FCC ID TVE-28166011
Secured Wireless Access Point
by Fortinet Inc.
Grantee Code: TVE Product Code: 28166011
Latest application date: 2017-03-16
Device Images
FCC ID Device Details
| FCC ID | TVE-28166011 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | TVE |
| Product Code | 28166011 |
| Applicant Business | Fortinet Inc. 🇺🇸 |
| Related Domains |  fortinet.com |
| Equipment Class | Secured Wireless Access Point |
| Test Firm | Bureau Veritas CPS(H.K.) Ltd., Taoyuan Branch |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2017-03-16 |
| 5180-5240 MHz | Original Equipment | 2016-10-26 |
| 2412-2462 MHz | Original Equipment | 2016-10-26 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual FAP-423E | Users Manual | 2017-03-16 | PDF 1.7 MB |
| Users Manual FAP-421E | Users Manual | 2017-03-16 | PDF 1.4 MB |
| Users Manual (External Antenna) | Users Manual | 2016-10-26 | PDF 1.7 MB |
| Users Manual (Internal Antenna) | Users Manual | 2016-10-26 | PDF 1.5 MB |
| Internal Photos_rev | Internal Photos | 2016-10-26 | PDF 3.8 MB |
| External Photos_rev | External Photos | 2016-10-26 | PDF 2.3 MB |
| FCC ID Label | ID Label/Location Info | 2017-03-16 | PDF 316.3 KB |
| Label Sample & Label Location | ID Label/Location Info | 2016-10-26 | PDF 587.9 KB |
| Setup Photos (DFS) | Test Setup Photos | 2017-03-16 | PDF 101.2 KB |
| Setup Photos (RF) | Test Setup Photos | 2017-03-16 | PDF 902.9 KB |
| Test Set Up Photos | Test Setup Photos | 2016-10-26 | PDF 676.8 KB |
| Test Report (DFS) | Test Report | 2017-03-16 | PDF 1.8 MB |
| Test Report (W53 and W56) | Test Report | 2017-03-16 | PDF 905.3 KB |
| Test Report (DTS)_rev | Test Report | 2016-10-26 | PDF 2.3 MB |
| Test Report (NII)_rev | Test Report | 2016-10-26 | PDF 1 MB |
| Attestation (Channel and Mode Declaration) | Attestation Statements | 2016-10-26 | PDF 215.4 KB |
| CIIPC Letter | Cover Letter(s) | 2017-03-16 | PDF 242.4 KB |
| Confidentiality Letter | Cover Letter(s) | 2017-03-16 | PDF 138.3 KB |
| Product Similarity Declaration | Cover Letter(s) | 2017-03-16 | PDF 92 KB |
| Confidentiality Request | Cover Letter(s) | 2016-10-26 | PDF 239.5 KB |
| Cover Letter (Agent Authorization) | Cover Letter(s) | 2016-10-26 | PDF 311.7 KB |
| RF Exposure | RF Exposure Info | 2017-03-16 | PDF 149.9 KB |
| RF Exposure Info (MPE)_rev | RF Exposure Info | 2016-10-26 | PDF 93.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 42.8 KB | |
| Block Diagram (2.4G Module) Metadata only | Block Diagram | PDF 63.3 KB | |
| Block Diagram (5G Module) Metadata only | Block Diagram | PDF 60.3 KB | |
| Schematics Metadata only | Schematics | PDF 471.8 KB | |
| Schematics (2.4G Module) Metadata only | Schematics | PDF 206.1 KB | |
| Schematics (5G Module) Metadata only | Schematics | PDF 210.8 KB | |
| Mesh mode Declaration Metadata only | Operational Description | PDF 140.5 KB | |
| Operational Description Metadata only | Operational Description | PDF 27.4 KB | |
| PAG Approved Metadata only | Operational Description | PDF 43.5 KB | |
| Software Operating Description Metadata only | Operational Description | PDF 891.5 KB | |
| Software Security Description Metadata only | Operational Description | PDF 902.2 KB | |
| Software Security Description Rev Metadata only | Operational Description | PDF 208.1 KB |
Application Information
| Application ID | uyBDSLA5T8v5N4IGowiZzg== |
|---|---|
| Final Action Date | 2017-03-16 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0014392971 |
| Model | 28166011 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Secured Wireless Access Point |
| Responsible Party | Andrew Ji, Director, aji@fortinet.com , 408 235 7700 |
| Test Firm | Richard Chen, Bureau Veritas CPS(H.K.) Ltd., Taoyuan Branch, richard.chen@bureauveritas.com  , +886-(0)3-260-0884 |
| TCB Email | bacl.regulatory@baclcorp.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Class II Permissive Change of adding DFS bands as described in this filing. Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 31 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This device has 20 MHz, 40 MHz and 80 MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| uyBDSLA5T8v5N4IGowiZzg== | 2017-03-16 | Class II permissive change or modification of presently authorized equipment |
| hGVdQitQ6Wj6WZwW7cBdWA== | 2016-10-26 | Original Equipment |
| Qe1TN8/u5ME1F1lEWOB/0Q== | 2016-10-26 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application uyBDSLA5T8v5N4IGowiZzg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bay Area Compliance Laboratory Corp. 1274 Anvilwood Avenue Sunnyvale, CA 94089 |
Date of Grant: 03/16/2017 Application Dated: 02/01/2017 |
| Fortinet Inc. |
| 899 Kifer Road |
| Sunnyvale, CA 94086 |
| Attention: Andrew Ji , Director |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | TVE-28166011 |
| Name of Grantee: | Fortinet Inc. |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Secured Wireless Access Point |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.296 | ||
| 38 CC MO ND | 15E | 5260.0 - 5320.0 | 0.134 | ||
| 38 CC MO ND | 15E | 5500.0 - 5720.0 | 0.242 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.392 |
| Class II Permissive Change of adding DFS bands as described in this filing. Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 31 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This device has 20 MHz, 40 MHz and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
