EIPT1020 RC Car Test Setup Photos - FCC ID UV5EI-PT1020

FCC ID UV5EI-PT1020

Radiated Emission

RC Car

by EB Excalibur, Inc.

Document preview loads when visible.

Document Details

FCC IDUV5EI-PT1020
Document ID798453
Document TypeTest Setup Photos
DescriptionRadiated Emission
Document Title798453.DOC
ApplicantEB Excalibur, Inc.
Equipment ClassRC Car
Product CodeEIPT1020
Application IDhbE98l+DmZIDqeN8FuxO6A==
Application PurposeOriginal Equipment
Application Date2007-05-30
Frequency Range27.145 MHz
FRN0018090274
Test FirmIntertek Testing Services Hong Kong
Certified ByAnthony Chan Assistant Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2007-05-30
Available2007-05-30
Created2007-05-30
Modified2007-05-30
Pages1
File TypeMicrosoft Word
File Size159233
File SHA-256a32ae086c22715ebca5a0de743f7c673f28bc77599dbc8fc66fab40db8043193
PDF Metadata AuthorReal
PDF Metadata CreatorPScript5.dll Version 5.2
PDF Metadata ProducerAcrobat Distiller 5.0.5 (Windows)
FCC.gov SourcesFCC.gov 798453
