FCC ID TV7RBCM2ND
Digital Transmission System 2412-2462 MHz
by Mikrotikls SIA
Grantee Code: TV7 Product Code: RBCM2ND
Latest application date: 2016-08-09
Device Images
FCC ID Device Details
| FCC ID | TV7RBCM2ND |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | TV7 |
| Product Code | RBCM2ND |
| Applicant Business | Mikrotikls SIA 🇱🇻 |
| Related Domains |  mikrotik.com |
| Equipment Class | Digital Transmission System 2412-2462 MHz |
| Test Firm | Rogers Labs, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-08-09 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-08-09 | PDF 228.3 KB |
| Internal Photos | Internal Photos | 2016-08-09 | PDF 1,007.3 KB |
| External Photos | External Photos | 2016-08-09 | PDF 765.8 KB |
| Label Sample | ID Label/Location Info | 2016-08-09 | PDF 109.3 KB |
| Test Setup Photos | Test Setup Photos | 2016-08-09 | PDF 1.1 MB |
| Test Report | Test Report | 2016-08-09 | PDF 2.4 MB |
| DoC Attestation Letter | Attestation Statements | 2016-08-09 | PDF 105.3 KB |
| Agent Authorization Letter for Rogers Labs | Cover Letter(s) | 2016-08-09 | PDF 146.6 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-08-09 | PDF 293.9 KB |
| Submittal Letter | Cover Letter(s) | 2016-08-09 | PDF 135.9 KB |
| RF Exposure | RF Exposure Info | 2016-08-09 | PDF 118 KB |
| Tune Up Procedure | Parts List/Tune Up Info | 2016-08-09 | PDF 4.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 40 KB | |
| Schematics Metadata only | Schematics | PDF 229.4 KB | |
| Operational Description Metadata only | Operational Description | PDF 27.1 KB |
Application Information
| Application ID | jpGFJ74Zm+pmYpa5S+GZdg== |
|---|---|
| Final Action Date | 2016-08-09 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0013617048 |
| Model | RBCM2ND |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Digital Transmission System 2412-2462 MHz |
| Responsible Party | Edmunds Zvegincevs, engineer, R&D;, certification@mikrotik.com , +371 67317700 |
| Test Firm | Scot Rogers, Rogers Labs, Inc., rogers@pixius.net  , 913-837-3214 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operation conditions for satisfying RF exposure compliance. This device has 20MHz and 40MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| jpGFJ74Zm+pmYpa5S+GZdg== | 2016-08-09 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0480000 | 15C |
Grants
TCB Grant - Application jpGFJ74Zm+pmYpa5S+GZdg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 08/09/2016 Application Dated: 08/09/2016 |
| Mikrotikls SIA |
| Brivibas gatve 214i |
| Riga, LV-1039 Latvia |
| Attention: Edmunds Zvegincevs , engineer, R&D |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TV7RBCM2ND |
| Name of Grantee: | Mikrotikls SIA |
| Equipment Class: | Digital Transmission System |
| Notes: | Digital Transmission System 2412-2462 MHz |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.048 |
| Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operation conditions for satisfying RF exposure compliance. This device has 20MHz and 40MHz bandwidth modes. |
EAS Grant - Application jpGFJ74Zm+pmYpa5S+GZdg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Mikrotikls SIA Brivibas gatve 214i Riga, LV-1039 Latvia |
Date of Grant: 08/09/2016 Application Dated: 08/09/2016 |
| Attention: Edmunds Zvegincevs , engineer, R&D |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TV7RBCM2ND |
| Name of Grantee: | Mikrotikls SIA |
| Equipment Class: | Digital Transmission System |
| Notes: | Digital Transmission System 2412-2462 MHz |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.048 |
| Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not transmit simultaneously with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures. Users and installers must be provided with antenna installation instructions and transmitter operation conditions for satisfying RF exposure compliance. This device has 20MHz and 40MHz bandwidth modes. |
