SRS100 Industrial Wireless Monitoring... - FCC ID U62-SRS100

FCC ID U62-SRS100

Radio Board p2

Industrial Wireless Monitoring Network

by SynapSense Corporation

Document preview loads when visible.

Document Details

FCC IDU62-SRS100
Document ID831832
Document TypeSchematics
DescriptionRadio Board p2
Document TitlePG1.sch
ApplicantSynapSense Corporation
Equipment ClassIndustrial Wireless Monitoring Network
Product CodeSRS100
Application IDhxWZUyX3WFsUManRW+BOug==
Application PurposeOriginal Equipment
Application Date2007-08-27
Frequency Range2405-2480 MHz
FRN0016283442
Test FirmCKC Laboratories, Inc.
Certified ByMary Ellen Clayton Report Writer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2007-08-21
Available2007-08-27
Created2007-06-06
Modified2007-06-06
Pages1
File TypeAdobe Acrobat PDF
File Size76653
File SHA-25635e9e2fee6f1ea77a9443b5eb379c5bd5f1a0796881c6daafec1b7a17fb1e9b2
PDF Metadata Authormdinicola
PDF Metadata CreatorPrimoPDF http://www.primopdf.com
PDF Metadata ProducerPrimoPDF
FCC.gov SourcesFCC.gov 831832
