0002B Spread Spectrum Transmitter Test Setup... - FCC ID UJA0002B
FCC ID UJA0002B
Test Setup Photos
Spread Spectrum Transmitter
by Pyramat LLC
Document preview loads when visible.
Document Details
| FCC ID | UJA0002B |
|---|---|
| Document ID | 850931 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Document Title | test Setup |
| Applicant | Pyramat LLC |
| Equipment Class | Spread Spectrum Transmitter |
| Product Code | 0002B |
| Application ID | AoBNh2G7WWyEfZEx+LYN0Q== |
| Application Purpose | Original Equipment |
| Application Date | 2007-10-03 |
| Frequency Range | 2404-2479 MHz |
| FRN | 0015346133 |
| Test Firm | Intertek Testing Services Limited Shanghai |
| Certified By | Suresh Kondapalli EMC team Leader |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2007-10-03 |
| Available | 2007-10-03 |
| Created | 2007-09-11 |
| Modified | 2007-09-11 |
| Pages | 6 |
| File Type | Adobe Acrobat PDF |
| File Size | 481753 |
| File SHA-256 | 47630ca02ccdef74a0891077c51db03f8a8b5d03ccd22f13d2ca1b70f3ffd8c0 |
| PDF Metadata Author | wakeyouw |
| PDF Metadata Creator | PScript5.dll Version 5.2.2 |
| PDF Metadata Producer | Acrobat Distiller 6.0 (Windows) |
| FCC.gov Sources | FCC.gov 850931 |
