration Letter ........................................................................................ 85
Revisions
Revision 1 Issued April 5, 2017
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 8 of 85
Testing
NVLAP Lab Code 200087-0
Forward
The following information is submitted for consideration in obtaining Class 2 Permissible
Change Grant of Certification for License Exempt, Unlicensed National Information
Infrastructure (U-NII) Intentional Radiator operating under 47CFR Paragraph 15E (15.407),
U-NII-1 and U-NII-3 new rules, 5180-5240, and 5745-5825 MHz bands, and Industry Canada
RSS-GEN Issue 4, and RSS-247 Issue 2, LE-LAN transmitter.
Name of Applicant:
Mikrotikls SIA
FRN: 0014431100
Pernavas 46 Str.
Riga LV-1009 Latvia
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM, IC: 7442A-RB953GS5HNT
Frequency Range: 5180-5240 MHz and 5745-5825 MHz (U-NII-1 and U-NII-3 under new
rules 15.407, 802.11a/n 20 MHz and 40 MHz channels) and limited antenna
options and restrictions for operation in Canada
Maximum Power: U-NII-1 Band, 20 MHz mode, 0.201-watt, 99% OBW 18400 kHz
U-NII-1 Band, 40 MHz mode, 0.252-watt, 99% OBW 38250 kHz
U-NII-1 Band, 80 MHz mode, N/A
U-NII-3 Band, 20 MHz mode, 0.217-watt, 99% OBW 18400 kHz
U-NII-3 Band, 40 MHz mode, 0.288-watt, 99% OBW 38400 kHz
U-NII-3 Band, 80 MHz mode, N/A
Opinion / Interpretation of Results
Tests Performed
Margin (dB)
Results
Restricted Frequency Bands 15.205, RSS-GEN 8.10
-7.0
Complies
AC Line Conducted 15.207, RSS-GEN 7.2.4
-8.4
Complies
Radiated Emissions 15.209, RSS-GEN 7.2.5
-1.7
Complies
Harmonic Emissions per 15.407, RSS-247
-22.4
Complies
Power Spectral Density per 15.407, RS-247
-5.9
Complies
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 9 of 85
Testing
NVLAP Lab Code 200087-0
Equipment Tested
Equipment
Model
FCC I.D.
EUT
RB953GS-5HnT-RP-US
TV7RB953GS5HNTM
AC Adapter
FLD181-240075-U
N/A
Dell Studio XPS
921LBN1
N/A
Test results in this report relate only to the items tested.
Antenna options tested include:
5 GHz antennas
Omni Directional (8.5 dBi) MT-482016/N/A
Panel Antenna (24 dBi) PA58-24-ANT
Dish Antenna (32 dBi) HDDA5W-32-DP2
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 10 of 85
Testing
NVLAP Lab Code 200087-0
Equipment Function and Configuration
The EUT is a 5 GHz (three chain) Digital Transmission System module providing Multiple
Inputs and Multiple Outputs (MIMO). The design provides MIMO operational capabilities
in the U-NII-1 and U-NII-3 services (5180-5240 and 5745-5825 MHz) and Industry Canada
operation as LE-LAN, Indoor only for 5180-5240 MHz band, Indoor/Outdoor access point
operation in the 5725-5850 MHz band. The EUT offers broadband wireless connectivity to
transmit and receive data. The design utilizes reverse polarity SMA connectors and requires
either profession installation or OEM equipment be provided with permanent compliant
antenna systems. The module supports multiple antenna options selected from the authorized
antenna styles as documented in this report. The EUT provides 3 antenna connection ports,
serial interface port, three Ethernet ports one of which will support Power Over Ethernet
(POE) operation, USB port and 2 SFP ports. The design requires power provided through
power interface port and adapter. For testing purposes, the module was connected to the
manufacturer supplied AC/DC power supply and communicating to the laptop computer
through the Ethernet network interface. This configuration provided operational control of
the EUT and communications over the network interface between the EUT and supporting
computer system. The design provides no other interfacing options than those presented in
this report. For testing purposes, the RB953GS-5HnT-RP-US module was configured to
transmit in available data modes receiving power from the manufacturer provided AC/DC
power adapter. The module was not enclosed in a case during testing assuming the printed
circuit board module presented worst-case emissions. As requested by the manufacturer and
required by regulations, the equipment was tested for emissions compliance using the
available configurations with the worst-case data presented. Test results in this report relate
only to the products described in this report.
Note: This equipment requires either permanently attached antennas in the final OEM
configuration or professional installation by qualified installers. The installation software
(available only to the OEM or installers) requires entry of installed antenna characteristics
which attenuate the output power to regulatory compliant levels. Antenna information
required is antenna gain only and depending on the frequency band and regulations, output
power is reduced accordingly.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 11 of 85
Testing
NVLAP Lab Code 200087-0
Equipment Configuration
External Antenna
(EUT)
External Antenna
Network Connection
External Antenna
POE Input
Laptop Computer (CPU)
AC/DC Adapter
CPU AC Power Adapter
Utility Power
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 12 of 85
Testing
NVLAP Lab Code 200087-0
Applicant Company information
Applicants Company
MikroTik (“Mikrotīkls, SIA”)
Applicants Address
Pernavas 46 Str., Riga LV-1009 Latvia
FCC Identifier
TV7RB953GS5HNTM
Industry Canada Identifier
7442A-RB953GS5HNT
Manufacturer Company
MikroTik (“Mikrotīkls, SIA”)
Manufacturer Address
Pernavas 46 Str., Riga LV-1009 Latvia
Equipment information
Product Marketing Name (PMN):
RB953GS-5HnT-RP-US
The PMN is the name or model number under which the product
will be marketed/offered for sale in Canada. If the product has
PMN, it must be provided.
Unique Product Number (UPN):
RB953GS5HNT
The applicant, made up of a maximum of 11 alphanumeric
characters (A-Z, 0-9), assigns the UPN.
Hardware Version Identification Number (HVIN):
RB953GS-5HnT-RP-US
The HVIN identifies hardware specifications of a product version.
The HVIN replaces the ISED Model Number in the legacy Efiling System. An HVIN is required for all products for
certification applications.
Host Marketing Name (HMN) (if applicable):
CA433U
The HMN is the name or model number of a final product, which
contains a certified radio module.
Brand Name
Model Number
RB953GS-5HnT-RP-US
Test Rule Part(s)
47CFR 15E, 15.407, RSS-247
Test Frequency Range
5.15-5.25 and 5.725-5.85 GHz
Project Number
170316
Submission Type
Certification
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 13 of 85
Testing
NVLAP Lab Code 200087-0
Product Details
Items
Product Type
Radio Type
Power Type
Modulation
Data Modulation
Data Rate (Mbps)
Frequency Range
Channel Number
Description
5 GHz U-NII-1 and U-NII-3 [ 3x3 MIMO]
Transceiver
POE adapter with External Power Supply
IEEE 802.11a: OFDM
IEE 802.11a/n: see the below table
IEEE 802.11 a/n: OFDM (BPSK/QPSK/16QAM/64QAM)
IEEE 802.11ac: OFDM (BPSK/QPSK/16QAM/64QAM/256QAM)
IEEE 802.11 g/n: N/A
IEEE 802.11 b: N/A
IEEE 802.11a: OFDM (36/48/54)
IEEE 802.11n/ac: see the below table
IEEE 802.11b/g/n: N/A
5150-5250 MHz / 5725-5850 MHz
802.11b: N/A
802.11g/n: N/A
802.11a/n: 9 for 20MHz bandwidth; 4 for 40MHz bandwidth
802.11 a/c: 1 for 80 MHz bandwidth
Maximum Conducted
Output Power
802.11 b:
802.11 g:
802.11 n (HT-20):
802.11 n (HT-40):
Band 1:
IEEE 802.11a: 0.201 Watts
IEEE 802.11a/n MCS0/Nss1 (VHT20): 0.201 Watts
IEEE 802.11a/n MCS0/Nss1 (VHT40): 0.252 Watts
IEEE 802.11ac MCS0/Nss1 (VHT80): N/A
Band 3:
IEEE 802.11a: 0. 217 Watts
IEEE 802.11a/n MCS0/Nss1 (VHT20): 0. 217 Watts
IEEE 802.11a/n MCS0/Nss1 (VHT40): 0. 288 Watts
IEEE 802.11ac MCS0/Nss1 (VHT80): N/A
Carrier Frequencies
Please refer to Table for Carrier Frequencies
Antenna
External antenna options include:
5 GHz antennas
Omni Directional (8.5 dBi) MT-482016/N/A
Panel Antenna (24 dBi) PA58-24-ANT
Dish Antenna (32 dBi) HDDA5W-32-DP2
Communication Mode
Device operates as a 3x3 input output 5 GHz U-NII 1 and U-NII-3. The
design utilizes Multiple-Input-Multiple-Output (MIMO) operational
capability. The design may be configured to transmit on all chains or chosen
single chain (without automatic switching between chains). The unit may
receive on single or all chains and may transmit on single or all chains.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 14 of 85
Testing
NVLAP Lab Code 200087-0
Beamforming Function
Without beamforming
Operating Mode
5150-5250 MHz (U-NII-1 band) and 5725-5825 MHz (U-NII-3) and
restricted antenna options for use in Canada
Accessories
AC Power Adapter
FLD181-240075-U
Power Over Ethernet (POE) adapter
Not utilized
Table for Filed Antennas
Ant.
Brand
Model Name
P/N
Antenna Type
Connector
Gain (dBi)
2.4GHZ
Mikrotikls
MT-482016/N/A
N/A
PA58-24-ANT
HDDA5W-32-DP2
N/A
N/A
Omni
Directional
Panel
Dish
5GHZ
8.5
24
32
Antenna and Bandwidth
Antenna
Bandwidth Mode
TX chains
20 MHz
IEEE 802.11a
1-3 from above list
IEEE 802.11n
IEEE 802.11ac
40 MHz
80 MHz
1-3 from above list
N/A
IEEE 11a/n Spec.
Protocol
Number of Transmit Chains (NTX)
Data Rate/MCS
802.11a/n (VHT20)
MCS 0-9/Nss1-3
802.11a/n (VHT40)
MCS 0-9/Nss1-3
802.11ac (VHT80)
N/A
MCS 0-9/Nss1-3
Note 1: IEEE Std. 802.11n modulation consists of HT20 and HT40 (HT: High Throughput). The
EUT supports HT20 and HT40.
Note 2: IEEE Std. 802.11ac modulation consists of VHT20, VHT40, VHT80, and VHT160 (VHT:
Very High Throughput). The EUT does not support 802.11ac VHT160.
Note 3: Modulation modes consist of below configuration:
IEEE 802.11a/n; HT20/HT40; IEEE 802.11ac: VHT80
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 15 of 85
Testing
NVLAP Lab Code 200087-0
Table for Carrier Frequencies
For 20MHz bandwidth systems, use Channel 36, 40, 44, 48, 149, 153, 157, 161, 165.
For 40MHz bandwidth systems, use Channel 38, 46, 151, 159.
Frequency Band
Channel No.
Frequency
Channel No.
Frequency
5150-5250MHz
36
38
40
42
149
151
153
155
5180MHz
5190MHz
5200MHz
5210MHz
5745MHz
5755MHz
5765MHZ
5775MHZ
44
46
48
157
159
161
165
5220MHz
5230MHz
5240MHz
5785MHz
5795MHz
5805MHz
5825MHz
U-NII-1
5725-5850MHz
U-NII-3
Table for Test Modes
Preliminary tests were performed in different data rates to define the worst radiated emission.
The data rate shown in the table below is the worst-case rate with respect to the specific test
item. Investigation has been done on all possible configurations while searching the worst cases.
The following table is a list of the test modes investigated for this report.
Test Items
Max. Conducted
Output Power
Power Spectral
Density
26dB, 99%
Occupied
Bandwidth
Measurement
Mode
Data Rate
Channel
Chain
11 a BPSK
Band 1&3
6Mbps
36/40/48/149/157/165
1,2,3
11a/n HT20
Band 1&3
MCS0/Nss1
36/40/48/149/157/165
1,2,3
11a/n HT40
Band 1&3
MCS0/Nss1
38/46/151/159
1,2,3
11ac VHT80
Band 1&3
MCS0/Nss1
42,155
N/A
11a BPSK
Band 1&3
6Mbps
36//40/48/149/157/165 1,2,3
11a/n HT20
Band 1&3
MCS0/Nss1
36/40/48/149/157/165
1,2,3
11a/n HT40
Band 1&3
MCS0/Nss1
38/46/151/159
1,2,3
11ac VHT80
Band 1&3
MCS0/Nss1
42,155
N/A
11a BPSK
Band 1&3
6Mbps
36/40/48/149/157/165
1,2,3
11a/n HT20
Band 1&3
MCS0/Nss1
36/40/48/149/157/165
1,2,3
11a/n HT40
Band 1&3
MCS0/Nss1
38/46/151/159
1,2,3
11ac VHT80
Band 1&3
MCS0/Nss1
42,155
N/A
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 16 of 85
Testing
NVLAP Lab Code 200087-0
6dB Spectrum
Bandwidth
Measurement
Radiated
Emission Below
1GHz
Radiated
Emission Above
1GHz
Band Edge
Emission
Frequency
Stability
802.11a BPSK
Band 3
6Mbps
149/157/165
1,2,3
802.11a/n HT20
Band 3
MCS0/Nss1
149/157/165
1,2,3
802.11a/n HT40
Band 3
MCS0/Nss1
151/159
1,2,3
802.11ac VHT80
Band 3
MCS0/Nss1
42,155
N/A
11a BPSK
Band 1&3
6Mbps
36/40/48/149/157/165
1,2,3
802.11a/n HT20
Band 1&3
MCS0/Nss1
36/40/48/149/157/165
1,2,3
802.11a/n HT40
Band 1&3
MCS0/Nss1
38/46/151/159
1,2,3
802.11ac VHT80
Band 1&3
MCS0/Nss1
42/155
N/A
11a BPSK
Band 1&3
6Mbps
36/40/48/149/157/165
1,2,3
802.11a/n HT20
Band 1&3
MCS0/Nss1
36/40/48/149/157/165
1,2,3
802.11a/n HT40
Band 1&3
MCS0/Nss1
38/46/151/159
1,2,3
802.11ac VHT80
Band 1&3
MCS0/Nss1
42/155
N/A
20MHz
Band 1&3
40/157
1,2,3
40MHz
Band 1&3
38/151
1,2,3
80MHz
Band 1&3
42/155
N/A
Test Result of Occupied Bandwidth
Mode
Frequency 26 dB
6 dB Bandwidth 99% Occupied
Bandwidth (kHz) (kHz)
Bandwidth (kHz)
802.11b
2412 MHz N/A
802.11g
802.11n (HT20)
2437 MHz
N/A
2462 MHz
N/A
2412 MHz
N/A
2437 MHz
N/A
2462 MHz
N/A
2412 MHz
N/A
2437 MHz
N/A
2462 MHz
N/A
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 17 of 85
Testing
NVLAP Lab Code 200087-0
Mode
Frequency
802.11n (HT40)
2422 MHz
26 dB
6 dB Bandwidth 99% Occupied
Bandwidth (kHz) (kHz)
Bandwidth (kHz)
N/A
2447 MHz
N/A
2452 MHz
N/A
5180 MHz
22720 kHz
N/A
18360 kHz
5200 MHz
22760 kHz
N/A
18400 kHz
5240 MHz
22720 kHz
N/A
18360 kHz
5745 MHz
N/A
20440 kHz
18280 kHz
5785 MHz
N/A
20440 kHz
18400 kHz
5825 MHz
N/A
20440 kHz
18320 kHz
5180 MHz
22720 kHz
N/A
18360 kHz
5200 MHz
22760 kHz
N/A
18400 kHz
5240 MHz
22720 kHz
N/A
18360 kHz
5745 MHz
N/A
16400 kHz
18280 kHz
5785 MHz
N/A
16440 kHz
18400 kHz
5825 MHz
N/A
16400 kHz
18320 kHz
5190 MHz
47475 kHz
N/A
38250 kHz
5230 MHz
47775 kHz
N/A
38550 kHz
5755 MHz
N/A
36450 kHz
38400 kHz
5795 MHz
N/A
36450 kHz
38400 kHz
802.11ac VHT80
5210 MHz
N/A
N/A
N/A
802.11ac VHT80
5775 MHz
N/A
N/A
N/A
802.11a
802.11n (ht20)
802.11a/n MCS0/Nss1
HT40
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 18 of 85
Testing
NVLAP Lab Code 200087-0
Application for Certification
(1)
Manufacturer:
Mikrotikls SIA
Pernavas 46 Str.
Riga LV-1009 Latvia
(2)
Identification: Model: RB953GS-5HnT-RP-US
FCC I.D.: TV7RB953GS5HNTM
(3)
IC: 7442A-RB953GS5HNT
Instruction Book:
Refer to Exhibit for Instruction Manual.
(4)
Description of Circuit Functions:
Refer to Exhibit of Operational Description.
(5)
Block Diagram with Frequencies:
Refer to Exhibit of Operational Description.
(6)
Report of Measurements:
Report of measurements follows in this Report.
(7)
Photographs: Construction, Component Placement, etc.:
Refer to Exhibit for photographs of equipment.
(8)
List of Peripheral Equipment Necessary for operation. The equipment operates from power
received from authorized AC/DC power adapter. The EUT provides three Ethernet ports for
communications, serial, USB and 2 SFP interface ports and power. During testing, the EUT
was powered from the AC/DC power supply and connected to CPU through network cable.
(9)
Transition Provisions of 47CFR 15.37 are not requested
(10)
Not Applicable. The unit is not a scanning receiver.
(11)
Not Applicable. The EUT does not operate in the 59 – 64 GHz frequency band.
(12)
The equipment is not software defined and this section is not applicable.
(13)
Applications for certification of U-NII devices in the 5.15-5.35 GHz and the 5.47-5.85
GHz bands must include a high-level operational description of the security procedures
that control the radio frequency operating parameters and ensure that unauthorized
modifications cannot be made. The required information has been provided in
Operational Description Exhibit filed with the application.
(14)
Contain at least one drawing or photograph showing the test set-up for each of the
required types of tests applicable to the device for which certification is requested. These
drawings or photographs must show enough detail to confirm other information
contained in the test report. Any photographs used must be focused originals without
glare or dark spots and must clearly show the test configuration used. This information is
provided in this report and Test Setup Exhibits provided with the application filing.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 19 of 85
Testing
NVLAP Lab Code 200087-0
Applicable Standards & Test Procedures
The following information is submitted in accordance with e-CFR dated October 31, 2016, Part
2, Subpart J, Part 15, Subpart 15E, Industry Canada RSS-GEN issue 4, and RSS-247 Issue 2.
Test procedures used are the established Methods of Measurement of Radio-Noise Emissions as
described in ANSI C63.10-2013, KDB 662911 D01 v02r01, KDB 789033 D02 v01r03, KDB
926956 v02, RSS-247 Issue 2, and RSS-GEN Issue 4. The following information is submitted
for processing applications for Modular Equipment Certification.
Equipment Testing Procedures
AC Line Conducted Emission Test Procedure
Testing for the AC line-conducted emissions was performed as defined in ANSI C63.10-2013.
The test setup, including the EUT, was arranged in the test configurations as presented during
testing. The test configuration was placed on a 1 x 1.5-meter wooden bench, 0.8 meters high
located in a screen room. The power lines of the system were isolated from the power source
using a standard LISN with a 50-µHy choke. EMI was coupled to the spectrum analyzer through
a 0.1 µF capacitor internal to the LISN. The LISN was positioned on the floor beneath the
wooden bench supporting the EUT. The power lines and cables were draped over the back edge
of the table. Refer to diagram one showing typical test arrangement and photographs in exhibits
for EUT placement used during testing.
Radiated Emission Test Procedure
Radiated emission testing was performed as required on a CISPR 16-1-4 compliant OATS
and as specified in ANSI C63.10-2013 and applicable KDB documents. The EUT was
placed on a rotating 0.9 x 1.2-meter platform, elevated as required above the ground plane at
a distance of 3 meters from the FSM antenna. The table permitted orientation of the EUT in
each of three orthogonal axis positions if necessary. EMI energy was maximized by
equipment placement, raising and lowering the FSM antenna, changing the antenna
polarization, and by rotating the turntable. Each emission was maximized before data was
taken using a spectrum analyzer. The frequency spectrum from 9 kHz to 50,000 MHz was
searched for during preliminary investigation. Refer to diagrams two and three showing
typical test arrangement and photographs in the test setup exhibits for specific EUT
placement during testing.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 20 of 85
Testing
NVLAP Lab Code 200087-0
1. Interconnecting cables that hang closer than 40 cm to the ground plane shall be folded back
and forth in the center forming a bundle 30 cm to 40 cm long see (see 6.2.3.2).
2. The I/O cables that are not connected to an accessory shall be bundled in the center. The end
of the cable may be terminated, if required, using the correct terminating impedance. The
overall length shall not exceed 1 m (see 6.2.2).
3. EUT connected to one LISN. Unused LISN measuring port connectors shall be terminated in
50 Ω loads. LISN may be placed on top of, or immediately beneath, reference ground plane
(see 6.2.2 and 6.2.3).
3.1 All other equipment powered from additional LISN(s).
3.2 Multiple-outlet strip can be used for multiple power cords of non-EUT equipment.
3.3 LISN at least 80 cm from nearest part of EUT chassis
4. Non-EUT components of EUT system being tested
5. Rear of EUT, including peripherals, shall all be aligned and flush with edge of tabletop (see
6.2.3.2).
6. Edge of tabletop shall be 40 cm removed from a vertical conducting plane that is bonded to
the ground plane (see 6.2.2 for options).
7. Antenna may be integral or detachable. If detachable, the antenna shall be attached for this
test.
Diagram 1 Test arrangement for Conducted emissions
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 21 of 85
Testing
NVLAP Lab Code 200087-0
1. A LISN is optional for radiated measurements between 30 MHz and 1000 MHz but not
allowed for measurements below 30 MHz and above 1000 MHz (see 6.3.1). If used, then
connect EUT to one LISN. Unused LISN measuring port connectors shall be terminated in 50
Ω loads. The LISN may be placed on top of, or immediately beneath, the reference ground
plane (see 6.2.2 and 6.2.3.2).
1.1 LISN spaced at least 80 cm from nearest part of EUT chassis.
2. Antenna can be integral or detachable, depending on the EUT (see 6.3.1).
3. Interconnecting cables that hang closer than 40 cm to the ground plane shall be folded back
and forth in the center forming a bundle 30 cm to 40 cm long (see 6.3.1).
4. For emission measurements at or below 1 GHz, the table height shall be 80 cm. For emission
measurements above 1 GHz, the table height shall be 1.5 m for measurements, except as
otherwise specified (see 6.3.1 and 6.6.3.1).
Diagram 2 Test arrangement for radiated emissions of tabletop equipment
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 22 of 85
Testing
NVLAP Lab Code 200087-0
Appropriate
Frequency
Dependent
Antenna
0.8 – 1.5 m
Frequency: 9 kHz-30 MHz
Frequency: 30 MHz- 1 GHZ
Frequency: Above 1 GHz
Loop Antenna
Broadband Biconilog
Horn
RBW = 9 kHz
RBW = 120 kHz
RBW = 1 MHz
VBW = 30 kHz
VBW = 120 kHz
VBW = 1 MHz
Sweep time = Auto
Sweep time = Auto
Sweep time = Auto
Detector = PK, QP
Detector = PK, QP
Detector = PK, AV
Antenna Height 1m
Antenna Height 1-4m
Antenna Height 1-4m
Diagram 3 Test arrangement for radiated emissions tested on Open Area Test Site (OATS)
Test Site Locations
Conducted EMI
The AC power line conducted emissions testing performed in a shielded
screen room located at Rogers Labs, Inc., 4405 West 259th Terrace,
Louisburg, KS
Radiated EMI
The radiated emissions tests were performed at the 3 meters, Open Area
Test Site (OATS) located at Rogers Labs, Inc., 4405 West 259th Terrace,
Louisburg, KS
Site Registration
Refer to Annex for Site Registration Letters
NVLAP Accreditation
Lab code 200087-0
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 23 of 85
Testing
NVLAP Lab Code 200087-0
List of Test Equipment
A Rohde and Schwarz ESU40 and/or Hewlett Packard 8591EM was used as the measuring
device for the emissions testing of frequencies below 1 GHz. A Rohde and Schwarz ESU40
and/or Hewlett Packard 8562A Spectrum Analyzer was used as the measuring device for testing
the emissions at frequencies above 1 GHz. The analyzer settings used are described in the
following table. Refer to the appendix for a complete list of test equipment.
AC Line Conducted Emissions (0.150 -30 MHz)
RBW
AVG. BW
Detector Function
9 kHz
30 kHz
Peak / Quasi Peak
Emissions (30-1000 MHz)
RBW
AVG. BW
Detector Function
120 kHz
300 kHz
Peak / Quasi Peak
Emissions (Above 1000 MHz)
RBW
Video BW
Detector Function
100 kHz
100 kHz
Peak
1 MHz
1 MHz
Peak / Average
Equipment
LISN
Cable
Cable
Cable
Antenna
Antenna
Antenna
Antenna
Antenna
Antenna
Antenna
Antenna
Analyzer
Analyzer
Analyzer
Analyzer
Amplifier
Amplifier
Amplifier
Manufacturer
Model (SN)
FCC
FCC-LISN-50-2-10(1PA) (160611)
Time Microwave 750HF290-750 (L10M)
Belden
RG-58 (L1-CAT3-11509)
Belden
RG-58 (L2-CAT3-11509)
ARA
BCD-235-B (169)
EMCO
3147 (40582)
ETS-Lindgren
3117 (200389)
Com Power
AH-118 (10110)
Com Power
AH-840 (101046)
Com Power
AL-130 (121055)
Sunol
JB-6 (A100709)
EMCO
3143 (9607-1277)
HP
8591EM (3628A00871)
HP
8562A (3051A05950)
HP External Mixers11571, 11970
Rohde & Schwarz ESU40 (100108)
Com-Power
PA-010 (171003)
Com-Power
CPPA-102 (01254)
Com-Power
PAM-118A (551014)
Band
Cal Date
.15-30MHz
5/16
9kHz-40 GHz 10/16
9kHz-30 MHz 10/16
9kHz-30 MHz 10/16
20-350MHz 10/16
200-1000MHz 10/16
1-18 GHz
5/16
1-18 GHz
10/15
18-40 GHz
5/16
.001-30 MHz 10/16
30-1000 MHz 10/16
20-1200 MHz 5/16
9kHz-1.8GHz 5/16
9kHz-110GHz 5/16
25GHz-110GHz5/16
20Hz-40GHz 5/16
100Hz-30MHz 10/16
1-1000 MHz 10/16
0.5-18 GHz
10/16
Due
5/17
10/17
10/17
10/17
10/17
10/17
5/18
10/17
5/18
10/17
10/17
5/17
5/17
5/17
5/17
5/17
10/17
10/17
10/17
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 24 of 85
Testing
NVLAP Lab Code 200087-0
Units of Measurements
Conducted EMI
Data is in dBµV; dB referenced to one microvolt
Radiated EMI
Data is in dBµV/m; dB/m referenced to one microvolt per meter
Sample Calculation:
RFS = Radiated Field Strength, FSM = Field Strength Measured
A.F. = Receive antenna factor, Gain = amplification gains and/or cable losses
RFS (dBµV/m @ 3m) = FSM (dBµV) + A.F. (dB) - Gain (dB)
Environmental Conditions
Ambient Temperature
22.2° C
Relative Humidity
46%
Atmospheric Pressure
1005.1 mb
Intentional Radiators
As per 47CFR part 15 paragraph 15.212, subpart E and Industry Canada RSS-247 Issue 2, the
following information is submitted for consideration and demonstration of compliance with
regulation and standards.
Antenna Requirements
The EUT incorporates reverse polarity SMA antenna ports for OEM use. The design requires
the OEM to either provide permanently attached antenna systems or professional installation.
Therefore, the design complies with the unique antenna connection requirements. The
requirements of 15.203 are fulfilled there are no deviations or exceptions to the specification.
Restricted Bands of Operation
Spurious emissions falling in the restricted frequency bands of operation were measured on the
OATS. The EUT utilizes frequency, determining circuitry, which generates harmonics falling
in restricted bands. Emissions were investigated while the EUT was located on the OATS using
appropriate antennas or pyramidal horns, amplification stages, and spectrum analyzer receiver.
Peak and average amplitudes of frequencies above 1000 MHz were compared to the required
limits with worst-case data presented below. Test procedures of ANSI C63.10-2013 were used
during testing. No other significant emission was observed which fell into the restricted bands
of operation. Computed radiated emission values consider the measured radiated field strength,
receive antenna correction factor, amplifier gain stage, and test system cable losses.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 25 of 85
Testing
NVLAP Lab Code 200087-0
Table 1 Radiated Emissions in Restricted Bands Data (MT-482016/N/A)
Frequency in
MHz
Horizontal
Peak
(dBµV/m)
Horizontal
Quasi-Peak
(dBµV/m)
Horizontal
Average
(dBµV/m)
Vertical
Peak
(dBµV/m)
Vertical
Quasi-Peak
(dBµV/m)
Vertical
Average
(dBµV/m)
Limit @ 3m
(dBµV/m)
U-NII-1 Operation Worst-case
5150.0
43.9
N/A
30.8
56.1
N/A
36.6
54.0
5350.0
43.9
N/A
31.0
47.0
N/A
34.1
54.0
10360.0
53.3
N/A
40.1
52.8
N/A
40.1
54.0
10400.0
53.4
N/A
40.7
53.0
N/A
40.3
54.0
10480.0
51.5
N/A
38.6
52.5
N/A
39.0
54.0
20720.0
52.5
N/A
39.6
53.1
N/A
39.6
54.0
U-NII-3 Operation 802.11a
11490.0
53.5
N/A
40.0
52.4
N/A
39.4
54.0
11570.0
52.5
N/A
39.7
52.7
N/A
40.3
54.0
11650.0
53.3
N/A
40.1
54.3
N/A
41.1
54.0
22980.0
53.3
N/A
40.7
53.8
N/A
40.8
54.0
Other emissions present had amplitudes at least 20 dB below the limit. Peak and Quasi-Peak
amplitude emissions are recorded above for frequency range below 1000 MHz. Peak and
Average amplitude emissions are recorded above for frequency range above 1000 MHz.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 26 of 85
Testing
NVLAP Lab Code 200087-0
Table 2 Radiated Emissions in Restricted Bands Data (PA58-24-ANT)
Frequency in
MHz
Horizontal
Peak
(dBµV/m)
Horizontal
Quasi-Peak
(dBµV/m)
Horizontal
Average
(dBµV/m)
Vertical
Peak
(dBµV/m)
Vertical
Quasi-Peak
(dBµV/m)
Vertical
Average
(dBµV/m)
Limit @ 3m
(dBµV/m)
U-NII-1 Operation Worst-case
5150.0
50.5
N/A
34.4
66.7
N/A
46.2
54.0
5350.0
45.9
N/A
33.0
57.4
N/A
44.3
54.0
10360.0
53.7
N/A
40.1
53.3
N/A
40.1
54.0
10400.0
52.8
N/A
40.2
55.2
N/A
41.9
54.0
10480.0
52.2
N/A
38.8
51.5
N/A
38.7
54.0
20720.0
52.5
N/A
39.6
52.5
N/A
39.6
54.0
U-NII-3 Operation 802.11a
11490.0
53.3
N/A
40.0
53.2
N/A
39.9
54.0
11570.0
52.5
N/A
39.6
52.3
N/A
39.6
54.0
11650.0
53.1
N/A
39.9
52.9
N/A
39.9
54.0
22980.0
54.1
N/A
40.8
53.8
N/A
40.9
54.0
Other emissions present had amplitudes at least 20 dB below the limit. Peak and Quasi-Peak
amplitude emissions are recorded above for frequency range below 1000 MHz. Peak and
Average amplitude emissions are recorded above for frequency range above 1000 MHz.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 27 of 85
Testing
NVLAP Lab Code 200087-0
Table 3 Radiated Emissions in Restricted Bands Data (HDDA5W-32-DP2)
Frequency in
MHz
Horizontal
Peak
(dBµV/m)
Horizontal
Quasi-Peak
(dBµV/m)
Horizontal
Average
(dBµV/m)
Vertical
Peak
(dBµV/m)
Vertical
Quasi-Peak
(dBµV/m)
Vertical
Average
(dBµV/m)
Limit @ 3m
(dBµV/m)
U-NII-1 Operation Worst-case
5150.0
47.2
N/A
34.1
65.2
N/A
47.0
54.0
5350.0
48.0
N/A
34.7
58.1
N/A
45.0
54.0
10360.0
53.0
N/A
40.0
53.1
N/A
40.1
54.0
10400.0
53.2
N/A
40.2
53.3
N/A
40.3
54.0
10480.0
52.3
N/A
38.5
51.8
N/A
38.8
54.0
20720.0
52.6
N/A
39.6
52.7
N/A
39.6
54.0
U-NII-3 Operation 802.11a
11490.0
52.8
N/A
39.9
52.2
N/A
39.9
54.0
11570.0
52.7
N/A
39.5
52.5
N/A
39.3
54.0
11650.0
53.1
N/A
40.3
53.2
N/A
39.9
54.0
22980.0
53.7
N/A
40.8
53.6
N/A
39.9
54.0
Other emissions present had amplitudes at least 20 dB below the limit. Peak and Quasi-Peak
amplitude emissions are recorded above for frequency range below 1000 MHz. Peak and
Average amplitude emissions are recorded above for frequency range above 1000 MHz.
Summary of Results for Radiated Emissions in Restricted Bands
The EUT demonstrated compliance with the emissions requirements of 47CFR 15.205,
RSS-GEN and RSS-247 Issue 2 Intentional Radiators. The EUT provided a worst-case
minimum margin of -7.0 dB below the emissions requirements in restricted frequency bands.
Peak, Quasi-peak, and average amplitudes were checked for compliance with the regulations.
Worst-case emissions are reported with other emissions found in the restricted frequency
bands at least 20 dB below the requirements.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 28 of 85
Testing
NVLAP Lab Code 200087-0
AC Line Conducted Emissions Procedure
The EUT was arranged in a typical equipment configuration and placed on a 1 x 1.5-meter
wooden bench 80 cm above the conducting ground plane, floor of a screen room. The bench
was positioned 40 cm away from the wall of the screen room. The LISN was positioned on
the floor of the screen room 80-cm from the rear of the EUT. The manufacturer supplied
supporting equipment AC/DC adapter provided direct current power to the POE, which
routed power to the EUT, was connected to the LISN. A second LISN was positioned on the
floor of the screen room 80-cm from the rear of the supporting equipment of the EUT. All
power cords except the EUT were then powered from the second LISN. EMI was coupled to
the spectrum analyzer through a 0.1 μf capacitor, internal to the LISN. Power line conducted
emissions testing were carried out individually for each current carrying conductor of the
EUT. The excess length of lead between the system and the LISN receptacle was folded
back and forth to form a bundle not exceeding 40 cm in length. The screen room, conducting
ground plane, analyzer, and LISN were bonded together to the protective earth ground.
Preliminary testing was performed to identify the frequency of each emission displaying the
highest amplitude. The cables were repositioned to obtain maximum amplitude of measured
EMI level. Once the worst-case configuration was identified, plots were made of the EMI
from 0.15 MHz to 30 MHz then the data was recorded with maximum conducted emissions
levels. Refer to figures one and two for plots of the EUT AC Line Conducted emissions.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 29 of 85
Testing
NVLAP Lab Code 200087-0
Figure 1 AC Line Conducted Emissions Line 1
Figure 2 AC Line Conducted Emissions Line 2
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 30 of 85
Testing
NVLAP Lab Code 200087-0
Table 4 AC Line Conducted Emissions Data (Highest Emissions Line L1)
Other emissions present had amplitudes at least 20 dB below the limit.
Table 5 AC Line Conducted Emissions Data (Highest Emissions Line L2)
Other emissions present had amplitudes at least 20 dB below the limit.
Summary of Results for AC Line Conducted Emissions
The EUT test system demonstrated compliance to the conducted emissions requirements of
47CFR 15.207, RSS-247 Issue 2 and RSS-GEN. The EUT demonstrated minimum margin
of –9.2 dB below the limit. Measurements were taken using the peak, quasi peak, and
average, measurement function for each emissions amplitude and were below the limits
stated in the specification. Other emissions were present with recorded data representing
worst-case amplitudes.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 31 of 85
Testing
NVLAP Lab Code 200087-0
General Radiated Emissions Procedure
The EUT was arranged in a typical equipment configuration and operated through all
available modes with worst-case data recorded. Preliminary testing was performed in a
screen room with the EUT positioned 1 meter from the FSM. Radiated emissions
measurements were performed to identify the frequencies, which produced the highest
emissions. Each radiated emission was then maximized at the OATS location before final
radiated emissions measurements were performed. Final data was taken with the EUT
located at the OATS at a distance of 3 meters between the EUT and the receiving antenna.
The frequency spectrum from 9 kHz to 60,000 MHz was searched for general radiated
emissions. Measured emission levels were maximized by EUT placement on the table,
rotating the turntable through 360 degrees, varying the antenna height between 1 and 4
meters above the ground plane and changing antenna position between horizontal and
vertical polarization. Antennas used were Loop from 9 kHz to 30 MHz, Broadband
Biconical from 30 to 200 MHz, Biconilog from 30 to 1000 MHz, Log Periodic from 200
MHz to 1 GHz and or Double Ridge or pyramidal horns and mixers above 1 GHz, notch
filters, and appropriate amplifiers and external mixers were utilized.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 32 of 85
Testing
NVLAP Lab Code 200087-0
Table 6 General Radiated Emissions from EUT Data (Highest Emissions)
Frequency in
MHz
Horizontal
Peak
(dBµV/m)
Horizontal
Quasi-Peak
(dBµV/m)
Horizontal
Average
(dBµV/m)
Vertical
Peak
(dBµV/m)
Vertical
Quasi-Peak
(dBµV/m)
Vertical
Average
(dBµV/m)
Limit @ 3m
125.0
33.8
30.4
N/A
30.6
25.4
N/A
43.5
131.2
31.5
17.4
N/A
37.7
20.5
N/A
43.5
167.1
28.0
20.9
N/A
27.0
18.9
N/A
43.5
184.7
34.7
25.6
N/A
31.2
21.9
N/A
43.5
186.5
31.1
24.7
N/A
29.0
19.9
N/A
43.5
192.4
34.7
29.3
N/A
26.1
20.7
N/A
43.5
201.0
39.3
29.2
N/A
34.3
23.5
N/A
43.5
250.0
28.1
26.2
N/A
27.0
24.3
N/A
46.0
1374.9
53.5
N/A
52.3
51.9
N/A
50.2
54.0
(dBµV/m)
Other emissions present had amplitudes at least 20 dB below the limit. Peak and Quasi-Peak
amplitude emissions are recorded above for frequency range below 1000 MHz. Peak and
Average amplitude emissions are recorded above for frequency range above 1000 MHz.
Summary of Results for General Radiated Emissions
The EUT demonstrated compliance with the radiated emissions requirements of 47CFR part
15 and Industry Canada RSS-247 Issue 2 Intentional Radiators. The EUT demonstrated a
minimum margin of –1.7 dB below the requirements. Other emissions were present with
amplitudes at least 20 dB below the Limits.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 33 of 85
Testing
NVLAP Lab Code 200087-0
Operation in the 5150-5250 and 5725-5850 MHz Frequency U-NII-1 and U-NII-3 Bands
Testing followed FCC KDB 789033 D02 General U-NII Test Procedures New Rules v01r03.
The test sample provided direct connection to the antenna ports. A power meter was used to
measure fundamental transmitter output power. A spectrum analyzer / receiver was used to produce
plots and make other antenna port conducted measurements for compliance testing. Test software
(Winbox version 3.10) was used to operate the transmitter. This software provided the ability to set
test channel, operational mode, and modulation scheme. The test antenna ports were connected to
coaxial cable with 50-ohm attenuator and receiver, spectrum analyzer, or power meter during
testing. Radiated emissions testing was performed with the bare board module test sample placed
on a turntable elevated as required above the ground plane at 3-meters distance from the FSM
antenna located on the OATS. The peak and quasi-peak amplitude of the frequencies below 1000
MHz were measured using a spectrum analyzer. The peak and average amplitude of emissions
above 1000 MHz were measured using a spectrum analyzer. Emissions data was recorded from the
measurement results. Data presented reflects measurement result corrected to account for
measurement system gains and losses. Plots were made of transmitter performance for reference
and demonstration of compliance.
In addition, all Manufacturers of U-NII devices are responsible for ensuring frequency stability
such that an emission is maintained within the band of operation under all conditions of normal
operation as specified in the user’s manual. The manufacturer has attested the equipment
operates within the required frequency spectrum under normal operational conditions. The
design provides three transmitter chains and antenna port connections with operational
capabilities in 2 frequency bands (5180-5240 MHz and 5745-5825 MHz). This report
documents emissions governed under the new rules for U-NII-1 and U-NII-3 bands operating in
the 5180-5240 and 5745-5825 MHz frequency bands.
The design provides 3 transmitter chains which may be which may be correlated. Summing the
gain of the highest gain antenna system (32 dBi) would provide for 36.7 dBi gain (Directional
gain = GANT + 10 log (NANT) dBi = 32 +10 log (3) = 32 + 4.7 = 36.7 dBi
OEM and professional installers are instructed to place antenna gain values in the manufacturer
controlled software, which reduces the transmitter out power to compliant levels as presented in
the operational description and attestation letter.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 34 of 85
Testing
NVLAP Lab Code 200087-0
Per 15.407 Technical Requirements
(a) power limitations
(1) For the Band 5.15-5.25 GHz
(i) For an outdoor access point operating in the band 5.15-5.25 GHz, the maximum conducted
output power over the frequency band of operation shall not exceed 1 W provided the
maximum antenna gain does not exceed 6 dBi. In addition, the maximum power spectral
density shall not exceed 17 dBm in any 1 megahertz band. If transmitting antennas of
directional gain greater than 6 dBi are used, both the maximum conducted output power
and the maximum power spectral density shall be reduced by the amount in dB that the
directional gain of the antenna exceeds 6 dBi. The maximum e.i.r.p. at any elevation angle
above 30 degrees as measured from the horizon must not exceed 125 mW (21 dBm).
Per KDB 789033 D02 General UNII Test Procedures New Rules v01r03, Section II
H. Measurement of emission at elevation angle higher than 30° from horizon.
This restriction leads to a general requirement for the antenna pattern: if the EIRP within 3-dB elevation
beamwidth of any radiation lobe is higher than 125 mW, this lobe must be controlled, either mechanically
or electrically, so that the 3-dB elevation beamwidth of this lobe is below 30° elevation angle relative to
horizon.
For the purposes of compliance, information for all the antenna types must be included in the filing.
For antennas to be considered of similar type, the antenna patterns must also be similar as well as other
characteristics of the antenna. Antenna information has been included in the application in support of this
requirement.
Note: For the sake of clarity, we define the elevation angle where 0° is horizontal and 90° is straight-up.
1. For fixed infrastructure, not electrically or mechanically steerable beam antenna
a) If elevation plane radiation pattern is available:
I) Determine the device intended mounting elevation angle and define 0° reference angle on the
elevation plane radiation pattern.
ii) Indicate any radiation pattern between 30° and 90° which has highest gain.
iii) Calculate the EIRP based on this highest gain and conducted output power.
iv) Compare to the limit of 125 mW to find compliance.
v) Include the elevation pattern data in the application filing with the test report to show how the
calculations are made.
b) If elevation plane radiation pattern is not available, but the antenna type (such as dipole
omnidirectional, Yagi, parabolic, or sector antenna) has symmetrical elevation plane pattern
referenced at main beam and all lobes on the main beam elevation plane have highest gains, then the
following measurement method is acceptable to determine compliance:
(i) Determine the device’s intended mounting elevation angle referenced to the horizon.
(ii) Rotate EUT antenna by 90° around the main beam axis in horizontal position to transform
measurement in elevation angle into azimuth angle and define 0° reference angle based on
device’s intended mounting elevation angle.
(iii) Move test antenna along the horizontal arc, or rotate the turn table with EUT antenna placed at
the center, between 30° and 90° relative to the 0° reference angle, and then continuing down
from 90° to 30° on the other side of the pattern, while maintaining the test antenna pointing
with constant distance to the EUT antenna and search for the spot which has the highest
measured emission. Both horizontal and vertical polarization shall be investigated to find out
the maximum radiated emission level.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 35 of 85
Testing
NVLAP Lab Code 200087-0
Note: Moving of test antenna along the horizontal arc, or rotating the turn table, shall be
performed in angular step size as small as possible, but not larger than 3°.
(iv) Calculate the EIRP based on the highest measured emission and compare to the limit of 125
mW to determine compliance.
(v) The antenna pattern measurements should be included in the filing.
Elevation Compliance Omni Directional (8.5 dBi) MT-482016/N/A
Elevation Radiation Pattern indicates no additional reduction would be required for use with this
antenna. The transmitter output power provides 13 dBm and the antenna gain reduces the output
power by 18 or greater dBi at elevations 30 degrees above the horizon. This provides power
levels below the 21 dBm requirement without additional attenuation.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 36 of 85
Testing
NVLAP Lab Code 200087-0
Elevation Compliance Panel Antenna (24 dBi) PA58-24-ANT
Elevation Radiation Pattern indicates no additional reduction would be required for use with this
antenna. The transmitter output power provides 13 dBm and the antenna gain provides a
maximum of 8 dBi gain at elevations 30 degrees above the horizon. This would not provide
output power exceeding the 21 dBm requirement. This configuration would not require
additional attenuation to comply with the 21 dBm requirement.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 37 of 85
Testing
NVLAP Lab Code 200087-0
Elevation Compliance Dish Antenna (32 dBi) HDDA5W-32-DP2
Elevation Radiation Pattern indicates no additional reduction would be required for use with this
antenna. The transmitter output power provides 13 dBm and the antenna gain provides a
maximum of 0 dBi gain at elevations 30 degrees above the horizon. This would not provide
output power exceeding the 21 dBm requirement. This configuration would not require
additional attenuation to comply with the 21 dBm requirement.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 38 of 85
Testing
NVLAP Lab Code 200087-0
Figure 3 Plot of Transmitter Emissions (Chain 0, Across 5150-5250 MHz Band, 802.11a)
Figure 4 Plot of Transmitter Emissions (Chain 1, Across 5150-5250 MHz Band, 802.11a)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 39 of 85
Testing
NVLAP Lab Code 200087-0
Figure 5 Plot of Transmitter Emissions (Chain 2, Across 5150-5250 MHz Band, 802.11a)
Figure 6 Plot of Transmitter Emissions (Chain 0, Across 5150-5250 MHz Band, 802.11n40)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 40 of 85
Testing
NVLAP Lab Code 200087-0
Figure 7 Plot of Transmitter Emissions (Chain 1, Across 5150-5250 MHz Band, 802.11n40)
Figure 8 Plot of Transmitter Emissions (Chain 2, Across 5150-5250 MHz Band, 802.11n40)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 41 of 85
Testing
NVLAP Lab Code 200087-0
Figure 9 Plot of Transmitter Low Band Edge (Chain 0, 5150-5250 MHz Band, 802.11a)
Figure 10 Plot of Transmitter Low Band Edge (Chain 1, 5150-5250 MHz Band, 802.11a)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 42 of 85
Testing
NVLAP Lab Code 200087-0
Figure 11 Plot of Transmitter Low Band Edge (Chain 2, 5150-5250 MHz Band, 802.11a)
Figure 12 Plot of Transmitter Low Band Edge (Chain 0, 5150-5250 MHz Band, 802.11n40)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 43 of 85
Testing
NVLAP Lab Code 200087-0
Figure 13 Plot of Transmitter Low Band Edge (Chain 1, 5150-5250 MHz Band, 802.11n40)
Figure 14 Plot of Transmitter Low Band Edge (Chain 2, 5150-5250 MHz Band, 802.11n40)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 44 of 85
Testing
NVLAP Lab Code 200087-0
Figure 15 Plot of Transmitter High Band Edge (Chain 0, 5150-5250 MHz Band, 802.11a)
Figure 16 Plot of Transmitter High Band Edge (Chain 1, 5150-5250 MHz Band, 802.11a)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 45 of 85
Testing
NVLAP Lab Code 200087-0
Figure 17 Plot of Transmitter High Band Edge (Chain 2, 5150-5250 MHz Band, 802.11a)
Figure 18 Plot of Transmitter High Band Edge (Chain 0, 5150-5250 MHz Band, 802.11n40)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 46 of 85
Testing
NVLAP Lab Code 200087-0
Figure 19 Plot of Transmitter High Band Edge (Chain 1, 5150-5250 MHz Band, 802.11n40)
Figure 20 Plot of Transmitter High Band Edge (Chain 2, 5150-5250 MHz Band, 802.11n40)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 47 of 85
Testing
NVLAP Lab Code 200087-0
Figure 21 Plot of Transmitter Emissions (Chain 0, 5150-5250 MHz Band, 802.11a, 99% OBW)
Figure 22 Plot of Transmitter Emissions (Chain 1, 5150-5250 MHz Band, 802.11a, 99% OBW)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 48 of 85
Testing
NVLAP Lab Code 200087-0
Figure 23 Plot of Transmitter Emissions (Chain 2, 5150-5250 MHz Band, 802.11a, 99% OBW)
Figure 24 Plot of Transmitter Emissions (Chain 0, 5150-5250 MHz Band, 802.11a, 26 dB OBW)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 49 of 85
Testing
NVLAP Lab Code 200087-0
Figure 25 Plot of Transmitter Emissions (Chain 1, 5150-5250 MHz Band, 802.11a, 26 dB OBW)
Figure 26 Plot of Transmitter Emissions (Chain 2, 5150-5250 MHz Band, 802.11a, 26 dB OBW)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 50 of 85
Testing
NVLAP Lab Code 200087-0
Figure 27 Plot of Transmitter Emissions (Chain 0, 5150-5250 MHz Band, 802.11n40, 99% OBW)
Figure 28 Plot of Transmitter Emissions (Chain 1, 5150-5250 MHz Band, 802.11n40, 99% OBW)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 51 of 85
Testing
NVLAP Lab Code 200087-0
Figure 29 Plot of Transmitter Emissions (Chain 2, 5150-5250 MHz Band, 802.11n40, 99% OBW)
Figure 30 Plot of Transmitter Emissions (Chain 0, 5150-5250 MHz Band, 802.11n40, 26 dB OBW)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 52 of 85
Testing
NVLAP Lab Code 200087-0
Figure 31 Plot of Transmitter Emissions (Chain 1, 5150-5250 MHz Band, 802.11n40, 26 dB OBW)
Figure 32 Plot of Transmitter Emissions (Chain 2, 5150-5250 MHz Band, 802.11n40, 26 dB OBW)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 53 of 85
Testing
NVLAP Lab Code 200087-0
Figure 33 Plot of Transmitter Emissions (Chain 0, Across 5725-5850 MHz Band, 802.11a)
Figure 34 Plot of Transmitter Emissions (Chain 1, Across 5725-5850 MHz Band, 802.11a)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 54 of 85
Testing
NVLAP Lab Code 200087-0
Figure 35 Plot of Transmitter Emissions (Chain 2, Across 5725-5850 MHz Band, 802.11a)
Figure 36 Plot of Transmitter Emissions (Chain 0, Across 5725-5850 MHz Band, 802.11n40)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 55 of 85
Testing
NVLAP Lab Code 200087-0
Figure 37 Plot of Transmitter Emissions (Chain 1, Across 5725-5850 MHz Band, 802.11n40)
Figure 38 Plot of Transmitter Emissions (Chain 2, Across 5725-5850 MHz Band, 802.11n40)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 56 of 85
Testing
NVLAP Lab Code 200087-0
Figure 39 Plot of Transmitter Low Band Edge (Chain 0, 5725-5850 MHz Band, 802.11a)
Figure 40 Plot of Transmitter Low Band Edge (Chain 1, 5725-5850 MHz Band, 802.11a)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 57 of 85
Testing
NVLAP Lab Code 200087-0
Figure 41 Plot of Transmitter Low Band Edge (Chain 2, 5725-5850 MHz Band, 802.11a)
Figure 42 Plot of Transmitter Low Band Edge (Chain 0, 5725-5850 MHz Band, 802.11n40)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 58 of 85
Testing
NVLAP Lab Code 200087-0
Figure 43 Plot of Transmitter Low Band Edge (Chain 1, 5725-5850 MHz Band, 802.11n40)
Figure 44 Plot of Transmitter Low Band Edge (Chain 2, 5725-5850 MHz Band, 802.11n40)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 59 of 85
Testing
NVLAP Lab Code 200087-0
Figure 45 Plot of Transmitter High Band Edge (Chain 0, 5725-5850 MHz Band, 802.11a)
Figure 46 Plot of Transmitter High Band Edge (Chain 1, 5725-5850 MHz Band, 802.11a)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 60 of 85
Testing
NVLAP Lab Code 200087-0
Figure 47 Plot of Transmitter High Band Edge (Chain 2, 5725-5850 MHz Band, 802.11a)
Figure 48 Plot of Transmitter High Band Edge (Chain 0, 5725-5850 MHz Band, 802.11n40)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 61 of 85
Testing
NVLAP Lab Code 200087-0
Figure 49 Plot of Transmitter High Band Edge (Chain 1, 5725-5850 MHz Band, 802.11n40)
Figure 50 Plot of Transmitter High Band Edge (Chain 2, 5725-5850 MHz Band, 802.11n40)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 62 of 85
Testing
NVLAP Lab Code 200087-0
Figure 51 Plot of Transmitter Emissions (Chain 0, 5725-5850 MHz Band, 802.11a, 99% OBW)
Figure 52 Plot of Transmitter Emissions (Chain 1, 5725-5850 MHz Band, 802.11a, 99% OBW)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 63 of 85
Testing
NVLAP Lab Code 200087-0
Figure 53 Plot of Transmitter Emissions (Chain 2, 5725-5850 MHz Band, 802.11a, 99% OBW)
Figure 54 Plot of Transmitter Emissions (Chain 0, 5725-5850 MHz Band, 802.11a, 6-dB OBW)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 64 of 85
Testing
NVLAP Lab Code 200087-0
Figure 55 Plot of Transmitter Emissions (Chain 1, 5725-5850 MHz Band, 802.11a, 6-dB OBW)
Figure 56 Plot of Transmitter Emissions (Chain 2, 5725-5850 MHz Band, 802.11a, 6-dB OBW)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 65 of 85
Testing
NVLAP Lab Code 200087-0
Figure 57 Plot of Transmitter Emissions (Chain 0, 5725-5850 MHz Band, 802.11n40, 99% OBW)
Figure 58 Plot of Transmitter Emissions (Chain 1, 5725-5850 MHz Band, 802.11n40, 99% OBW)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 66 of 85
Testing
NVLAP Lab Code 200087-0
Figure 59 Plot of Transmitter Emissions (Chain 2, 5725-5850 MHz Band, 802.11n40, 99% OBW)
Figure 60 Plot of Transmitter Emissions (Chain 0, 5725-5850 MHz Band, 802.11n40, 6-dB OBW)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 67 of 85
Testing
NVLAP Lab Code 200087-0
Figure 61 Plot of Transmitter Emissions (Chain 1, 5725-5850 MHz Band, 802.11n40, 6-dB OBW)
Figure 62 Plot of Transmitter Emissions (Chain 2, 5725-5850 MHz Band, 802.11n40, 6-dB OBW)
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 68 of 85
Testing
NVLAP Lab Code 200087-0
Transmitter Emissions Data
Table 7 Transmitter Radiated Emission (5150-5250 MHz Band, MT-482016/N/A)
Frequency in
MHz
Horizontal
Peak (dBµV/m)
Horizontal
Average (dBµV/m)
Vertical Peak
(dBµV/m)
Vertical Average
(dBµV/m)
Limit @ 3m
(dBµV/m)
20 MHz Channel
5180.0
--
--
--
--
--
10360.0
53.3
40.1
52.8
40.1
68.3
15540.0
56.4
43.3
56.9
43.5
68.3
20720.0
52.5
39.6
53.1
39.6
68.3
25900.0
54.9
41.2
54.5
41.4
68.3
5220.0
--
--
--
--
--
10440.0
53.4
40.7
53.0
40.3
68.3
15660.0
55.2
42.8
56.4
43.1
68.3
20880.0
51.5
39.1
52.5
39.1
68.3
26100.0
55.3
42.5
56.1
42.5
68.3
5240.0
--
--
--
--
--
10480.0
51.5
38.6
52.5
39.0
68.3
15720.0
56.6
44.1
57.2
44.5
68.3
20960.0
52.3
39.5
52.2
39.3
68.3
26200.0
54.9
42.1
55.1
42.1
68.3
Band Edges
5150.0
43.9
30.8
56.1
36.6
54.0
5350.0
43.9
31.0
47.0
34.1
54.0
Other emissions present had amplitudes at least 20 dB below the limit. Peak and Quasi-Peak
amplitude emissions are recorded above for frequency range of 30-1000 MHz. Peak and
Average amplitude emissions are recorded above for frequency range above 1000 MHz.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 69 of 85
Testing
NVLAP Lab Code 200087-0
Table 8 Transmitter Radiated Emission (5150-5250 MHz Band, PA58-24-ANT)
Frequency in
MHz
Horizontal
Peak (dBµV/m)
Horizontal
Average (dBµV/m)
Vertical Peak
(dBµV/m)
Vertical Average
(dBµV/m)
Limit @ 3m
(dBµV/m)
20 MHz Channel
5180.0
--
--
--
--
--
10360.0
53.7
40.1
53.3
40.1
68.3
15540.0
56.0
43.0
56.7
43.2
68.3
20720.0
52.5
39.6
52.5
39.6
68.3
25900.0
55.2
41.8
55.3
41.9
68.3
5220.0
--
--
--
--
--
10440.0
52.8
40.2
55.2
41.9
68.3
15660.0
55.5
42.6
53.2
40.4
68.3
20880.0
51.9
39.1
51.9
39.1
68.3
26100.0
56.2
42.4
56.1
42.5
68.3
5240.0
--
--
--
--
--
10480.0
52.2
38.8
51.5
38.7
68.3
15720.0
57.6
44.2
57.1
44.4
68.3
20960.0
52.1
39.6
52.2
39.4
68.3
26200.0
55.2
42.1
55.2
42.1
68.3
Band Edges
5150.0
50.5
34.4
66.7
46.2
54.0
5350.0
45.9
33.0
57.4
44.3
54.0
Other emissions present had amplitudes at least 20 dB below the limit. Peak and Quasi-Peak
amplitude emissions are recorded above for frequency range of 30-1000 MHz. Peak and
Average amplitude emissions are recorded above for frequency range above 1000 MHz.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 70 of 85
Testing
NVLAP Lab Code 200087-0
Table 9 Transmitter Radiated Emission (5150-5250 MHz Band, HDDA5W-32-DP2)
Frequency in
MHz
Horizontal
Peak (dBµV/m)
Horizontal
Average (dBµV/m)
Vertical Peak
(dBµV/m)
Vertical Average
(dBµV/m)
Limit @ 3m
(dBµV/m)
20 MHz Channel
5180.0
--
--
--
--
--
10360.0
53.0
40.0
53.1
40.1
68.3
15540.0
56.9
43.2
55.8
43.1
68.3
20720.0
52.6
39.6
52.7
39.6
68.3
25900.0
54.5
41.8
55.7
41.9
68.3
5220.0
--
--
--
--
--
10440.0
53.2
40.2
53.3
40.3
68.3
15660.0
56.1
42.8
55.4
42.6
68.3
20880.0
52.3
39.1
52.7
39.1
68.3
26100.0
55.6
42.3
55.4
42.4
68.3
5240.0
--
--
--
--
--
10480.0
52.3
38.5
51.8
38.8
68.3
15720.0
57.4
44.3
58.4
44.3
68.3
20960.0
52.6
39.4
52.2
39.4
68.3
26200.0
55.4
42.2
55.2
42.1
68.3
Band Edges
5150.0
47.2
34.1
65.2
47.0
54.0
5350.0
48.0
34.7
58.1
45.0
54.0
Other emissions present had amplitudes at least 20 dB below the limit. Peak and Quasi-Peak
amplitude emissions are recorded above for frequency range of 30-1000 MHz. Peak and
Average amplitude emissions are recorded above for frequency range above 1000 MHz.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 71 of 85
Testing
NVLAP Lab Code 200087-0
Table 10 Transmitter Radiated Emission (5725-5850 MHz Band, MT-482016/N/A)
Frequency in
MHz
Horizontal
Peak (dBµV/m)
Horizontal
Average (dBµV/m)
Vertical Peak
(dBµV/m)
Vertical Average
(dBµV/m)
Limit @ 3m
(dBµV/m)
20 MHz Channel
5745.0
--
--
--
--
--
11490.0
53.5
40.0
52.4
39.4
68.3
17235.0
58.7
45.7
58.3
45.6
68.3
22980.0
53.3
40.7
53.8
40.8
68.3
28725.0
56.2
43.3
56.9
43.3
68.3
5785.0
--
--
--
--
--
11570.0
52.5
39.7
52.7
40.3
68.3
17355.0
57.3
44.1
57.7
44.7
68.3
23140.0
53.6
40.7
53.9
40.8
68.3
28925.0
56.9
43.4
56.5
43.4
68.3
5825.0
--
--
--
--
--
11650.0
53.3
40.1
54.3
41.1
68.3
17475.0
57.0
43.6
57.4
44.9
68.3
23300.0
54.1
40.2
53.8
40.4
68.3
29125.0
56.6
43.6
56.4
43.5
68.3
Band Edges
5725.0
44.1
31.2
47.4
32.3
78.2
5850.0
44.2
31.5
49.0
35.4
78.2
Other emissions present had amplitudes at least 20 dB below the limit. Peak and Quasi-Peak
amplitude emissions are recorded above for frequency range of 30-1000 MHz. Peak and
Average amplitude emissions are recorded above for frequency range above 1000 MHz.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 72 of 85
Testing
NVLAP Lab Code 200087-0
Table 11 Transmitter Radiated Emission (5725-5850 MHz Band, PA58-24-ANT)
Frequency in
MHz
Horizontal
Peak (dBµV/m)
Horizontal
Average (dBµV/m)
Vertical Peak
(dBµV/m)
Vertical Average
(dBµV/m)
Limit @ 3m
(dBµV/m)
20 MHz Channel
5745.0
--
--
--
--
--
11490.0
53.3
40.0
53.2
39.9
68.3
17235.0
59.4
45.8
59.2
45.9
68.3
22980.0
54.1
40.8
53.8
40.9
68.3
28725.0
56.4
43.3
56.0
43.3
68.3
5785.0
--
--
--
--
--
11570.0
52.5
39.6
52.3
39.6
68.3
17355.0
57.3
44.0
56.4
43.9
68.3
23140.0
53.4
40.6
54.0
40.7
68.3
28925.0
56.4
43.4
56.5
43.4
68.3
5825.0
--
--
--
--
--
11650.0
53.1
39.9
52.9
39.9
68.3
17475.0
56.7
43.5
57.2
43.7
68.3
23300.0
53.2
40.2
53.5
40.5
68.3
29125.0
56.5
43.6
56.3
43.6
68.3
Band Edges
5725.0
53.4
32.2
78.8
56.3
78.2
5850.0
44.5
31.4
66.3
42.3
78.2
Other emissions present had amplitudes at least 20 dB below the limit. Peak and Quasi-Peak
amplitude emissions are recorded above for frequency range of 30-1000 MHz. Peak and
Average amplitude emissions are recorded above for frequency range above 1000 MHz.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 73 of 85
Testing
NVLAP Lab Code 200087-0
Table 12 Transmitter Radiated Emission (5725-5850 MHz Band, HDDA5W-32-DP2)
Frequency in
MHz
Horizontal
Peak (dBµV/m)
Horizontal
Average (dBµV/m)
Vertical Peak
(dBµV/m)
Vertical Average
(dBµV/m)
Limit @ 3m
(dBµV/m)
20 MHz Channel
5745.0
--
--
--
--
--
11490.0
52.8
39.9
52.2
39.9
68.3
17235.0
58.9
45.6
58.6
45.9
68.3
22980.0
53.7
40.8
53.6
40.7
68.3
28725.0
56.0
43.3
56.1
43.3
68.3
5785.0
--
--
--
--
--
11570.0
52.7
39.5
52.5
39.3
68.3
17355.0
57.1
44.0
57.8
44.4
68.3
23140.0
53.6
40.6
53.3
40.7
68.3
28925.0
56.5
43.4
56.7
43.5
68.3
5825.0
--
--
--
--
--
11650.0
53.1
40.3
53.2
39.9
68.3
17475.0
58.1
45.1
56.8
43.8
68.3
23300.0
53.3
40.5
53.1
40.2
68.3
29125.0
56.5
43.6
56.7
43.6
68.3
Band Edges
5725.0
55.4
36.1
78.9
56.2
78.2
5850.0
52.8
33.7
66.9
44.6
78.2
Other emissions present had amplitudes at least 20 dB below the limit. Peak and Quasi-Peak
amplitude emissions are recorded above for frequency range of 30-1000 MHz. Peak and
Average amplitude emissions are recorded above for frequency range above 1000 MHz.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 74 of 85
Testing
NVLAP Lab Code 200087-0
Table 13 Transmitter Antenna Port Conducted Power and Emissions Chain 0
Frequency
MHz
Conducted Antenna Port
Output Power (Watts)
99% Occupied
Bandwidth kHz
Power Spectral
Density dBm
20 MHz Mode 802.11a
5180
0.062
18360
4.77 dBm/1MHz
5200
0.074
18400
5.29 dBm/1MHz
5240
0.060
18360
4.42 dBm/1MHz
40 MHz Mode 802.11n
5190
0.100
38250
2.30 dBm/1M
5230
0.077
38550
2.28 dBm/1M
20 MHz Mode 802.11a
5745
0.060
18280
2.26 dBm/500kHz
5785
0.066
18400
3.37 dBm/500kHz
5825
0.076
18320
3.40 dBm/500kHz
40 MHz Mode 802.11n
5755
0.096
38400
-0.11 dBm/500kHz
5795
0.110
38400
0.16 dBm/500kHz
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 75 of 85
Testing
NVLAP Lab Code 200087-0
Table 14 Transmitter Antenna Port Conducted Power and Emissions Chain 1
Frequency
MHz
Conducted Antenna Port
Output Power (Watts)
99% Occupied
Bandwidth kHz
Power Spectral
Density dBm
20 MHz Mode 802.11a
5180
0.079
17840
5.08 dBm/1MHz
5200
0.050
17960
5.36 dBm/1MHz
5240
0.059
17920
5.51 dBm/1MHz
40 MHz Mode 802.11n
5190
0.072
38025
2.16 dBm/1M
5230
0.081
38025
2.64 dBm/1M
20 MHz Mode 802.11a
5745
0.060
17960
1.17 dBm/500kHz
5785
0.071
17880
2.18 dBm/500kHz
5825
0.062
17920
1.69 dBm/500kHz
40 MHz Mode 802.11n
5755
0.081
37800
-1.54 dBm/500kHz
5795
0.091
37875
-0.69 dBm/500kHz
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 76 of 85
Testing
NVLAP Lab Code 200087-0
Table 15 Transmitter Antenna Port Conducted Power and Emissions Chain 2
Frequency
MHz
Conducted Antenna Port
Output Power (Watts)
99% Occupied
Bandwidth kHz
Power Spectral
Density dBm
20 MHz Mode 802.11a
5180
0.060
17640
6.34 dBm/1MHz
5200
0.074
17640
6.31 dBm/1MHz
5240
0.056
17680
5.72 dBm/1MHz
40 MHz Mode 802.11n
5190
0.072
37950
2.94 dBm/1M
5230
0.093
37725
3.36 dBm/1M
20 MHz Mode 802.11a
5745
0.050
17800
-0.51 dBm/500kHz
5785
0.062
17640
0.96 dBm/500kHz
5825
0.079
17600
0.79 dBm/500kHz
40 MHz Mode 802.11n
5755
0.068
38025
-3.59 dBm/500kHz
5795
0.087
37875
-3.14 dBm/500kHz
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 77 of 85
Testing
NVLAP Lab Code 200087-0
Table 16 Transmitter all antenna Ports Total Power and PSD U-NII-1 Band
Frequency
MHz
Antenna Port Output Total
(Watts)
Total Power Spectral
Density dBm
20 MHz Mode 802.11a
5180
0.201
10.2 dBm/1MHz
5200
0.198
10.5 dBm/1MHz
5240
0.175
10.0 dBm/1MHz
40 MHz Mode 802.11n
5190
0.245
7.3 dBm/1MHz
5230
0.252
6.0 dBm/1MHz
Table 17 Transmitter all antenna Ports Total Power and PSD U-NII-3 Band
Frequency
MHz
Antenna Port Output Total
(Watts)
Total Power Spectral
Density dBm
20 MHz Mode 802.11a
5745
0.171
5.90 dBm/500 kHz
5785
0.199
4.60 dBm/500 kHz
5825
0.217
5.60 dBm/500 kHz
40 MHz Mode 802.11n
5755
0.244
3.3 dBm/500 kHz
5795
0.288
2.8 dBm/500 kHz
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 78 of 85
Testing
NVLAP Lab Code 200087-0
Summary of Results for Transmitter Radiated Emissions of Intentional Radiator
The EUT demonstrated compliance with the radiated emissions requirements of 47CFR Part
15.407 and Industry Canada RSS-247. The maximum conducted combined output power
delivered into antenna ports was 0.288 -Watts. The minimum harmonic radiated emission
margin provided -22.4 dB margin below requirements. General radiated emissions of EUT
and supporting equipment provided -1.7 dB margin. There were no other significantly
measurable emissions in the restricted bands other than those recorded in this report. Other
emissions were present with amplitudes at least 20 dB below the requirements. There were
no other deviations or exceptions to the requirements.
Statement of Modifications and Deviations
No modifications to the EUT were required for the unit to demonstrate compliance with the
47CFR Part 15C and Industry Canada RSS-247 emissions requirements. There were no
deviations or modifications to the specifications.
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 79 of 85
Testing
NVLAP Lab Code 200087-0
Annex
•
Annex A Measurement Uncertainty Calculations
•
Annex B Rogers Labs Test Equipment List
•
Annex C Rogers Qualifications
•
Annex D FCC Site Registration Letter
•
Annex E Industry Canada Site Registration Letter
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 80 of 85
Testing
NVLAP Lab Code 200087-0
Annex A Measurement Uncertainty Calculations
Measurement uncertainty calculations were made for the laboratory. Result of measurement
uncertainty calculations are recorded below for AC line conducted and radiated emission
measurements.
Measurement Uncertainty
U(E)
U(lab)
3 Meter Horizontal 30-200 MHz Measurements
2.08
4.16
3 Meter Vertical 30-200 MHz Measurements
2.16
4.33
3 Meter Vertical Measurements 200-1000 MHz
2.99
5.97
10 Meter Horizontal Measurements 30-200 MHz
2.07
4.15
10 Meter Vertical Measurements 30-200 MHz
2.06
4.13
10 Meter Horizontal Measurements 200-1000 MHz
2.32
4.64
10 Meter Vertical Measurements 200-1000 MHz
2.33
4.66
3 Meter Measurements 1-6 GHz
2.57
5.14
3 Meter Measurements 6-18 GHz
2.58
5.16
AC Line Conducted
1.72
3.43
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 81 of 85
Testing
NVLAP Lab Code 200087-0
Annex B Rogers Labs Test Equipment List
List of Test Equipment
Calibration
Spectrum Analyzer: Rohde & Schwarz ESU40
Spectrum Analyzer: HP 8562A, HP Adapters: 11518, 11519, and 11520
Mixers: 11517A, 11970A, 11970K, 11970U, 11970V, 11970W
Spectrum Analyzer: HP 8591EM
Antenna: EMCO Biconilog Model: 3143
Antenna: Sunol Biconilog Model: JB6
Antenna: EMCO Log Periodic Model: 3147
Antenna: Com Power Model: AH-118
Antenna: Com Power Model: AH-840
Antenna: Antenna Research Biconical Model: BCD 235
Antenna: Com Power Model: AL-130
Antenna: EMCO 6509
LISN: Compliance Design Model: FCC-LISN-2.Mod.cd, 50 μHy/50 ohms/0.1 µf
R.F. Preamp CPPA-102
Attenuator: HP Model: HP11509A
Attenuator: Mini Circuits Model: CAT-3
Attenuator: Mini Circuits Model: CAT-3
Cable: Belden RG-58 (L1)
Cable: Belden RG-58 (L2)
Cable: Belden 8268 (L3)
Cable: Time Microwave: 4M-750HF290-750
Cable: Time Microwave: 10M-750HF290-750
Frequency Counter: Leader LDC825
Oscilloscope Scope: Tektronix 2230
Wattmeter: Bird 43 with Load Bird 8085
Power Supplies: Sorensen SRL 20-25, SRL 40-25, DCR 150, DCR 140
R.F. Generators: HP 606A, HP 8614A, HP 8640B
R.F. Power Amp 65W Model: 470-A-1010
R.F. Power Amp 50W M185- 10-501
R.F. Power Amp A.R. Model: 10W 1010M7
R.F. Power Amp EIN Model: A301
LISN: Compliance Eng. Model 240/20
LISN: Fischer Custom Communications Model: FCC-LISN-50-16-2-08
Antenna: EMCO Dipole Set 3121C
Antenna: C.D. B-101
Antenna: Solar 9229-1 & 9230-1
Audio Oscillator: H.P. 201CD
ELGAR Model: 1751
ELGAR Model: TG 704A-3D
ESD Test Set 2010i
Fast Transient Burst Generator Model: EFT/B-101
Field Intensity Meter: EFM-018
Shielded Room 5 M x 3 M x 3.0 M
Date
5/16
5/16
Due
5/17
5/17
5/16
5/16
10/16
10/16
10/16
5/16
10/16
10/16
10/16
10/16
10/16
10/16
10/16
10/16
10/16
10/16
10/16
10/16
10/16
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
2/17
5/17
5/17
10/17
10/17
10/17
5/18
10/17
10/17
10/17
10/17
10/17
10/17
10/17
10/17
10/17
10/17
10/17
10/17
10/17
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
2/18
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 82 of 85
Testing
NVLAP Lab Code 200087-0
Annex C Rogers Qualifications
Scot D. Rogers, Engineer
Rogers Labs, Inc.
Mr. Rogers has approximately 17 years’ experience in the field of electronics. Engineering
experience includes six years in the automated controls industry and remaining years
working with the design, development and testing of radio communications and electronic
equipment.
Positions Held
Systems Engineer:
A/C Controls Mfg. Co., Inc. 6 Years
Electrical Engineer:
Rogers Consulting Labs, Inc. 5 Years
Electrical Engineer:
Rogers Labs, Inc. Current
Educational Background
1)
Bachelor of Science Degree in Electrical Engineering from Kansas State University.
2)
Bachelor of Science Degree in Business Administration Kansas State University.
3)
Several Specialized Training courses and seminars pertaining to Microprocessors and
Software programming.
Scot D. Rogers
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 83 of 85
Testing
NVLAP Lab Code 200087-0
Annex D FCC Site Registration Letter
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 84 of 85
Testing
NVLAP Lab Code 200087-0
Annex E Industry Canada Site Registration Letter
Rogers Labs, Inc.
Mikrotikls SIA
S/N: 54EE04337EEF
4405 W. 259th Terrace
Model: RB953GS-5HnT-RP-US
FCC ID: TV7RB953GS5HNTM
Louisburg, KS 66053
Test #: 170316
IC: 7442A-RB953GS5HNT
Phone/Fax: (913) 837-3214
Test to: 47CFR, 15.407, RSS-247 Date: April 5, 2017
Revision 1 File: Mikrotikls RB953GS-5HnT-RP-US FCC TstRpt 170316
Page 85 of 85
Download: RB953GS5HNTM Unlicensed National Information Infrastructure TX Test Report  Mikrotikls SIA
Mirror Download [FCC.gov]RB953GS5HNTM Unlicensed National Information Infrastructure TX Test Report  Mikrotikls SIA
Document ID3366826
Application ID4RECByLVnqJPYN3y6asTqA==
Document DescriptionTest Report
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize410.56kB (5132007 bits)
Date Submitted2017-04-21 00:00:00
Date Available2017-04-21 00:00:00
Creation Date2017-04-05 16:08:32
Producing SoftwareMicrosoft® Word 2016
Document Lastmod2017-04-05 16:08:32
Document TitleTest Report
Document CreatorMicrosoft® Word 2016

Source Exif Data:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.5
Linearized                      : No
Page Count                      : 85
Language                        : en-US
XMP Toolkit                     : 3.1-701
Producer                        : Microsoft® Word 2016
Creator Tool                    : Microsoft® Word 2016
Create Date                     : 2017:04:05 16:08:32-05:00
Modify Date                     : 2017:04:05 16:08:32-05:00
Document ID                     : uuid:2B55D631-7366-4AE9-8CF3-1063DDBF18F3
Instance ID                     : uuid:2B55D631-7366-4AE9-8CF3-1063DDBF18F3
Creator                         : Microsoft® Word 2016

Facebook Twitter Google+ RSS © FCCID.io 2017
