FCC ID UIDTG3482ER
Wireless Telephony Gateway
by ARRIS
Grantee Code: UID Product Code: TG3482ER
Latest application date: 2016-12-12
Device Images
FCC ID Device Details
| FCC ID | UIDTG3482ER |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | UID |
| Product Code | TG3482ER |
| Applicant Business | ARRIS 🇺🇸 |
| Related Domains |  arrisi.com |
| Equipment Class | Wireless Telephony Gateway |
| Test Firm | EUROFINS ELECTRICAL AND ELECTRONIC TESTING NA, INC |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-12-12 |
| 5180-5240 MHz | Original Equipment | 2016-12-12 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Guide | Users Manual | 2016-12-12 | PDF 1.6 MB |
| Internal Photos | Internal Photos | 2017-01-26 | PDF 2.3 MB |
| External Photos | External Photos | 2017-01-26 | PDF 396.7 KB |
| Label and Location | ID Label/Location Info | 2016-12-12 | PDF 138.5 KB |
| Test Setup Photos | Test Setup Photos | 2017-01-26 | PDF 385.8 KB |
| Test Report - BLE | Test Report | 2016-12-12 | PDF 840.6 KB |
| Test Report - Thread | Test Report | 2016-12-12 | PDF 838.1 KB |
| Test Report - Wi-Fi | Test Report | 2016-12-12 | PDF 2.3 MB |
| Test Report - ZigBee | Test Report | 2016-12-12 | PDF 840.1 KB |
| Test Report UNII 1 | Test Report | 2016-12-12 | PDF 5.6 MB |
| Test Report UNII 3 | Test Report | 2016-12-12 | PDF 4.6 MB |
| long term confidential letter | Cover Letter(s) | 2016-12-12 | PDF 70.7 KB |
| short term confidential letter | Cover Letter(s) | 2016-12-12 | PDF 73.1 KB |
| Antenna datasheet | RF Exposure Info | 2016-12-12 | PDF 632.6 KB |
| Co-Location MPE | RF Exposure Info | 2016-12-12 | PDF 110.7 KB |
| MPE - 15C | RF Exposure Info | 2016-12-12 | PDF 128.5 KB |
| MPE - 15E | RF Exposure Info | 2016-12-12 | PDF 116.3 KB |
| Block Diagram Metadata only | Block Diagram | PDF 763.5 KB | |
| Schem Docis Board Metadata only | Schematics | PDF 5.7 MB | |
| Schem I O Board Metadata only | Schematics | PDF 2 MB | |
| Schem PS Board Metadata only | Schematics | PDF 377.9 KB | |
| Schem Wifi Board Part 1 Metadata only | Schematics | PDF 3.1 MB | |
| Schem Wifi Board Part 2 Metadata only | Schematics | PDF 3.2 MB | |
| Theory of Operations Metadata only | Operational Description | PDF 270.8 KB | |
| Device Security Metadata only | SDR Software/Security Inf | PDF 201.1 KB |
Application Information
| Application ID | mVl1cBy+qIb88kvu6Y/WFQ== |
|---|---|
| Final Action Date | 2016-12-12 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0009654609 |
| Model | TG3482ER |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wireless Telephony Gateway |
| Responsible Party | Antonio A Figueiredo, Manager -Regulatory/Compliance, tony.figueiredo@arrisi.com , 678-473-5067 |
| Technical Contact | Antonio A. Figueiredo, ARRIS Group, Inc., tony.figueiredo@arris.com  , 678-473-5067 |
| Test Firm | Greg Kovolenko, EUROFINS ELECTRICAL AND ELECTRONIC TESTING NA, INC, greg.kovolenko@metlabs.com  , 4108444071 |
| TCB Email | tcbinfo@metlabs.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 01/26/2017 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | BLE, Thread, Zigbee Output power is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Wi-Fi Output power is aggregate conducted. This device has 20 and 40 MHz bandwidth modes. Device is a 2 x 2 MIMO. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| mVl1cBy+qIb88kvu6Y/WFQ== | 2016-12-12 | Original Equipment |
| XgvXTjBAEjMi3e0MnfBU1Q== | 2016-12-12 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application XgvXTjBAEjMi3e0MnfBU1Q==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Electrical and Electronic Testing NA, Inc 914 W. Patapsco Avenue Baltimore, MD 21230-3432 |
Date of Grant: 12/12/2016 Application Dated: 12/12/2016 |
| ARRIS |
| 3871 Lakefield Drive |
| Suite 300 |
| SUWANEE, GA 30024 |
| Attention: Antonio Figueiredo , Manager -Regulatory/Compliance |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | UIDTG3482ER |
| Name of Grantee: | ARRIS |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Wireless Telephony Gateway |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.39 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.4 |
| Output power is aggregate conducted. This device has 20, 40, and 80 MHz bandwidth modes in a MIMO configuration. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
