FCC ID UIDSBG6950
Wireless Telephony Gateway
by ARRIS
Grantee Code: UID Product Code: SBG6950
Latest application date: 2017-08-02
Device Images
FCC ID Device Details
| FCC ID | UIDSBG6950 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | UID |
| Product Code | SBG6950 |
| Applicant Business | ARRIS 🇺🇸 |
| Related Domains |  arrisi.com |
| Equipment Class | Wireless Telephony Gateway |
| Test Firm | EUROFINS ELECTRICAL AND ELECTRONIC TESTING NA, INC |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2017-08-02 |
| 5180-5240 MHz | Original Equipment | 2017-03-24 |
| 2412-2462 MHz | Original Equipment | 2017-03-24 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Manual | Users Manual | 2017-03-24 | PDF 1.2 MB |
| Internal Photos | Internal Photos | 2017-05-08 | PDF 960.7 KB |
| Internal Photos - Antenna Location | Internal Photos | 2017-05-08 | PDF 163.3 KB |
| Internal Photos - Antenna Location | Internal Photos | 2017-05-08 | PDF 118.3 KB |
| External Photos | External Photos | 2017-05-08 | PDF 340 KB |
| Label | ID Label/Location Info | 2017-03-24 | PDF 59.9 KB |
| Label placement | ID Label/Location Info | 2017-03-24 | PDF 888.2 KB |
| Label placement drawing | ID Label/Location Info | 2017-03-24 | PDF 888.2 KB |
| Test Setup Photos | Test Setup Photos | 2017-05-08 | PDF 231.3 KB |
| Test setup photos Metadata only | Test Setup Photos | 2017-05-08 | PDF 231.3 KB |
| Test Report - DFS | Test Report | 2017-08-02 | PDF 1.6 MB |
| Test Report - UNII 2 | Test Report | 2017-08-02 | PDF 4 MB |
| Test Report | Test Report | 2017-03-24 | PDF 1.7 MB |
| Test Report UNII 1 | Test Report | 2017-03-24 | PDF 2.7 MB |
| Test Report UNII 3 | Test Report | 2017-03-24 | PDF 1.9 MB |
| Class II PC Letter | Cover Letter(s) | 2017-08-02 | PDF 89.7 KB |
| Declaration | Cover Letter(s) | 2017-08-02 | PDF 82.8 KB |
| differences letter | Cover Letter(s) | 2017-08-02 | PDF 74.7 KB |
| long term confidential letter | Cover Letter(s) | 2017-03-24 | PDF 70.7 KB |
| short term confidential letter | Cover Letter(s) | 2017-03-24 | PDF 73.1 KB |
| Antenna Info | RF Exposure Info | 2017-03-24 | PDF 829 KB |
| Antenna Information | RF Exposure Info | 2017-03-24 | PDF 645.1 KB |
| MPE | RF Exposure Info | 2017-03-24 | PDF 110.8 KB |
| MPE | RF Exposure Info | 2017-03-24 | PDF 126 KB |
| Block Diagram Metadata only | Block Diagram | PDF 138.5 KB | |
| Schematic Part 1 Metadata only | Schematics | PDF 3.8 MB | |
| Schematic Part 2 Metadata only | Schematics | PDF 3.1 MB | |
| Theory of Operations Metadata only | Operational Description | PDF 267.8 KB | |
| U-NII Device Security Metadata only | SDR Software/Security Inf | PDF 207.8 KB |
Application Information
| Application ID | FueYj5zogxdDYjw+cFeyNg== |
|---|---|
| Final Action Date | 2017-08-02 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0009654609 |
| Model | SBG6950 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Wireless Telephony Gateway |
| Responsible Party | Antonio A Figueiredo, Manager -Regulatory/Compliance, tony.figueiredo@arrisi.com , 678-473-5067 |
| Technical Contact | Antonio A. Figueiredo, ARRIS Group, Inc., tony.figueiredo@arris.com  , 678-473-5067 |
| Test Firm | Greg Kovolenko, EUROFINS ELECTRICAL AND ELECTRONIC TESTING NA, INC, greg.kovolenko@metlabs.com  , 4108444071 |
| TCB Email | tcbinfo@metlabs.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Class II Permissive Change for adding DFS band. Power Output listed is aggregate conducted for MIMO operation. This is a 3x3 MIMO operating in a configuration as described in this filing. 5150-5250 MHz is restricted for indoor use only. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter. This device supports 20, 40, and 80 MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| FueYj5zogxdDYjw+cFeyNg== | 2017-08-02 | Class II permissive change or modification of presently authorized equipment |
| i4Q1k8b6ndfRRVl50gCMZQ== | 2017-03-24 | Original Equipment |
| cZbPW7YhxbX98V3JYeW5Cw== | 2017-03-24 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application i4Q1k8b6ndfRRVl50gCMZQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Electrical and Electronic Testing NA, Inc 914 W. Patapsco Avenue Baltimore, MD 21230-3432 |
Date of Grant: 03/24/2017 Application Dated: 03/24/2017 |
| ARRIS |
| 3871 Lakefield Drive |
| Suite 300 |
| SUWANEE, GA 30024 |
| Attention: Antonio Figueiredo , Manager -Regulatory/Compliance |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | UIDSBG6950 |
| Name of Grantee: | ARRIS |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Telephony Gateway |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.13 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.12 |
| Power Output listed is aggregate conducted for MIMO operation. This is a 3x3 MIMO operating in a configuration as described in this filing. 5150-5250 MHz is restricted for indoor use only. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter. This device supports 20, 40, and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application i4Q1k8b6ndfRRVl50gCMZQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ARRIS 3871 Lakefield Drive Suite 300 SUWANEE, GA 30024 United States |
Date of Grant: 03/24/2017 Application Dated: 03/24/2017 |
| Attention: Antonio Figueiredo , Manager -Regulatory/Compliance |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | UIDSBG6950 |
| Name of Grantee: | ARRIS |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Telephony Gateway |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.13 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.12 |
| Power Output listed is aggregate conducted for MIMO operation. This is a 3x3 MIMO operating in a configuration as described in this filing. 5150-5250 MHz is restricted for indoor use only. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter. This device supports 20, 40, and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Electrical and Electronic Testing NA, Inc 914 W. Patapsco Avenue Baltimore, MD 21230-3432 |
Date of Grant: 08/02/2017 Application Dated: 05/30/2017 |
| ARRIS |
| 3871 Lakefield Drive |
| Suite 300 |
| SUWANEE, GA 30024 |
| Attention: Antonio Figueiredo , Manager -Regulatory/Compliance |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | UIDSBG6950 |
| Name of Grantee: | ARRIS |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Telephony Gateway |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.13 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.12 | ||
| 38 CC MO ND | 15E | 5260.0 - 5320.0 | 0.072 | ||
| 38 CC MO ND | 15E | 5500.0 - 5700.0 | 0.07 |
| Class II Permissive Change for adding DFS band. Power Output listed is aggregate conducted for MIMO operation. This is a 3x3 MIMO operating in a configuration as described in this filing. 5150-5250 MHz is restricted for indoor use only. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter. This device supports 20, 40, and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application FueYj5zogxdDYjw+cFeyNg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ARRIS 3871 Lakefield Drive Suite 300 SUWANEE, GA 30024 United States |
Date of Grant: 08/02/2017 Application Dated: 05/30/2017 |
| Attention: Antonio Figueiredo , Manager -Regulatory/Compliance |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | UIDSBG6950 |
| Name of Grantee: | ARRIS |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Telephony Gateway |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.13 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.12 | ||
| 38 CC MO ND | 15E | 5260.0 - 5320.0 | 0.072 | ||
| 38 CC MO ND | 15E | 5500.0 - 5700.0 | 0.07 |
| Class II Permissive Change for adding DFS band. Power Output listed is aggregate conducted for MIMO operation. This is a 3x3 MIMO operating in a configuration as described in this filing. 5150-5250 MHz is restricted for indoor use only. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter. This device supports 20, 40, and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Electrical and Electronic Testing NA, Inc 914 W. Patapsco Avenue Baltimore, MD 21230-3432 |
Date of Grant: 03/24/2017 Application Dated: 03/24/2017 |
| ARRIS |
| 3871 Lakefield Drive |
| Suite 300 |
| SUWANEE, GA 30024 |
| Attention: Antonio Figueiredo , Manager -Regulatory/Compliance |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | UIDSBG6950 |
| Name of Grantee: | ARRIS |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Telephony Gateway |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.262 |
| Power Output listed is aggregate conducted for MIMO operation. This is a 3x3 MIMO operating in a configuration as described in this filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter. This device supports 20 and 40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application cZbPW7YhxbX98V3JYeW5Cw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ARRIS 3871 Lakefield Drive Suite 300 SUWANEE, GA 30024 United States |
Date of Grant: 03/24/2017 Application Dated: 03/24/2017 |
| Attention: Antonio Figueiredo , Manager -Regulatory/Compliance |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | UIDSBG6950 |
| Name of Grantee: | ARRIS |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless Telephony Gateway |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.262 |
| Power Output listed is aggregate conducted for MIMO operation. This is a 3x3 MIMO operating in a configuration as described in this filing. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter. This device supports 20 and 40 MHz bandwidth modes. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
