DG2470 DG2470 series is a 4-port DOCSIS 3.0... - FCC ID UIDDG2470

FCC ID UIDDG2470

User Manual - DG2470A

DG2470 series is a 4-port DOCSIS 3.0 Gateway (24x8 Channel Bonding). The product will provide 802.11n and 802.11 Wi-Fi and has Quad-Port Gigabit Ethernet and USB

by ARRIS

Document preview loads when visible.

Document Details

FCC IDUIDDG2470
Document ID2554914
Document TypeUsers Manual
DescriptionUser Manual - DG2470A
Document TitleTouchstone DG2470 Data Gateway User Guide
ApplicantARRIS
Equipment ClassDG2470 series is a 4-port DOCSIS 3.0 Gateway (24x8 Channel Bonding). The product will provide 802.11n and 802.11 Wi-Fi and has Quad-Port Gigabit Ethernet and USB
Product CodeDG2470
Application IDUgbdObg3cBChu9pPDor+Xw==
Application PurposeOriginal Equipment
Application Date2015-03-13
Frequency Range2412-2462 MHz
FRN0009654609
Test FirmEUROFINS ELECTRICAL AND ELECTRONIC TESTING NA, INC
Certified ByAntonio A. Figueiredo Regulatory/Compliance
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2015-03-13
Available2015-03-13
Created2015-02-19
Modified2015-02-19
Pages38
File TypeAdobe Acrobat PDF
File Size851805
File SHA-256b5fd7104212a7fcab0332833b757a7fdffa4ffa5a6798838bf6dac9320d7f77b
PDF Metadata AuthorBob Schultz "ARRIS Global Knowledge Systems" ARRIS
PDF Metadata ProducerBob Schultz "ARRIS Global Knowledge Systems" Adobe PDF Library 11.0
FCC.gov SourcesFCC.gov 2554914, FCC.gov 2554980
