SG8840 2.4 GHz Wireless Camera Schematics - FCC ID UCZSG8840

FCC ID UCZSG8840

Schematics

2.4 GHz Wireless Camera

by Lorex Technology Inc.

Document preview loads when visible.

Document Details

FCC IDUCZSG8840
Document ID677540
Document TypeSchematics
DescriptionSchematics
Document Titlegav-02
ApplicantLorex Technology Inc.
Equipment Class2.4 GHz Wireless Camera
Product CodeSG8840
Application IDxBPFnxOZCjOxb1gLl+/aMw==
Application PurposeOriginal Equipment
Application Date2006-07-05
Frequency Range2414-2468 MHz
FRN0019966381
Test FirmBay Area Compliance Laboratory Corp. (Shenzhen)
Certified ByNick Xu
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2006-07-05
Available2006-07-05
Created2006-05-18
Modified2006-05-18
Pages1
File TypeAdobe Acrobat PDF
File Size31085
File SHA-256b81d1f3d3e851f43bf73e85ee5333f5fbf240d684dbcc7f680685143ae67bf32
PDF Metadata Authorjin
PDF Metadata CreatorpdfFactory www.pdffactory.com
PDF Metadata ProducerpdfFactory 2.46 (Windows XP Professional Chinese)
FCC.gov SourcesFCC.gov 677540, FCC.gov 677541
