AL5721 Worldwide Wireless USB Device-Side... - FCC ID U9YAL5721

FCC ID U9YAL5721

Test Report

Worldwide Wireless USB Device-Side Radio Card

by Alereon, Inc

Document preview loads when visible.

Document Details

FCC IDU9YAL5721
Document ID1056863
Document TypeTest Report
DescriptionTest Report
Document TitleTTS Compliance Test Report
ApplicantAlereon, Inc
Equipment ClassWorldwide Wireless USB Device-Side Radio Card
Product CodeAL5721
Application IDeYyQwW1FdwSmhUfUX+PbBg==
Application PurposeOriginal Equipment
Application Date2009-03-13
Frequency Range3168-4752 MHz
FRN0012134086
Test FirmTDK RF Solutions, Inc.
Certified ByArmando Medina Test Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date04/27/2009
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2009-01-15
Available2009-03-13
Created2009-01-14
Modified2009-01-14
Pages103
File TypeAdobe Acrobat PDF
File Size1646260
File SHA-25671cebb554fa4b129b36e2b323842af3dc3ccbbfdfbd07dece437351a88ce4bbc
PDF Metadata AuthorRENAMEDBYADMWHILEHIDDENTOALLOWDUPLICATEACCELERATORS
PDF Metadata CreatorNone
PDF Metadata ProducerAcrobat Distiller 6.0.1 (Windows)
FCC.gov SourcesFCC.gov 1056863
