FCC ID UIDXBB1
Battery Backup
by ARRIS
Grantee Code: UID Product Code: XBB1
Latest application date: 2016-10-13
Device Images
FCC ID Device Details
| FCC ID | UIDXBB1 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | UID |
| Product Code | XBB1 |
| Applicant Business | ARRIS 🇺🇸 |
| Related Domains |  arrisi.com  sgs.com |
| Equipment Class | Battery Backup |
| Test Firm | SGS North America, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2480 MHz | Original Equipment | 2016-10-13 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-10-13 | PDF 323.2 KB |
| Internal Photos | Internal Photos | 2016-10-13 | PDF 638.4 KB |
| External photos | External Photos | 2016-10-13 | PDF 311.9 KB |
| Label | ID Label/Location Info | 2016-10-13 | PDF 73.8 KB |
| Label Location | ID Label/Location Info | 2016-10-13 | PDF 144.2 KB |
| Setup Photos | Test Setup Photos | 2016-10-13 | PDF 744.5 KB |
| RF Test Report | RF Exposure Info | 2016-10-13 | PDF 393.1 KB |
| Test Report DTS | Test Report | 2016-10-13 | PDF 2 MB |
| Agent Authorization | Cover Letter(s) | 2016-10-13 | PDF 76.3 KB |
| Confidentiality letter | Cover Letter(s) | 2016-10-13 | PDF 119 KB |
| Block Diagram Metadata only | Block Diagram | PDF 262.1 KB | |
| Schematics Metadata only | Schematics | PDF 887.2 KB | |
| Operational Description Metadata only | Operational Description | PDF 195.2 KB |
Application Information
| Application ID | BuM1dp7EA8gwKCpvRg7h3w== |
|---|---|
| Final Action Date | 2016-10-13 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0009654609 |
| Model | XBB1 |
| Frequency Range | 2405-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Battery Backup |
| Responsible Party | Antonio A Figueiredo, Manager -Regulatory/Compliance, tony.figueiredo@arrisi.com , 678-473-5067 |
| Agent | Jeremy Jeremy Jeremy, SGS North America, jeremy.pickens@sgs.com , 770-570-1800 |
| Technical Contact | Jeremy Pickens, SGS North America, jeremy.pickens@sgs.com , 770-570-1800 |
| Non-Technical Contact | Jeremy Pickens, SGS North America, jeremy.pickens@sgs.com , 770-570-1800 |
| Test Firm | David Schramm, SGS North America, Inc., david.schramm@sgs.com , 973-461-7914 |
| TCB Email | uscts.tcb@sgs.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is peak conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter evaluation procedures as documented in this filing. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| BuM1dp7EA8gwKCpvRg7h3w== | 2016-10-13 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2405-2480 MHz | 0.0100000 | 15C |
Grants
TCB Grant - Application BuM1dp7EA8gwKCpvRg7h3w==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
SGS North America, Inc. 620 Old Peachtree Road NW Suite 100 Suwanee, GA 30024 |
Date of Grant: 10/13/2016 Application Dated: 10/13/2016 |
| ARRIS |
| 3871 Lakefield Drive |
| Suite 300 |
| SUWANEE, GA 30024 |
| Attention: Antonio Figueiredo , Manager -Regulatory/Compliance |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | UIDXBB1 |
| Name of Grantee: | ARRIS |
| Equipment Class: | Digital Transmission System |
| Notes: | Battery Backup |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.01 |
| Power output listed is peak conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter evaluation procedures as documented in this filing. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance |
EAS Grant - Application BuM1dp7EA8gwKCpvRg7h3w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ARRIS 3871 Lakefield Drive Suite 300 SUWANEE, GA 30024 United States |
Date of Grant: 10/13/2016 Application Dated: 10/13/2016 |
| Attention: Antonio Figueiredo , Manager -Regulatory/Compliance |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | UIDXBB1 |
| Name of Grantee: | ARRIS |
| Equipment Class: | Digital Transmission System |
| Notes: | Battery Backup |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2405.0 - 2480.0 | 0.01 |
| Power output listed is peak conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter evaluation procedures as documented in this filing. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance |
