FCC ID U4Y-DAXAO1
802.11a/ac PCI-e Module
by LANCOM Systems GmbH
Grantee Code: U4Y Product Code: DAXAO1
Latest application date: 2016-09-21
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-09-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-09-21 | PDF 78.4 KB |
| Internal Photographs | Internal Photos | 2016-09-21 | PDF 2.1 MB |
| External Photographs | External Photos | 2016-09-21 | PDF 5.6 MB |
| Label Information | ID Label/Location Info | 2016-09-21 | PDF 178.1 KB |
| Test Setup Photographs | Test Setup Photos | 2016-09-21 | PDF 5.9 MB |
| Test Report | Test Report | 2016-09-21 | PDF 1.2 MB |
| Authorization Letter | Cover Letter(s) | 2016-09-21 | PDF 21.5 KB |
| Confidentiality Request | Cover Letter(s) | 2016-09-21 | PDF 81.6 KB |
| Modular Request | Cover Letter(s) | 2016-09-21 | PDF 69.3 KB |
| RF Exposure | RF Exposure Info | 2016-09-21 | PDF 77.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 62.1 KB | |
| Schematics Metadata only | Schematics | PDF 524.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 114.8 KB | |
| Software Control Declaration Metadata only | SDR Software/Security Inf | PDF 387 KB | |
| Software Security Description Metadata only | SDR Software/Security Inf | PDF 79.2 KB |
Application Information
| Application ID | C58FqmPKz7yN/Sr2ozsBiA== |
|---|---|
| Final Action Date | 2016-09-21 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0016193682 |
| Model | DAXAO1 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | 802.11a/ac PCI-e Module |
| Responsible Party | Udo Brocker, Director Engineering, udo.brocker@lancom.de  , +49240549936401 |
| Technical Contact | Mark Koop, Teleconformity, mark.koop@teleconformity.com  , 31-84-8395867 |
| Test Firm | Sharon Jiang, SPORTON International Inc., sharonjiang@sporton.com.tw  , 886-3-656-9065 |
| TCB Email | certification@micomlabs.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval. Output power listed is maximum combined output power. This device is a 3x3 MIMO as is described in the filing. The antenna used with this transmitter must be installed to provide a minimum separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter within the device. OEM Integrators must be instructed not to provide the end-user with instructions to remove or install the device. Installers must be provided with installation instructions and End-Users must be provided with operating procedures for satisfying RF exposure compliance. |
