AM515 Smartphone Test Setup Photos - FCC ID UOSAM515
FCC ID UOSAM515
Setup Photos
Smartphone
Document preview loads when visible.
Document Details
| FCC ID | UOSAM515 |
|---|---|
| Document ID | 3399466 |
| Document Type | Test Setup Photos |
| Description | Setup Photos |
| Document Title | Test Setup Photos Part 15B----已贴 |
| Applicant | Amgoo Telecom Co., Ltd. |
| Equipment Class | Smartphone |
| Product Code | AM515 |
| Application ID | VOEQ1z96w+SivWNeJSz1yA== |
| Application Purpose | Original Equipment |
| Application Date | 2017-05-22 |
| FRN | 0022456610 |
| Test Firm | Bay Area Compliance Laboratories Corp.(kunshan) |
| Certified By | James Wang |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2017-05-22 |
| Available | 2017-05-22 |
| Created | 2017-10-24 |
| Modified | 2017-10-24 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 372148 |
| File SHA-256 | 7534c3eadf3473002001c6d7181fa3b4235269d1eb5f38c1f8b5ca8c271d3aec |
| PDF Metadata Author | SZ141 |
| PDF Metadata Producer | GPL Ghostscript 9.18 SZ141 |
| FCC.gov Sources | FCC.gov 3399466 |
