AWA24R 2.4 GHz Wireless Module Test Setup Photos - FCC ID UP2AWA24R
FCC ID UP2AWA24R
Test Setup Photos
2.4 GHz Wireless Module
Document preview loads when visible.
Document Details
| FCC ID | UP2AWA24R |
|---|---|
| Document ID | 3185178 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Document Title | Test Setup |
| Applicant | Artaflex, Inc. |
| Equipment Class | 2.4 GHz Wireless Module |
| Product Code | AWA24R |
| Application ID | zc013O+pXCz4OLcy5QepFg== |
| Application Purpose | Original Equipment |
| Application Date | 2016-11-03 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0021807284 |
| Test Firm | TUV SUD CANADA (Gormley) |
| Certified By | Kashif Ahmed |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2016-11-03 |
| Available | 2016-11-03 |
| Created | 2016-11-02 |
| Modified | 2016-11-02 |
| Pages | 5 |
| File Type | Adobe Acrobat PDF |
| File Size | 717055 |
| File SHA-256 | c44e48071e4babfcf013bca9eb0e8a6da23091ec01c6f72ef5327f71aad6ad82 |
| PDF Metadata Author | TUV SUD Canada |
| PDF Metadata Producer | Microsoft® Word 2013 Microsoft® Word 2013 |
| FCC.gov Sources | FCC.gov 3185178 |
