PACE4 Test Setup Photos - FCC ID U46-PACE4

FCC ID U46-PACE4

Test setup

PACE4

by TeleEpoch Limited

Document preview loads when visible.

Document Details

FCC IDU46-PACE4
Document ID3652479
Document TypeTest Setup Photos
DescriptionTest setup
ApplicantTeleEpoch Limited
Equipment ClassPACE4
Product CodePACE4
Application ID7qMd3ii94euQJS3H1au0bQ==
Application PurposeOriginal Equipment
Application Date2017-11-25
Frequency Range2412-2462 MHz
FRN0016193377
Test FirmShenzhen Huatongwei International Inspection Co.,
Certified ByFerry Wan Vice President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2017-11-25
Available2017-11-25
Created2017-11-23
Modified2017-11-23
Pages2
File TypeAdobe Acrobat PDF
File Size265975
File SHA-256bbfdcd82ccf364a7159604bea38255d26d202207be3b9d4c0e64d47fdbc4fba8
PDF Metadata AuthorHP
PDF Metadata ProducerMicrosoft® Word 2013 Microsoft® Word 2013
FCC.gov SourcesFCC.gov 3652479
